Snowmobile Arctic Cat (2004 year). Manual - part 59





5-3

5

Electrical

Specifications

(370/440 cc)

„

NOTE: The ignition system is a Normally Open Ignition (NOI).

Peak Voltage Tests were made with connectors plugged in, spark plugs removed and grounded, and by pull-
ing the recoil starter rope briskly.

„

NOTE: Lighting coil output is unregulated voltage.

Description

Resistance Test

Test Value

  + Test Connections -

Ignition Coil

Primary
Secondary

0.25-0.34 ohm

6800-10,200 ohms

orange

high tension wire

black

high tension wire

Stator Coil (Charge)

128-192 ohms

red/white

black/red

Lighting Coil

0.17-0.26 ohm

yellow

yellow

Spark-Plug Cap

4000-6000 ohms

cap end

cap end

Description

Test Value

+ Test Connections -

Voltage Regulator

1.9-2.1 AC volts

yellow

brown

Low Oil-Light Sending

Unit

Less than 1 ohm

(float end down)

terminal

terminal

Ignition Switch

Less than 1 ohm

(key in OFF position)

terminal

terminal

Description

Peak Voltage Test

+ Test Connections -

Primary Coil

170-187V

orange

black

Stator Coil (Charge)

200-220V

red/white

black/red

Lighting Coil

9.0-9.9V

yellow

yellow

5-4

Electrical

Specifications

(550 cc)

„

NOTE: The ignition system is a Normally Open Ignition (NOI).

Peak Voltage Tests were made with connectors plugged in, spark plugs removed and grounded, and by pull-
ing the recoil starter rope briskly.

„

NOTE: Lighting coil output is unregulated voltage.

Description

Resistance Test

Test Value

+ Test Connections -

Ignition Coil

Primary
Secondary

0.25-0.34 ohm

6800-10,200 ohms

orange

high tension wire

black

high tension wire

Charge Coil (1)

128-192 ohms

red/white

black/white

Charge Coil (2)

13.6-20.4 ohms

black/red

red/white

Lighting Coil

0.17-0.26 ohm

yellow

yellow

Spark-Plug Cap

4000-6000 ohms

cap end

cap end

Description

Test Value

 + Test Connections -

Voltage Regulator

1.2-1.3 AC volts

yellow

brown

Low Oil-Light Sending

Unit

Less than 1 ohm

(float end down)

terminal

terminal

High Temperature

Sensor

Open (water temperature

lower than 190°F)

terminal

ground

Up to 20 ohms

(water temperature

higher than 230°F)

terminal

ground

High Temperature

Warning Light

Less than 10 ohms

terminal

terminal

Ignition Switch

Less than 1 ohm

(key in OFF position)

terminal

terminal

Description

Peak Voltage Test

+ Test Connections -

Primary Coil

177-195V

orange

black

Charge Coil (1)

9.0-9.9V

red/white

black/white

Charge Coil (2)

9.0-9.9V

black/red

red/white

Lighting Coil

10-11V

yellow

yellow

5-5

5

Electrical

Specifications



(500 cc w/APV)

„

NOTE: The ignition system is a Normally Open

Ignition (NOI).

Peak Voltage Tests were made with connectors plugged in, spark plugs removed and grounded, and by pull-
ing the recoil starter rope briskly.

„

NOTE: Lighting coil output is unregulated volt-

age.

Description

Resistance Test

Test Value

 + Test Connections -

Ignition Coil

Primary
Secondary

0.27-0.41 ohm

6800-10,200 ohms

orange

high tension wire

black

high tension wire

DC Power Coil

0.71-1.07 ohms

red/yellow

yellow/red

Ignition Timing Sensor

148-222 ohms

green/white

brown/green

Lighting Coil

0.12-0.18 ohm

yellow

yellow

Spark-Plug Cap

4000-6000 ohms

cap end

cap end

Description

Test Value

 + Test Connections -

Voltage Regulator

1.2-1.3 AC Volts

yellow

brown

Low Oil-Light Sending

Unit

Less than 1 ohm

(float end down)

terminal

terminal

Ignition Switch

Less than 1 ohm

(key in OFF position)

terminal

terminal

Description

Peak Voltage Test

+ Test Connections -

CDI/External Coil

150V

orange

black

DC Power Coil

10V

red/yellow

yellow/red

Ignition Timing Sensor

1.4-1.6V

green/white

brown/green

Lighting Coil

4V

yellow

yellow

5-6

Electrical

Specifications

(500 w/o APV/570 cc)

„

NOTE: The ignition system is a Normally Open Ignition (NOI).

Peak Voltage Tests were made with connectors plugged in, spark plugs removed and grounded, and by pull-
ing the recoil starter rope briskly.

„

NOTE: Lighting coil output is unregulated voltage.

Description

Resistance Test

Test Value

 + Test Connections -

Ignition Coil

Primary
Secondary

0.25-0.34 ohm

6800-10,200 ohms

orange

high tension wire

black

high tension wire

Charge Coil (1)

12-18 ohms

black/red

green/red

Charge Coil (2)

12-18 ohms

brown/white

green/red

Ignition Timing Sensor

148-222 ohms

green/white

brown

Lighting Coil

0.12-0.18 ohm

yellow

yellow

Spark-Plug Cap

4000-6000 ohms

cap end

cap end

Description

Test Value

 + Test Connections -

Voltage Regulator
(500 cc)

1.2-1.3 AC volts

yellow

brown

Voltage Regulator
(570 cc)

1.9-2.1 AC volts

yellow

brown

Low Oil-Light Sending

Unit

Less than 1 ohm

(float end down)

terminal

terminal

Ignition Switch

Less than 1 ohm

(key in OFF position)

terminal

terminal

Description

Peak Voltage Test

 + Test Connections -

Primary Coil

185-204V

orange

black

Charge Coil (1)

69-76V

black/red

green/red

Charge Coil (2)

79-87V

brown/white

green/red

Ignition Timing Sensor

1.4-1.6V

green/white

brown

Lighting Coil

7.0-7.7V

yellow

yellow
