Polaris ACE 150 EFI (2018 year). Manual - part 6

28

FEATURES AND CONTROLS

Component Locations

Running

Lights

Brush Guard

Steering

Wheel

Cab

Frame

Muffler

(Spark Arrester)

29

FEATURES AND CONTROLS

Seats

Driver’s Seat Adjustment

1. Lift the seat latch lever located under

the right front edge of the driver’s

seat.

2. While holding the lever upward, slide

the seat forward or rearward to the

desired position, then release the

lever.

3. Slide the seat forward and rearward

to ensure the latch is engaged. Before

operating the vehicle, always make

sure the seat is securely installed.

Seat Removal

1. To remove the driver’s seat, lift the

seat latch lever.

2. While holding the lever upward,

slide the seat completely forward,

remove 10mm bolts, and remove

seat from the seat mounting rails.

3. Before operating the vehicle,

always make sure the driver’s seat

is installed and securely latched.

Seat Latch Lever

Slide Seat Forward

30

FEATURES AND CONTROLS

Steering Wheel

The steering wheel can be adjusted

upward or downward for rider

preference.
1. Loosen and remove the steering

wheel adjustment bolt.

2. Move steering wheel upward or

downward to the desired position

by aligning the mounting holes.

3. Tighten bolt to 13.5 Nm (10 ft-

lbs).

CAUTION! Ensure bolt is fully tightened

prior to operating the vehicle.

Adjustment Bolt

31

FEATURES AND CONTROLS

Seat Belts

This POLARIS vehicle is equipped with three-point lap and diagonal

seat belt for the operator. Always make sure the seat belt are secured

for the operator before riding.
To wear the seat belt properly, follow this

procedure:
1. Pull the seat belt latch downward and

across your chest toward the buckle at

the inner edge of the seat. The belt

should fit snugly across your hips and

diagonally across your chest. Make

sure the belt is not twisted.

Tip: The position of the shoulder strap can be

adjusted to the height of the operator.

Have an adult relocate the mounting bolt

to a different position, making sure the nut

and bolt are tightened securely. Nut and

bolt should be tightened to 40.6 Nm (30 ft-

lbs).

2. Push the latch plate into the buckle

until it clicks.

3. Release the strap, it will self-tighten.
4. Press the red release latch on the

buckle to release the seat belt.

Seat Belt

Latch

Seat Belt

Buckle

Nut and

Bolt
