FEATURES

Instrument Cluster

Indicators

Check Engine Indicator
This indicator appears if an EFI-related fault occurs. Do not operate the

snowmobile if this warning appears. Serious engine damage could

result. See your dealer. See page 36 for diagnostic code definitions.
Over-Temperature Indicator
This indicator illuminates to alert the operator that the engine is over-

heating. The operator should take action to cool the engine. See page 86.

If the indicator flashes, continued operation could result in serious

engine damage. Stop the engine immediately.
Low Oil Indicator
This indicator appears when engine oil is too low. Immediately stop the

engine. Add oil before operating. See page 65.
High Beam Indicator
The high beam indicator illuminates when the lights are set to high

beam.
Parking Brake Indicator
This indicator illuminates when the parking brake is engaged. It will

also illuminate when the service brake is in use. See page 56.
Reverse Indicator
This indicator flashes when the transmission is in reverse. See page 70.

FEATURES

Instrument Cluster

Rider Information Center

The rider information center is located in the instrument cluster. The

center displays vehicle speed, engine speed, odometer, resettable trip

meters (2), total engine hours of operation, fuel level, engine tempera-

ture and diagnostic display mode.
Setting changes can be made with the engine running or with the engine

off. If the engine is off, make sure the stop switch is pressed down, and

turn the ignition key to the START position briefly to activate the instru-

ment cluster. The instrument cluster will illuminate for about 90 sec-

onds.
The information center is set to display standard units of measurement

for distance and temperature. To change to metric units, see page 34.

FEATURES

Instrument Cluster

Rider Information Center

1. Information Display Area - This area displays either engine speed

or vehicle speed (whichever is not displayed in the speed display),

engine temperature and maximum vehicle speed. To change the dis-

play, see page 32.

2. Speed Display - The speed display area displays either vehicle

speed or engine speed. To change the display, see page 32.

3. Fuel Gauge - The segments of the fuel gauge show the level of fuel

in the fuel tank. When the last segment clears, a low fuel warning is

activated. All segments including the fuel icon will flash. Refuel

immediately.

Tip: If the fuel icon fails to display, an open or short circuit has occurred in the

fuel sensor circuit. See your dealer.

4. Odometer/Engine Hour Display - This area displays the odometer,

Trip A, Trip B and engine hours. To change the display, see page 33.

5. Battery Power - This indicator illuminates when battery power is

low.

6. Playback Icon - The playback function allows the rider to record

and play back engine speed, vehicle speed and throttle position sen-

sor information for up to three minutes. The playback icon flashes

while recording. See page 33.

FEATURES

Instrument Cluster

Rider Information Center

Speed Display Area
The speed display area displays either vehicle speed or engine speed.

Vehicle speed is displayed in either miles per hour (MPH) or kilometers

per hour (km/h). Engine speed is displayed in revolutions per minute

(RPM).
1. To change which item displays, first make sure the information dis-

play area is set to display either engine speed or vehicle speed.

2. Press and hold the mode button (on the instrument cluster) or the

mode switch (on the left handlebar) for three seconds.

Information Display Area
This area displays either engine speed or vehicle speed (whichever is

not displayed in the speed display), engine temperature and maximum

vehicle speed. To change the display, press and release the MODE but-

ton or the MODE switch until the desired item is displayed.
