59

THE PERFECT FIT

IQ Rear Suspension Adjustments

Weight Transfer During Acceleration

The preferred method for controlling
weight transfer during acceleration is
by adjusting the rear rear scissor stop
(RRSS). The factory setting is the
best for most trail riding conditions.

To decrease weight transfer under
acceleration (for improved corner-
ing), rotate the RRSS to a higher
position.

To increase weight transfer or ski lift
during acceleration, rotate the RRSS
to a lower position.

Tip: Your dealer can help you with initial

setup and additional setup
instructions to help you achieve your
optimum ride. A scissor stop tool is
also available from your dealer.

Track Tension

Track adjustment is critical for proper handling. Always maintain
correct tension and alignment. Refer to the track tension maintenance
section beginning on page 110.

HIGH

LOW

LOW

MEDIUM

60

THE PERFECT FIT

Handlebar Adjustments

Use the RIDER SELECT feature to adjust handlebar position. See page
33. Use the following steps to adjust handlebar angle at the handlebar
block.

1. Remove the handlebar cover

to expose the handlebar and
the four adjuster block bolts.

2. Using a 7/16" wrench, loosen

the four nuts on the bottom of
the adjuster block (turn han-
dlebar to left or right for
access to back nuts).

Tip: If necessary, pry the blocks apart

with a screwdriver.

3. Adjust the handlebar to the

desired height. Be sure
handlebars, brake lever and
throttle lever operate
smoothly and do not hit the
gas tank, windshield or any
other part of the machine
when turned fully to the left
or right. If necessary, loosen the set screws for the left and right
controls, rotate the controls slightly, then tighten the set screws to
the proper torque.

NOTICE: Do not stretch wires while adjusting the controls. Stretching the wires

could damage the handwarmers.

• Right control torque: 35 in. lbs. (3.95 Nm) +/- 10%.

• Left control torque: 24 in. lbs. (2.7 Nm) +/- 10%.

4. Torque the front bolts first, then torque the rear bolts. Torque the

bolts to 15-17 ft. lbs. (20-23 Nm).

5. Reinstall the handlebar cover.

Handlebar
Cover

Adjuster
Block
Bolts

Nuts

61

THE PERFECT FIT

Accessories

POLARIS offers a wide range of accessories for your snowmobile to
help make each ride more enjoyable.

Use only POLARIS parts and accessories on your POLARIS
snowmobile. Use of unapproved parts and accessories may result in:

• Non-compliance with government/industry requirements

• Voiding of warranty

• Injury to self or others

This applies, but is not limited to the following areas: brakes, clutches,
fuel systems, and exhaust systems. Exhaust systems are critical safety
areas that must use approved POLARIS parts. Please see your
POLARIS dealer for service.

62

THE PERFECT FIT

Traction Products

Studs

Before equipping your snowmobile with traction products, be aware of
the laws in your area pertaining to the use of traction products.

Use only POLARIS traction products on your snowmobile. Track
warranties are void if track damage or failure results from improper or
excessive stud installation or the use of non-POLARIS traction
products.

See your dealer about installing studs and/or carbides.

NOTICE: Always install wear strips before installing studs. Failure to install wear

strips may result in cooler or tunnel damage. See page 63.

Never add shims to the wear strip. Track damage will result because
of lack of clearance between upper carrier wheels and track.

Use of studs longer than the recommended length on machines
equipped with center coolers will result in center cooler damage or
damage to the tunnel.

Track studding will enhance braking control on hard-packed snow or
ice, but extreme caution is still required on such surfaces. Steering
ability may be reduced on hard-packed snow or ice.

When studded tracks are used, increased wear to the brake pads will
result from increased braking. Extended-wear brake pad kits are
available. See your dealer.

NOTICE: Aggressive studding patterns may require grinding protruding stud

bolts flush to prevent idler wheel damage. Maintain track tension on
studded tracks on the tight side of the spec to prevent heat exchanger
damage. Center of stud must be at least 1 1/8” (2.86 cm) from the
outside edge of the track.
