105

MAINTENANCE

Steering System

n

Ski Skags

WARNING! Worn skis and/or skags will adversely affect handling. Loss of

vehicle control may result, causing serious injury or death. See your dealer's

studding chart for recommended skags. If you install longer or more aggressive

carbide skags than the original equipment, it may also be necessary to add track

studs to maintain proper vehicle control while turning on hard-packed snow or

ice.

Check skags before each use of the snowmobile to ensure positive steer-

ing characteristics. Skags must be replaced when worn to half their orig-

inal diameter.

TIP: Carbide skags must be replaced if any abnormal wear or chipping is found.

Skag Replacement
Some models are equipped with single skags. Some models are

equipped with dual skags.
1. Raise and support the front of

the snowmobile so the skis are

approximately 6I (15.2 cm)

from the ground.

2. Remove the attaching nuts and

pry the skag downward.

3. Remove the front end of the

skag.

4. Remove the rear end of the

skag.

5. Reverse the steps to install a

skag.

Skag

106

MAINTENANCE

Steering System

n

Rail Slide Wear

Measure slide thickness at

several points along the rail.

Have your dealer replace the

slide when it's worn down to

the top of the wear limit

indicator groove (+). Do not

operate the snowmobile if

slide thickness measures less

than 7/16I (1.1 cm).

Rear Suspension

Inspect the rear suspension bushings at the intervals outlined in the Peri-

odic Maintenance Table beginning on page 73. Inspect more often if the

snowmobile is frequently operated in extreme conditions. Replace bush-

ings when they show evidence of wear.

7/16

I



(1.1 cm)

+

+

+

+

+

107

MAINTENANCE

Fall Tune-Up

For maximum performance, arrange for a fall service tune-up with your

Polaris dealer. His experienced and trained service technician will keep

your snowmobile in peak operating condition.

Matte Clear Coat Cleaning (if equipped)

Matte finish products are prone to trapping dirt, oils and other contami-

nants. Polaris Industries recommends cleaning with warm water and a

mild dish detergent. Use a soft sponge to gently rub the surface and rinse

with clean warm water. For stubborn stains such as grease or oil use a

citrus based cleaner (3M Citrus Base Cleaner recommended). Spray

onto the area to be cleaned and rub with a soft sponge. Allow to sit for a

couple of minutes and wash away with clean warm water. Repeat as

necessary to clean the surface.

NOTICE: Never use a polishing/buffing wax or any sponge that has an abrasive

surface. These products will buff the matte surface of the finish result-

ing in a glossy finish. It is not recommended that you clean matte fin-

ishes with a pressure washer as this will further imbed contaminants

into the clear coat and possibly damage the decals.

Extended Storage

Off-season or extended storage of your snowmobile requires preventive

measures to aid against deterioration and to prolong the useful life of

many components. See page 110 for the part numbers of Polaris prod-

ucts.

Cleaning and Preservation

Proper storage starts with cleaning, washing, and waxing the hood, side

panels, chassis, and plastic parts. Wipe down remaining surfaces with a

damp cloth. Clean and touch up with paint any rusted or previously

painted surfaces. Be sure that corrosive salt and acids are removed from

surfaces before beginning preservation with waxes and rust inhibitors

(grease, oil or paint).
The snowmobile should be stored in a dry garage or shed, out of direct

sunlight, and covered with a fabric snowmobile cover. Plastic tarp may

cause condensation to form and damage snowmobile components.

108

MAINTENANCE

Extended Storage

Controls and Linkage

Lubricate all bushings and cables as outlined in the Periodic Mainte-

nance Table beginning on page 74.

Clutch and Drive System

Remove the drive belt and store in a cool dry location. Do not lubricate

clutch components, except the driven clutch shaft bushing as outlined in

the Master Repair Manual. See your dealer.

Engine Protection

Proper preparation of the engine and fuel system is vital to the preven-

tion of rust and corrosion on precision engine parts during storage.

Whenever the snowmobile is stored for a period of more than 60 days,

the engine must be fogged with fogging oil. Follow the engine fogging

instructions provided on the container.
Always add Premium Carbon Clean or a fuel conditioner/stabilizer to

the fuel tank. Follow the instructions on the container, running the

engine for five minutes to get additives through the entire fuel system.

Top off with fresh fuel. Do not allow the snowmobile to run out of fuel.

Electrical Connections

Replace worn or frayed electrical wire and connectors. Be sure wiring

harness is properly secured away from sharp edges, steering linkage,

moving parts, and hot exhaust parts.

Track and Suspension

Moderate track tension should be maintained during summer storage.

The snowmobile should be supported off the ground to allow the track

to hang freely.
