37

THE PERFECT FIT

Rear Suspension Adjustments

Shock Compression Damping

Your snowmobile is equipped with the Indy Select rear shock, which

allows for adjustments to the compression valving.
1. Locate the adjustment screw near the base of the shock.
2. Adjust the screw 1/2 turn clockwise to increase compression valv-

ing and stiffen the ride. Test ride the snowmobile before making

further adjustments.

Tip: An excessive adjustment can result in damage to the shock. When adjust-

ing these shocks, we recommend that you turn the screw only 1/2 turn at a

time, then test ride.

3. Adjust the screw 1/2 turn counterclockwise to reduce compression

and soften the ride.

There are approximately three full turns of adjustment available. If bot-

toming continues after the screw has been turned fully clockwise, the

torsion spring should be adjusted (see page 36). Return the screw to its

original starting position after the torsion spring has been tightened.

Adjustment Screw

38

THE PERFECT FIT

Handlebar Adjustments

Standard Handlebar

Follow these steps to adjust handlebar angle at the handlebar block.
1. Remove the handlebar cover

to expose the handlebar and

the four adjuster block bolts.

2. Using a 7/16-inch wrench,

loosen the four nuts on the

bottom of the adjuster block

(turn the handlebar either left

or right for access to the rear

nuts). If necessary, pry the

blocks apart with a screw-

driver.

3. Adjust the handlebar to the

desired angle. Be sure the

handlebar, brake lever and

throttle lever operate

smoothly and do not hit the

gas tank, windshield or any

other part of the machine

when the handlebar is turned

fully to the left or right.

4. Torque the front bolts first, then torque the rear bolts. Torque the

bolts to 11-13 ft. lbs. (15-18 Nm).

5. Reinstall the handlebar cover.

Cover

Nuts

Bolts

39

THE PERFECT FIT

Accessories

Polaris offers a wide range of accessories for your snowmobile. From

map light to electric start, Polaris has the accessories that will help make

each ride more enjoyable. See your dealer for a list of accessories.
Use only Polaris parts and accessories on your Polaris snowmobile. Use

of unapproved parts and accessories may result in:
• Non-compliance with government/industry requirements
• Voiding of warranty
• Personal injury to self or others
This applies to, but is not limited to the following areas: brakes,

clutches, fuel systems, and exhaust systems.

Tip: Exhaust systems are critical safety areas that must use approved Polaris

parts. Please see your Polaris dealer for service.

40

THE PERFECT FIT

Traction Products

Another way to tailor your machine is to install traction products. See

your dealer about installing studs and/or carbides. Many tracks with

deep lug designs cannot be studded, but your dealer will be able to offer

advice and assistance.

NOTICE: Installing studs on models without wear strips will result in damage to

the cooler or tunnel. Always ensure that wear strips are installed

before installing studs. See your dealer for more details.

Tip: Before equipping your machine with traction products, be aware of the laws

in your area pertaining to the use of traction products.

Track studding will enhance braking control on hard-packed snow or

ice, but extreme caution is still required on such surfaces. Steering abil-

ity may be reduced on hard-packed snow or ice.

WARNING! Loss of control can result in serious personal injury or death.

Proper balance of traction products on the skis and track must be maintained to

obtain proper vehicle control on hard-packed snow or ice. See your dealer for

assistance.
NOTICE: Use of studs longer than the recommended length on machines

equipped with coolers will result in damage to the cooler or tunnel.

Always use the recommended length studs.
