105

MAINTENANCE

POLARIS Variable Transmission (PVT) System

PVT Drying

There may be some instances when water is accidently ingested into the
PVT system. Use the following instructions to dry it out before
operating.

NOTICE: When washing the vehicle, always avoid spraying water directly

toward the PVT intake duct. See page 124 for recommended
washing procedures.

1. Remove the drain plug from the bottom of the clutch box. Allow the

water to drain. Reinstall the drain plug securely.

2. Place the transmission in PARK. Apply the brakes. Start the engine.
3. Apply varying throttle for 10-15 seconds to expel the moisture and

air-dry the belt and clutches. Do not hold the throttle wide open for
more than 10 seconds.

4. Allow the engine RPM to settle to idle speed. Apply the brakes.

Shift the transmission to the lowest available range.

5. Test for belt slippage. If the belt slips, repeat the process.
6. Your vehicle requires service as soon as possible. Your POLARIS

dealer can assist.

106

MAINTENANCE

Air Filter

Always clean all dirt and debris
away from the air box area before
servicing the air filter. Always
change the air filter at the intervals
outlined in the Periodic Maintenance
Chart beginning on page 83.

1. Remove the rear access panel in

the cargo box.

2. Clean all dirt and debris from

the air box area.

3. Loosen the hose clamp and

remove the intake hose from the
air box cover before unlatching
the cover clips.

4. Unlatch the cover clips and

carefully remove the air box
cover. Do not allow the air box
cover to contact the air filter
during removal.

NOTICE: Dirt or debris in the air box

could result in severe engine
damage. Always clean all dirt
and debris from the air box
before installing the filter.

5. Inspect the air box for dirt,

debris, oil or water. Clean the
air box thoroughly and wipe it
well with a clean, dry cloth.

Hose Clamp

Cover Clips (6)

Air Filter

107

MAINTENANCE

Air Filter

6. Install a new filter if needed. Do not attempt to clean the air filter.

Install the air filter with the pleats facing upward.

7. Reinstall the air box cover and secure the cover clips. Do not allow

the air box cover to contact the air filter during installation.

8. Reinstall the intake hose and tighten the clamp securely.

9. Reinstall the access panel.

Intake Pre-Filters

The engine and PVT intake pre-filters
are located on the left side of the cargo
box. Inspect both pre-filters before
each use of the vehicle to ensure
adequate air flow. If necessary, remove
the pre-filters and clean with soapy
water. Dry with low pressure
compressed air.

NOTICE: When washing the vehicle,

always avoid spraying water
directly toward the PVT intake
duct. See page 124 for
recommended washing
procedures.

Engine Intake Pre-Filter

PVT Intake Pre-Filter

108

MAINTENANCE

Spark Arrester

Failure to heed the following warnings while servicing the spark arrester could
result in serious injury or death.

• Do not perform clean-out immediately after the engine has been run, as the

exhaust system becomes very hot. Serious burns could result from contact
with the exhaust components. Allow components to cool sufficiently before
proceeding.

• Wear eye protection and gloves.

• Never operate without the spark arrester.

• Never run the engine in an enclosed area. Exhaust contains poisonous carbon

monoxide gas that can cause loss of consciousness or death in a very short
time.

Periodically clean the spark arrester to remove accumulated carbon.
1. Remove the retaining nut. Remove the arrester from the end of the

muffler.

2. Use a non-synthetic brush to clean the arrester screen. A synthetic

brush may melt if components are warm. If necessary, blow debris
from the screen with compressed air.

3. Inspect the screen for wear and damage. Replace a worn or

damaged screen.

4. Reinstall the arrester. Torque the nut to 7-9 ft. lbs. (10-12 Nm).

WARNING

Arrester

Retaining

Nut

Screen

Muffler
