Snowmobile Yamaha FX10X, FX10RTX, FX10RTRX, FX10RTRAX, FX10MTX, FX10MTRX, FX10MTRAX. Manual - part 33

4-21

POWR

TR

DRIVE CHAIN

INSTALLATION

1. During installation, pay attention to the follow-

ing.

È Make sure that the bearing seals face towards the

drive chain as shown.

É Properly install the rubber seal onto the drive chain

cover, making sure that there are no gaps.

Be sure to install the collars in their original
positions, otherwise the brake disc and sec-
ondary shaft will stick.

Ë 0.2 ~ 0.7 mm (0.008 ~ 0.028 in)

: ESSO beacon 325 grease or Aeroshell grease

#7A

For the secondary shaft and drive chain cover
installation, refer to “SECONDARY SHAFT”.

2. Fill:

• Drive chain oil

Refer to “DRIVE CHAIN” in CHAPTER 2.

3. Adjust:

• Drive chain slack

Refer to “DRIVE CHAIN” in CHAPTER 2.

É

É

Ë

Ã

C

4

Ã

C

1

Ã

C

3

Ã

C

2

È

C

1

C

2

C

3

C

4

4-22

POWR

TR

DRIVE CHAIN

WITH REVERSE MODEL

Order

Job name/Part name

Q’ty

Remarks

Drive chain removal

Remove the parts in the order listed below.

Right lower cover

Refer to “COVERS” in CHAPTER 3.

Brake caliper/Parking brake

Refer to “BRAKE”.

1

Shim

—

t = 0.5

2

Washer

1

t = 1.0

3

Brake disc

1

4

Collar

1

5

Drain bolt

1

Drain.

6

Chain tension adjusting bolt

1

Loosen.

7

Gear position switch connector

2

Disconnect.

8

Cover

1

9

Shift lever assembly

1

10

Fuse holder

1

11

Shift rod

1

12

Collar

1

LT

Ê

Í

Î

É

È

É

Ì

Ë

Ë

É

É

Ë

8

10

11

7

9

New

New

New

New

New

New

New

1 2

3

12

5

4

18

27

33

32

6

20

13

21

22

29

30

31

LT

LT

23

24

25

26

28

17

19

16

15

14

6 Nm (0.6 m

•

 kg, 4.3 ft

•

 lb)

10 Nm (1.0 m

•

 kg, 7.2 ft

•

 lb)

È:
É:

16 Nm (1.6 m

•

 kg, 11 ft

•

 lb)

Ê:

Ë:
Ì:

23 Nm (2.3 m

•

 kg, 17 ft

•

 lb)

25 Nm (2.5 m

•

 kg, 18 ft

•

 lb)

Î:

Í:

28 Nm (2.8 m

•

 kg, 20 ft

•

 lb)

55 Nm (5.5 m

•

 kg, 40 ft

•

 lb)

4-23

POWR

TR

DRIVE CHAIN

Order

Job name/Part name

Q’ty

Remarks

13

Drive chain cover

1

14

Rubber seal

1

15

Chain tensioner

1

16

Washer

1

t = 0.5

17

Collar

1

18

Counter gear

1

19

Spring

1

20

Retainer

1

21

Spring

1

22

Reverse driven gear assembly

1

23

Journal

1

24

Washer

1

25

Forward driven sprocket

1

26

Collar

1

27

Reverse drive gear

1

28

Drive chain

1

LT

Ê

Í

Î

É

È

É

Ì

Ë

Ë

É

É

Ë

8

10

11

7

9

New

New

New

New

New

New

New

1 2

3

12

5

4

18

27

33

32

6

20

13

21

22

29

30

31

LT

LT

23

24

25

26

28

17

19

16

15

14

6 Nm (0.6 m

•

 kg, 4.3 ft

•

 lb)

10 Nm (1.0 m

•

 kg, 7.2 ft

•

 lb)

È:
É:

16 Nm (1.6 m

•

 kg, 11 ft

•

 lb)

Ê:

Ë:
Ì:

23 Nm (2.3 m

•

 kg, 17 ft

•

 lb)

25 Nm (2.5 m

•

 kg, 18 ft

•

 lb)

Î:

Í:

28 Nm (2.8 m

•

 kg, 20 ft

•

 lb)

55 Nm (5.5 m

•

 kg, 40 ft

•

 lb)

4-24

POWR

TR

Order

Job name/Part name

Q’ty

Remarks

29

Collar

1

30

Drive sprocket

1

31

Collar

1

32

Plate

1

33

Shaft

1

For installation, reverse the removal proce-
dure.

LT

Ê

Í

Î

É

È

É

Ì

Ë

Ë

É

É

Ë

8

10

11

7

9

New

New

New

New

New

New

New

1 2

3

12

5

4

18

27

33

32

6

20

13

21

22

29

30

31

LT

LT

23

24

25

26

28

17

19

16

15

14

6 Nm (0.6 m

•

 kg, 4.3 ft

•

 lb)

10 Nm (1.0 m

•

 kg, 7.2 ft

•

 lb)

È:
É:

16 Nm (1.6 m

•

 kg, 11 ft

•

 lb)

Ê:

Ë:
Ì:

23 Nm (2.3 m

•

 kg, 17 ft

•

 lb)

25 Nm (2.5 m

•

 kg, 18 ft

•

 lb)

Î:

Í:

28 Nm (2.8 m

•

 kg, 20 ft

•

 lb)

55 Nm (5.5 m

•

 kg, 40 ft

•

 lb)

DRIVE CHAIN
