Snowmobile Arctic Cat (2002 year). Manual - part 35

2-123

2

570ENG2

271

1.8-2.2 kg-m

(13-16 ft-lb)

1.8-2.2 kg-m

(13-16 ft-lb)

4.6 kg-m

(29-43.5 ft-lb)

0.7-1.0 kg-m

(5-7 ft-lb)

HT

HT

1.1 kg-m

(8 ft-lb)

0.8-2.1 kg-m

(6-9 ft-lb)

1.8-2.8 kg-m

(13-20 ft-lb)

609*

271

271

8.0-8.7 kg-m

(58-63 ft-lb)

0.7 kg-m

(5 ft-lb)

271

1.8-2.2 kg-m

(13-16 ft-lb)

1.8-2.2 kg-m

(13-16 ft-lb)

4.6 kg-m

(29-43.5 ft-lb)

0.7-1.0 kg-m

(5-7 ft-lb)

HT

HT

1.1 kg-m

(8 ft-lb)

0.8-2.1 kg-m

(6-9 ft-lb)

1.8-2.8 kg-m

(13-20 ft-lb)

609*

271

271

271

8-8.7 kg-m

(58-63 ft-lb)

0.8-1.2 kg-m

(6-9 ft-lb)

0.8-1.2 kg-m

(6-9 ft-lb)

*Must be used in conjunction

with Loctite Primer #7471.

0.8-1.2 kg-m

(6-9 ft-lb)

2-124

800 cc

800-ENG

10 mm  4.8-5.4 kg-m

(35-39 ft-lb)

8

6 mm   0.9-1.3 kg-m

(6.5-9.5 ft-lb)

mm  1.8-2.8 kg-m

(13-20 ft-lb)

HT

242

2.4 kg-m

(17 ft-lb)

2.4 kg-m

(17 ft-lb)

2.8-3.5 kg-m

(20-25 ft-lb)

2.8-3.5 kg-m

(20-25 ft-lb)

6.9-7.6 kg-m

(50-55 ft-lb)

242

242

2-125

2

800ENG2

2.6-3.3 kg-m

(19-24 ft-lb)

0.9-1.3 kg-m

(6.5-9.5 ft-lb)

1 kg-m

(7 ft-lb)

242

1-1.4 kg-m

(7-10 ft-lb)

2.5-2.8 kg-m

(18-20 ft-lb)

2.4-3.2 kg-m

(17-23 ft-lb)

0.9-1.3 kg-m

(6.5-9.5 ft-lb)

4.8-7.2 kg-m

(35-52 ft-lb)

0.9-1.3 kg-m

(6.5-9.5 ft-lb)

242

242

4.6-6.8 kg-m

(33-49 ft-lb)

242

242

7.95-8.65 kg-m

(57.5-62.5 ft-lb)

HT

0.9-1.3 kg-m

(6.5-9.5 ft-lb)

0.8-1.2 kg-m

(6-9 ft-lb)

242

0.9-1.3 kg-m

(6.5-9.5 ft-lb)

2-126

600 cc Triple

6003-ENG

242

242

HT

1.8-2.8 kg-m

(13-20 ft-lb)

1.8-2.2 kg-m

(13-16 ft-lb)

6.9-7.6 kg-m

(50-55 ft-lb)

1.4 kg-m

(10 ft-lb)

2.4 kg-m

(17 ft-lb)

2.8-3.5 kg-m

(20-25 ft-lb)

2.4 kg-m

(17 ft-lb)
