Snowmobile Yamaha RX1 (2003 year). Manual - part 8

5-13

ESU00053

V-belt holders

Keep a spare V-belt for emergency use by placing it into
the V-belt holders provided.

CAUTION:

@

Make sure that the V-belt is installed securely in the
holders.

@

ESU00342

Storage compartment

The storage compartment is located under the shroud.
Open the storage compartment to store the tool kit,
spare parts, or other small items.

6-1

ESU00072

6-

PRE-OPERATION CHECKS

NOTE:

@

Pre-operation checks should be made each time the
snowmobile is used.

@

WARNING

@

The engine and muffler will be very hot after the
engine has been run.
Avoid touching the engine and muffler while they are
still hot with any part of your body or clothing during
inspection or repair.

@

ESU00075

Fuel

Make sure that there is sufficient fuel in the fuel tank.

WARNING

@

●

Fuel is HIGHLY FLAMMABLE and poisonous.
Check the “SAFETY INFORMATION” section
carefully before refueling. (See page 3-2.)

●

Do not fill the fuel tank above the bottom of the
filler tube

1. Fuel could overflow if the snowmo-

bile is tilted on its side or if the ambient tempera-
ture rises, causing the fuel to warm up and
expand.

●

Make sure that the fuel tank cap is closed
securely after refueling. Leaking fuel can catch
fire.

@

2 Fuel level

CAUTION:

@

●

Oxygenated fuels (gasohol) containing a maxi-
mum 5% of ethanol can be used, although richer
jetting may be required to prevent engine dam-

Recommended fuel:

Unleaded gasoline

Pump octane

; 88 or higher

Fuel tank capacity:

38.0 L (8.4 Imp gal, 10.0 US gal)

R+M

2

6-2

age. Consult a Yamaha dealer. Gasohol contain-
ing methanol is not recommended.

●

Make sure that snow or ice does not enter the fuel
tank when refueling.

●

Do not use alcohol deicers or water absorbing
additives with oxygenated fuel.

●

The fuel tank should be filled with straight gaso-
line as specified.

@

ESU00343

Engine oil

Use a combination of the recommended SAE and API oil
classifications shown in the chart below.

CB-01E

CAUTION:

@

●

Use only 4-stroke engine oil.

●

Engine oil also lubricates the starter clutch. In
order to prevent clutch slippage, do not mix any
chemical additives with the oil or use oils of a
higher grade than “CD”. In addition, do not use
oils labeled “ENERGY CONSERVING II” or higher.

@

SAE

API

SE, SF, SG

or

higher

-40˚

-20˚

0˚

20˚

40˚

60˚ F

SAE 5W-30

-40˚

-29˚

-18˚

-7˚

4˚

16˚ C

E_8fa_Preop.fm  Page 2  Monday, June 17, 2002  1:18 PM

6-3

ESU00344

Engine oil level

The engine oil level should be checked before each use.

CAUTION:

@

Do not run the engine with too much or not enough
oil in the oil tank. Oil could flow into the air filter case
and the engine could be damaged.

@

Checking the engine oil level

1. Place the snowmobile on a level surface and apply

the parking brake.

2. Start the engine, warm it up for 10–15 minutes, and

then turn it off.

3. Disconnect the oil level gauge coupler

1.

CAUTION:

@

Disconnect the oil level gauge coupler before remov-
ing the oil level gauge/dipstick. Otherwise the cable
can twist and become severed.

@

4. Remove the oil level gauge/dipstick

2, wipe it clean,

insert it back into the filler hole (without screwing it
in), and then remove it again to check the oil level.

NOTE:

@

The engine oil should be between the “F”

3 and “E” 4

level marks on the oil level gauge/dipstick.

@

5. If the engine oil is below the “E” level mark, add suffi-

cient oil of the recommended type to raise it to the “F”
level mark. (See page 6-2 for recommended oil.)

CAUTION:

@

●

When adding the engine oil, be careful not to fill
above the “F” level mark on the oil level
gauge/dipstick.

●

Make sure that no foreign material enters the
engine oil tank.

@

6. Insert the oil level gauge/dipstick into the oil filler

hole, and then tighten it securely.

7. Connect the oil level gauge coupler.
