Snowmobile Polaris 600 RMK, 600 SwitchBack (2006 year). Manual - part 6

FEATURES

1. Hood

2. Headlight

3. Windshield

4. Handlebar

5. Side Shield

6. Seat

7. Storage Compartment

8. Taillights

9. Rear Bumper

10. Snow Flap

11. Suspension

12. Track

13. Nosepan

14. Front Bumper

15. Ski

1. Fuel Filler Cap

2. Rider Selectt

3. Ignition Switch

4. Handlebar hook

5. Brake Lever

6. Mountain Bar

7. MFD (Multi-Function Display)

8. Engine Stop Switch

9. Choke

10. Throttle Control

11. Recoil Starter Handle

12. Hood Hold Down Straps

13. Headlight Dimmer Switch

14. Parking Brake

15. Handlebar Grip Warmer Switch

16. Thumbwarmer Switch

17. Electronic Reverse Button

18. MFD Control

14 15 16 17

FEATURES

RIDER SELECT Adjustable Steering System

The RIDER SELECT adjustable steering system allows you to adjust

the handlebar position to fit your style of riding.

Choosing the Best RIDER SELECTt Position

Position

Riding Style

1
2
3

Relaxed Trail Riding
Rider weight is slightly behind the center

of the snowmobile for comfortable and re-

laxed riding.

4
5

General Trail Riding, Boondocking,

Deep Snow Riding
Rider weight is centered on the snowmo-

bile, providing balance, comfort and con-

trol for both novice and experienced rid-

ers. This is the recommended position for

most riding situations.

6
7

Snowcross & Steep Hill Climbing

Only
Rider weight is slightly ahead of the center

of the snowmobile, adding weight to the

skis and making the snowmobile feel

heavier at the front. These positions are

desirable for hill climbing and may reduce

maneuverability for other types of riding.

FEATURES

RIDER SELECT Adjustable Steering System

WARNING

Attempting to adjust the handlebar position while the snowmobile

is moving could result in loss of control and serious injury or

death. Always stop the snowmobile before attempting to adjust

the steering system.

1. Stop the snowmobile.
2. Press the release button and move

the handlebar forward or rearward

to the desired position.

WARNING

Do not lubricate the RIDER

SELECT mechanism. Doing so

could cause loss of control and result in serious injury or death.

The RIDER SELECT mechanism is lubricated for life at the

factory.

WARNING

Some aftermarket accessories (including windshields and cargo

bags) may interfere with the handlebar. Such accessories could

limit your ability to steer the vehicle and/or may contact the brake

lever. This could lead to loss of control resulting in serious injury

or death. Always be sure that accessories do not contact the

handlebar or brake lever at any steering position and at any

RIDER SELECT position.

Adjustable Headlights

Adjust the headlight beam by

moving the adjuster to the left

or right.

FEATURES

Fuel Valve

The fuel valve is located under the

hood. Turn the fuel valve off whenever

the snowmobile is stored or parked.
1. Turn the valve clockwise to turn

off the fuel supply.

2. Turn the valve counter-clockwise

to turn on the fuel supply.

Seat Storage

Compartment

Lift the seat lever (+) and lift the

seat to access the under-seat storage

area.

Radiator Compartment

Access Panel

The access panel (+) is provided

for cleaning debris from the

radiator.

Cargo Rack

The maximum weight capacity for

the cargo rack (+) is 15 lbs. (7 kg).

Always secure cargo before

operating. Do not exceed the rack

weight limit. Do not allow a

passenger to sit on the seat back or

the cargo rack.
