Snowmobile Polaris 600 RUSH (2010 year). Manual - part 1





1.2

General Information

9923311 - 2010-2012 PRO-RIDE RUSH/Switchback/RMK Service Manual

© 2011 Polaris Sales Inc.

MODEL SPECIFICATIONS

2010 600 RUSH

Model Numbers:

S10BF6KSA / S10BF6KSL / S10BF6KEA

NOTE:   OPTIONAL - USE 2 GRAM LIGHTER CLUTCH
WEIGHTS WHEN OPERATING IN PROLONGED
WARM TEMPERATURES (LATE FALL/SPRING
SEASON) TO MAINTAIN PEAK OPERATING RPM.

Engine

Engine Type

Liberty Liquid-Cooled /

Case Reed Induction

Model Number

S4202-6044-OP6N

Displacement / # Cylinders

599cc / 2

Bore (inches/mm)

3.04 / 77.25

Stroke (inches/mm)

2.52 / 64

Piston to Cylinder
Clearance (inches/mm)

.0033-.0054 / 0.085-0.137

Installed Ring Gap

(inches / mm)

.014-.020 / 0.356 - 0.508

Operating RPM ±200

8250

Idle RPM

1700

Engagement RPM ±200

3800

Exhaust Valve Spring

Purple

Thermostat Opening
Temperature (° F/ ° C)

120 / 49

Fuel Delivery

Type - Number of Fuel
Injectors

DC-CFI - 4

Throttle Body Marking

1203978

Throttle Body Bore

46mm

TPS Voltage @ Idle

(5 VDC +/- .01 Input)

0.95 +/- 0.01 VDC

Fuel Pressure - PSI (bar)

58-60 (4.0-4.1)

Fuel Octane (R+M/2)

10% Ethanol 24

 Resistor


Premium/Non-Ethanol
160

 Resistor

<91 Octane

(Non-Oxygenated)

OR

87/89/91+

(Up to10% Oxygenated)

91+

(Non-Oxygenated)

Clutch Settings

ALTITUDE

meters

(feet)

DRIVE CLUTCH

P2 DRIVEN CLUTCH

Shift

Weight

Clutch
Spring

Clutch
Spring

Driven

Helix

Gearing

0-600

(0-2000)

10-64

BLACK

120 - 310

7043601

130 - 180

Tabbed

7043515

58/42 - .45

5137176

23:39 - 72

600-1200

(2000-4000)

10-62

22:39 - 72

1200-1800

(4000-6000)

10-60

22:40 - 72

1800-2400

(6000-8000)

10-58

2400-3000

(8000-10,000)

10-56

20:41 - 72

3000-3600

(10,000-12,000)

10A-L

Drive Clutch Bolt Torque: 80 lb.ft. (108Nm)

Re-torque after running engine.

Clutch Settings (Electric Start Models)

ALTITUDE

meters

(feet)

DRIVE CLUTCH

P2 DRIVEN CLUTCH

Shift

Weight

Clutch
Spring

Clutch
Spring

Driven

Helix

Gearing

0-600

(0-2000)

10-64

BLK/GRN

120 - 340

7042083

130 - 180

Tabbed

7043515

58/42 - .45

5137176

23:39 - 72

600-1200

(2000-4000)

10-62

22:39 - 72

1200-1800

(4000-6000)

10-60

22:40 - 72

1800-2400

(6000-8000)

10-58

2400-3000

(8000-10,000)

10-56

20:41 - 72

3000-3600

(10,000-12,000)

10A-L

Drive Clutch Bolt Torque: 80 lb.ft. (108Nm)

Re-torque after running engine.

Track

Width - Inches (cm)

15 (38)

Length - Inches (cm)

120 (304.8)

Pitch

Plies

2.86

2

Lug Height - Inches (cm)

1.25 (3.175) (Ripsaw)

Track tension sag in/cm
with 10 lbs/4.54kg placed
16 in/40cm ahead of rear
idler shaft

7/8



- 1-1/8

(2.2 - 2.9cm)

1.3

General Information

1

9923311 - 2010-2012 PRO-RIDE RUSH/Switchback/RMK Service Manual

© 2011 Polaris Sales Inc.

NOTE:  * = Rider weight in everyday clothing.

** = From full soft (CCW) position.

General

Width (in/cm)

48 / 121.9

Length (in/cm)

108 / 274

Height (in/cm)

46 / 117

Estimated Dry Weight (lb/kg)

459 / 208

Fuel (Gallons / Liters)

11 / 41.6

Oil (Quarts / Liters)

3.4 / 3.3

Cooling System Capacity(Qts/ L)

5.25 / 5.0

Brake Fluid

DOT 4

Drive Belt

Part Number

Width (inches / cm)

Side Angle

Circumference (inches / cm)

Center Distance (inches / cm)

3211122

1.460 / 3.7

26_

46.77 / 118.8

11.5 / 29.2

Chaincase

Center Distance (inches)

Top Gear (Stock)

Bottom Gear (Stock)

Chain (Stock)

Gear Lube

Capacity (oz / ml)

Reverse System

7.53

23
39
72

Polaris Synthetic (80W)

9 / 266

PERC

Electrical

Alternator Output

Operating Voltage

Watts @ 13.5 VDC (Total)

13.5 - 14.5 VDC

400

Ignition Timing

18_ @1700 RPM

Coolant Temp = 120_F (49_C)

Spark Plug Gap in.(mm)

.027 (.70)

Spark Plug

NGK BPR9ES

Front Suspension

Suspension Type

PRO-RIDE

Shocks

Walker Evans Needle w/Remote

Reservoir

16 Click Compression Adjustable

Factory Setting** = 6

IFS Spring Rate

lbs/in (N/mm)

80 (14)

IFS Spring Installed
Length - Inches (cm)

Preload = 3.75 (9.5)

10.25 (26)

Front Vertical Travel

Inches (cm)

9 (22.9)

Ski Center Distance

Inches (cm)

Setup Width

42.5 (108)

41.52 (105)

Camber Inches (cm)

1.68

 0.31 (4.3  .8)

Toe Out Inches (mm)

0 -1/8

 (0 - 3)

Rear Suspension

Suspension Type

Pro-Ride Progressive

Front Track Shock

(FTS)

Walker Evans w/Remote Reservoir

16 Click Compression Adjustable

Factory Setting** = 2

FTS Spring Rate

lbs/in (N/mm)

120 - 310 (21 - 54.25)

FTS Spring Installed
Length

Inches (cm)

Preload = .75 (1.9)

7.75 (19.7)

Rear Track Shock

(RTS)

Walker Evans Needle

w/Remote Reservoir

16 Click Compression Adjustable

Factory Setting** = 4

Standard RTS Spring

Rider Weight*

120 - 250lbs.

Rate lbs/in (N/mm)

PN: 7043572-385

190 (33.25)

LW RTS Spring

Rider Weight*

90 - 150lbs.

Rate lbs/in (N/mm)

PN: 7041575-385

120 (21)

HD RTS Spring

Rider Weight*

240 - 335+lbs.

Rate lbs/in. (N/mm)

PN: 7043585-385

260 (45.5)

RTS Spring

Rider / Weight Setting

Spring length set to rider weight

using adjustment gauge.

STD Gauge PN: 5253792

LW Gauge PN: 5253854
HD Gauge PN: 5253855

(STD gauge in tool kit. LW and HD

gauges are accessories and should

be ordered when ordering a LW or

HD spring.)

Rider weight adjustment can also be

performed using tape measure and

RTS Spring Guide Table located in

the Steering/Suspension Chapter.

Rear Travel

Inches (cm)

14 (35.6)

1.4

General Information

9923311 - 2010-2012 PRO-RIDE RUSH/Switchback/RMK Service Manual

© 2011 Polaris Sales Inc.

2011 600 RUSH

Model Numbers:

600 RUSH

S11BF6NSA / S11BF6NSL / S11BF6NSB / S11BF6NSM


600 RUSH LX

S11BD6NSL / S11BD6NSM


600 RUSH PRO-R

S11BP6NSA / S11BP6NSL / S11PB6NEL / S11BP6NSB

S11BP6NSM / S11BE6NSM

NOTE:   OPTIONAL - USE 2 GRAM LIGHTER CLUTCH
WEIGHTS WHEN OPERATING IN PROLONGED
WARM TEMPERATURES (LATE FALL/SPRING
SEASON) TO MAINTAIN PEAK OPERATING RPM.

Engine

Engine Type

Liberty Liquid-Cooled /

Case Reed Induction

Model Number

S4215-6044-OO6N

Displacement / # Cylinders

599cc / 2

Bore (inches/mm)

3.04 / 77.25

Stroke (inches/mm)

2.52 / 64

Piston to Cylinder
Clearance (inches/mm)

.0033-.0054 / 0.085-0.137

Installed Ring Gap

(inches / mm)

.017-.025 / 0.450-0.650

Operating RPM ±200

8250

Idle RPM ±200

1700

Engagement RPM ±200

3800

Exhaust Valve Spring

Purple

Thermostat Opening
Temperature (° F/ ° C)

120 / 49

Fuel Delivery

Type - Number of Fuel
Injectors

DC-CFI - 4

Throttle Body Marking

1203978

Throttle Body Bore

46mm

TPS Voltage @ Idle

(5 VDC +/- .01 Input)

0.95 +/- 0.01 VDC

Fuel Pressure - PSI (bar)

58-60 (4.0-4.1)

Fuel Octane (R+M/2)

10% Ethanol 24

 Resistor


Premium/Non-Ethanol
160

 Resistor

<91 Octane

(Non-Oxygenated)

OR

87/89/91+

(Up to10% Oxygenated)

91+

(Non-Oxygenated)

Clutch Settings

ALTITUDE

meters

(feet)

DRIVE CLUTCH

P2 DRIVEN CLUTCH

Shift

Weight

Clutch
Spring

Clutch
Spring

Driven

Helix

Gearing

0-600

(0-2000)

10-64

BLACK

120 - 310

7043681

130 - 180

Tabbed

7043515

58/42 - .45

5137176

23:39 - 72

600-1200

(2000-4000)

10-62

22:39 - 72

1200-1800

(4000-6000)

10-60

22:40 - 72

1800-2400

(6000-8000)

10-58

2400-3000

(8000-10,000)

10-56

20:41 - 72

3000-3600

(10,000-12,000)

10A-L

Drive Clutch Bolt Torque: 80 lb.ft. (108Nm)

Re-torque after running engine.

Clutch Settings (Electric Start Models)

ALTITUDE

meters

(feet)

DRIVE CLUTCH

P2 DRIVEN CLUTCH

Shift

Weight

Clutch
Spring

Clutch
Spring

Driven

Helix

Gearing

0-600

(0-2000)

10-64

BLK/GRN

120 - 340

7042083

130 - 180

Tabbed

7043515

58/42 - .45

5137176

23:39 - 72

600-1200

(2000-4000)

10-62

22:39 - 72

1200-1800

(4000-6000)

10-60

22:40 - 72

1800-2400

(6000-8000)

10-58

2400-3000

(8000-10,000)

10-56

20:41 - 72

3000-3600

(10,000-12,000)

10A-L

Drive Clutch Bolt Torque: 80 lb.ft. (108Nm)

Re-torque after running engine.

Track

Width - Inches (cm)

15 (38)

Length - Inches (cm)

121 (307)

Pitch

Plies

2.52

2

Lug Height - Inches (cm)

RUSH

RUSH PRO-R

1.0 (2.54) (Hacksaw)

1.25 (3.175) (Ripsaw)

Track tension sag in/cm
with 10 lbs/4.54kg placed
16 in/40cm ahead of rear
idler shaft

1/2



- 1.0

(1.3 - 2.54cm)

1.5

General Information

1

9923311 - 2010-2012 PRO-RIDE RUSH/Switchback/RMK Service Manual

© 2011 Polaris Sales Inc.

NOTE:  * = Rider weight in everyday clothing.

** = From full soft (CCW) position.

General

Width (in/cm)

48 / 121.9

Length (in/cm)

108 / 274

Height (in/cm)

46 / 117

Estimated Dry Weight (lb/kg)

469 / 212

Fuel (Gallons / Liters)

11 / 41.6

Oil (Quarts / Liters)

3.4 / 3.3

Cooling System Capacity(Qts/ L)

6 / 5.7

Brake Fluid

DOT 4

Drive Belt

Part Number

Width (inches / cm)

Side Angle

Circumference (inches / cm)

Center Distance (inches / cm)

3211122

1.460 / 3.7

26_

46.77 / 118.8

11.5 / 29.2

Chaincase

Center Distance (inches)

Top Gear (Stock)

Bottom Gear (Stock)

Chain (Stock)

Gear Lube

Capacity (oz / ml)

Reverse System

7.53

23
39
72

Polaris Synthetic (80W)

9 / 266

PERC

Electrical

Alternator Output

Operating Voltage

Watts @ 13.5 VDC (Total)

13.5 - 14.5 VDC

400

Ignition Timing

18_ @1700 RPM

Coolant Temp = 120_F (49_C)

Spark Plug Gap in.(mm)

.027 (.70)

Spark Plug

NGK BPR9ES

Front Suspension

Suspension Type

PRO-RIDE

Shocks

RUSH

RUSH PRO-R

Fox HPG w/IFP

Walker Evans Needle Piggyback

16 Click Compression Adjustable

Factory Setting** = 6

IFS Spring Rate

lbs/in (N/mm)

100 (17.5)

Spring Preload -
Inches (cm)

4.5 (11.4)

Travel-Inches (cm)

9 (22.9)

Ski Center Distance

Inches (cm)

Setup Width

42.5 (108)

41.52 (105)

Camber Inches (cm)

1.68

 0.31 (4.3  .8)

Toe Out Inches (mm)

0 -1/8

 (0 - 3)

Rear Suspension

Suspension Type

PRO-RIDE Progressive

Front Track Shock

(FTS)

RUSH

RUSH PRO-R

Fox HPG w/IFP

Walker Evans w/Remote Reservoir

16 Click Compression Adjustable

Factory Setting** = 2

FTS Spring Rate

lbs/in (N/mm)

120 - 310 (21 - 54.25)

FTS Spring Installed
Length-Inches (cm)

RUSH Preload

RUSH PRO-R Preload

7.5 (19.05)

1.0 (2.54)
1.0 (2.54)

Rear Track Shock

(RTS)

RUSH

RUSH PRO-R

Fox HPG w/IFP

Walker Evans Needle

w/Remote Reservoir

16 Click Compression Adjustable

Factory Setting** = 4

Standard RTS Spring

Rider Weight*

120 - 250lbs.

Rate lbs/in (N/mm)

PN: 7043572-133

190 (33.25)

LW RTS Spring

Rider Weight*

90 - 150lbs.

Rate lbs/in (N/mm)

PN: 7041575-385

120 (21)

HD RTS Spring

Rider Weight*

240 - 335+lbs.

Rate lbs/in. (N/mm)

PN: 7043585-385

260 (45.5)

RTS Spring

Rider / Weight Setting

Spring length set to rider weight

using adjustment gauge.

STD Gauge PN: 5254748

LW Gauge PN: 5254749
HD Gauge PN: 5254750

(STD gauge in tool kit. LW and HD

gauges are accessories and should

be ordered when ordering a LW or

HD spring.)

Rider weight adjustment can also be

performed using tape measure and

RTS Spring Guide Table located in

the Steering/Suspension Chapter.

Rear Travel

Inches (cm)

14 (35.6)



















Content   ..  1  2  3   ..
