107

MAINTENANCE

Handlebar Adjustment

The handlebars can be adjusted for rider preference.

Improper adjustment of the handlebars or incorrect torquing of the adjuster

block tightening bolts can cause limited steering or loosening of the handlebars,

resulting in loss of control. Follow the adjustment procedures exactly, or see a

qualified service person for service. Your POLARIS dealer can assist.

1. Remove the upper headlight pod.
2. Loosen the four handlebar bolts.
3. Adjust the handlebar to the desired

height.

4. Be sure the handlebars do not

contact the gas tank or any other

part of the machine when turned

fully to the left or right.

5. Torque the front two bolts to 14-17

N-m, then torque the rear two

bolts. A gap of up to 3 mm will

remain at the rear of the clamp

blocks.

14-17 N-m

108

MAINTENANCE

Steering Assembly

Check the steering assembly of the vehicle

periodically for loose nuts and bolts. If

loose nuts and bolts are found, service is

required before operating the vehicle. Your

POLARIS dealer can assist.

Rear Spring

The rear shock absorber spring is adjusted

by rotating the adjuster either clockwise or

counter-clockwise to increase or decrease

spring tension.

Power Steering Unit

If your model is equipped with power

steering, frequently clean the areas around

and on the power steering unit to allow

proper cooling. Clean these areas

thoroughly.

Seat Removal

1. Grasp one side of the seat

near the rear edge.

2. Pull upward abruptly to

disengage the under-seat

fasteners.

3. Remove the seat.

High

Tension

Low

Tension

Cam

109

MAINTENANCE

Side Panel Removal

1. Remove the seat. See page

108.

2. Use a flat screwdriver to

remove the plastic rivets

securing the side panel.

3. Grasp the rear of the side

panel near the rear cab. With

a firm motion, pull the side

panel outward to disengage

the side panel from the

grommets.

4. Pull the panel outward and

rearward to remove it.

Step 2

Step 3

110

MAINTENANCE

Footwell Removal

1. Remove the screws on the bottom of the footwell.
2. Remove the screws securing the footwell to the rear fender.
3. Use a flat screwdriver to remove the plastic rivets securing the

footwell to the front fender.

4. Remove the footwell.

Torx Head Screws

Plastic Rivets

Torx Head Screws
