57

OPERATION

Carburetion

Jetting Guidelines

Changes in altitude and temperature affect air density, which is the

amount of oxygen available for combustion. In low elevations and cold

temperatures, the air has more oxygen. In higher elevations and higher

temperatures, the air is less dense.
RMK carburetors are preset to operate at altitudes of 6000-8000 feet

(1800-2400 m) above sea level (see page 78 for more information). Car-

buretors must be re-calibrated if the snowmobile is operated outside this

production temperature and/or altitude range. The main jet installed in

production is not correct for all altitudes and/or temperatures.

NOTICE: A main jet that’s too small will cause a lean operating condition and

may cause serious engine damage. Jet the carburetors carefully for

elevation and temperature according to the jetting charts. See your

Owner’s Manual Supplement.

Tip: It’s the owner’s responsibility to ensure that the correct jets are installed in

the machine for a geographical area. Be very careful when jetting down in

warm weather. As the weather turns colder it will be necessary to re-jet

upward to prevent engine damage. When selecting the proper main jet

always use the lowest elevation and temperature that is likely to be encoun-

tered.

58

OPERATION

n

Engine Stop Switch

Push down on the engine

stop switch to stop the

engine in an emergency.

This will ground out the

ignition and bring the

engine to a quick stop.

To restart the engine, the

switch must be pulled up

to the ON position.

n

Throttle Safety Switch

The throttle safety switch is designed to stop the engine whenever all

pressure is removed from the throttle lever and the throttle cable or

valves do not return to the normal closed position. Test the throttle

safety switch system daily before operation.

WARNING! Operating the snowmobile with a faulty throttle safety switch can

result in serious injury or death in the event of an accident. If the throttle safety

switch does not shut off the engine during a carburetor/throttle system

malfunction, immediately push down the engine stop switch. Do not start the

engine again until the malfunction has been corrected by your dealer.

Test the throttle safety switch

system daily before operation.
1. Sit on the seat.
2. Start the engine and allow it

to idle.

3. Hold the throttle lever pin

stationary by exerting pres-

sure on the pivot pin in the direction shown in the illustration.

4. Apply a slight amount of throttle. A properly functioning switch

must shut down the engine.

Stop Switch

59

OPERATION

n

Throttle Lever

WARNING! An improperly functioning throttle lever may cause erratic machine

behavior and loss of control, which could result in serious injury or death. If the

throttle lever does not work properly, DO NOT start the engine.

If the engine stops abruptly when the throttle lever is released:
1. Turn the ignition switch to OFF.
2. Visually inspect the throttle cable and carburetor(s) to determine

what caused the safety switch to activate.

3. Test the throttle lever by compressing and releasing it several times.

The lever and cable must return to the idle position quickly and

completely.

4. If the throttle lever operates properly, turn the ignition switch on and

go through normal starting procedures.

5. If the engine doesn’t start, take the snowmobile to an authorized

Polaris dealer for service.

Excessive free play in the throttle cable may cause the safety switch to

activate, preventing the engine from starting. If this occurs, return the

machine to an authorized Polaris dealer for service.
If an emergency exists and it’s necessary to start the engine, the throttle

safety switch and engine stop switch may be disconnected from the wire

harness. When these switches are disconnected, the ignition key switch

must be used to shut off the engine. DO NOT continue to operate the

machine with the throttle safety switch disconnected. Return the

machine to an authorized Polaris dealer for service as soon as possible.

60

OPERATION

Emergency Stopping

The following chart lists methods for stopping the snowmobile in the

event of an emergency. Refer to page 58 for more information about the

engine stop switch and throttle safety switch.

WARNING! Excessive or repetitive use of brakes for high speed stops will

cause an overheated brake system. This overheated condition could cause

sudden loss of brakes and/or fire, resulting in serious injury or death. When

traveling on long downhill stretches, pump the brakes. Riding the brakes may

cause the brake system to overheat and result in brake failure.

SYSTEM

WHAT IT DOES

THROTTLE

CONDITION

Ignition Switch

Interrupts ignition circuit

All

Brake

Slows jackshaft

All

Choke

Floods engine

Half throttle or less

Engine Stop Switch

Interrupts ignition circuit

All

Throttle Safety Switch

Interrupts ignition circuit

All
