95

MAINTENANCE

Engine Oil

Oil Level Check

The oil level in the oil bottle may drain below the level of the dipstick if
the engine has not run for more than a week. If you're not sure if there is
oil in the system, you must first check to make sure oil is in the system
before checking the oil level. Perform the “Oil in System Check” proce-
dure on page 97 before performing the oil level check.

1. Position the vehicle on a level surface.

2. If the engine is cold, start the engine and allow it to idle until the

engine coolant temperature reaches the specified range. Proceed to
step 4.

3. If the engine has been running, stop the engine and verify that cool-

ant temperature is within the specified range for performing the oil
check. Allow the engine to cool if necessary. When the coolant is
within the specified range, restart the engine and allow it to idle for
no more than 20 seconds to circulate the oil back into the tank.

4. Turn the engine off.

Tip: Check the oil level within three

minutes, before the coolant tem-
perature (and oil level) begin to
drop.

5. Remove the dipstick from the

oil tank.

6. Clean the dipstick with a

clean shop towel and reinstall
it, screwing it in completely.

7. Remove the dipstick and

view the oil level.

Tip: The oil level reading will be accurate for only one to three minutes after

turning off the engine. If the oil check isn't completed within three minutes,
reinstall the dipstick. Restart the engine and allow it to idle for no more than
20 seconds to circulate the oil back into the tank.

Dipstick

96

MAINTENANCE

Engine Oil

Oil Level Check

8. Maintain the oil level in

the safe operating range,
between the upper and
lower marks on the dip-
stick. If the level is low,
add the recommended oil
in small increments, about 2 ounces (60 ml), and recheck the level.

Tip: If the level is low, or when changing the oil, add only enough oil to bring the

level to the bottom of the safe operating range on the dipstick.

9. If the level is high, remove 2 ounces (60 ml) and recheck the level.

NOTICE: Do not overfill the oil tank. Engine damage may occur. Always add oil

in small increments and recheck the level to avoid overfilling.

10. Recheck the oil level if oil was added or removed, making sure the

coolant temperature is within the specified range. If necessary, con-
tinue adding or removing oil until the level is in the safe operating
range.

Fill mark for oil changes
(at specified coolant temperature)

Safe operating range

97

MAINTENANCE

Engine Oil

Oil in System Check

1. Position the vehicle on a level surface. Start the engine and allow it

to idle 3-5 seconds (no more than 5 seconds). Turn the engine off.

2. Remove the dipstick. Clean the dipstick with a clean shop towel and

reinstall it, screwing it in completely. Remove the dipstick and ver-
ify that oil is present anywhere on the dipstick.

3. If oil is present, continue with the oil level check procedure begin-

ning on page 94.

4. If oil is not present, add 1/2 quart (.47 l) of the recommended oil.

Reinstall the dipstick, start the engine for no more than 5 seconds,
stop the engine, and recheck for the presence of oil.

5. If oil is present, continue with the oil level check procedure begin-

ning on page 94.

6. If oil is not present, add another 1/2 quart (.47 l) of oil. Reinstall the

dipstick, start the engine for no more than 5 seconds, stop the
engine, and recheck for the presence of oil.

7. If no oil is present on the dipstick, check the oil system for leaks and

proper operation or see your POLARIS dealer.

98

MAINTENANCE

Engine Oil

Oil Change

Always change the oil at the intervals outlined in the Periodic Mainte-
nance Table beginning on page 91. Clean the foam oil breather element
with each engine oil change. See page 102.

Always use the recommended oil. See page 94, or see your POLARIS
dealer about oil change kits, which contain a new filter and the recom-
mended oil.

Tip: A special jumper harness is required for changing the oil on this vehicle.

Please see your POLARIS dealer to purchase the harness, which will allow
you to use the ignition key to turn over the engine without starting it. You
may also need an assistant to help with the oil change.

1. Position the vehicle on a level surface.

2. Make sure the engine coolant temperature is between 145° and 160°

F. (63°-71° C). If necessary, start the engine and allow it to idle until
the coolant temperature is within the specified range.

3. Turn the engine off.

CAUTION! Hot oil and a hot exhaust system and engine can cause burns. Do
not allow hot oil or hot components to contact skin.

4. Open the hood and remove the right side panel.

Tip: Clamp orientation is critical to the proper operation of the system. Be aware

of clamp placement and orientation when removing hose clamps. Always
reinstall hose clamps in the same location and position.
