1.38
Model Specifications
2008 700 RMK 155
700 Dragon RMK 155 / 163
Model Number:
Base 155 = S08PM7JS
Dragon 155 = S08PG7JS / S08PG7JE
Dragon 163 = S08PH7JS / S08PH7JE
Engine
Engine Type
Liberty Liquid-Cooled /
Case Reed Induction
Model Number
S3471-7044-PU7J
Displacement / # Cylinders
599cc / 2
Bore (inches/mm)
3.19 / 81
Stroke (inches/mm)
2.67 / 68
Piston to Cylinder Clearance
(inches/mm)
.0044 - .0059 / .112 - .151
Installed Ring Gap
(inches / mm)
.017 - .026 / .44 - .650
Operating RPM (+0 / -300)
8250
Idle RPM
1700
Engagement RPM ±200
3800
Exhaust Valve Spring
Pink
Fuel Delivery
Type
Cleanfire Direct Injection
Throttle Body Marking
1203213
Throttle Body Bore
46mm
TPS Voltage @ Idle
0.95 +/- 0.01 Vdc
Fuel Pressure - PSI (bar)
58 (4.0)
Recommended Fuel Octane
(R+M/2)
91 Non-Oxygenated
Clutch Settings
ALTITUDE
meters
(feet)
DRIVE CLUTCH
DRIVEN CLUTCH
Shift
Weight
Clutch
Spring
Clutch
Spring
Driven
Helix
Gearing
0-600
(0-2000)
10-66
140 / 330
(7043342)
BLACK
(155 / 222)
(7043063)
56/42 - .36
LW-ER
20:41-76
600-1200
(2000-4000)
10-64
1200-1800
(4000-6000)
10-62
1800-2400
(6000-8000)
10-60
2400-3000
(8000-10,000)
10-58
3000-3600
(10,000-12,000)
10-56
Drive Clutch Bolt Torque: 80 lb.ft. (108Nm)
General
Width (in/cm)
46.5 / 118.1
Length (in/cm)
129 / 327.7
Height (in/cm)
48 / 121.9
Estimated Dry Weight (lb/kg)
Base 155
Dragon 155
Dragon 163
489 / 221.8
484 / 219.5
489 / 221.8
Fuel (Gallons / Liters)
11.5 / 43.5
Oil (Quarts / Liters)
3 / 2.8
Cooling System Capacity
(Quarts / Liters)
155 = 6.5 / 6.1
163 = 6.625 / 6.3
Brake Fluid
DOT 4
Drive Belt
Part Number
Width (inches / cm)
Side Angle
Circumference (inches / cm)
Center Distance (inches / cm)
3211115
1.460 / 3.7
26_
46.77 / 118.8
11.5 / 29.2
Chaincase
Center Distance (inches)
Top Gear (Stock)
Bottom Gear (Stock)
Chain (Stock)
Gear Lube
Capacity (oz / ml)
Reverse System
8.373
20
41
76
Polaris Synthetic
11 / 325.3
Perc
Electrical
Alternator Output
Operating Voltage
Watts @ 13.5 Vdc (Total)
13.5 - 14.5 Vdc
400
Ignition Timing
18_ @1700 RPM
Coolant Temp = 120_F (49_C)
Spark Plug Gap in.(mm)
.027 (.70)
Spark Plug
Champion RN57YCC
Track
Width - Inches (cm)
15 (38)
Length - Inches (cm)
155 (393.7)
163 (414)
Lug Height - Inches (cm)
2.4 (6.1)
Track tension sag in/cm with
10 lbs/4.54kg placed 16 in/
40cm ahead of rear idler shaft
3/8
″
- 1/2
″
(1 - 1.3cm)
