Index Snowmobiles / ATV Snowmobile Polaris 600 RMK F/O, 700 RMK F/O, 800 RMK F/O - service manual 2004 year
|
|
A13 CONSOLE 600 RMK 144 F/O S04NK6ES and 600 RMK 144 STOCK A S04NK6ESA and 600 RMK 144 STOCK B S04NK6ESB and 600 RMK 144 STOCK C S04NK6ESC and 700 RMK 144 F/O S04NK7CS and 700 RMK 144 STOCK A S04NK7CSA and 700 RMK 144 STOCK B S04NK7CSB and 700 RMK 144 STOCK C S04NK7CSC and 700 RMK 151 F/O S04NL7CS and 700 RMK 151 STOCK A S04NL7CSA and 700 RMK 151 STOCK B S04NL7CSB and 700 RMK 151 STOCK C S04NL7CSC and 800 RMK 144 F/O S04NK8CS and 800 RMK 144 STOCK A S04NK8CSA and 800 RMK 144 STOCK B S04NK8CSB and 800 RMK 144 STOCK C S04NK8CSC and 800 RMK 151 F/O S04NL8CS and 800 RMK 151 STOCK A S04NL8CSA and 800 RMK 151 STOCK B S04NL8CSB and 800 RMK 151 STOCK C S04NL8CSC and 800 RMK 159 F/O S08NM8CS and 800 RMK 159 STOCK A S08NM8CSA and 800 RMK 159 STOCK B S08NM8CSB and 800 RMK 159 STOCK C S08NM8CSC 6 9 10 14 15 13 18 19 17 8 3 1 4 12 5 11 2 16 11 7 7 20 E 2003 Polaris Sales Inc. Part numbers may have changed since this microfiche was issued. To ensure that correct parts are received, refer to PartSmart, which is updated monthly. Ref. Part No. Qty. Description Ref. Part No. Qty. Description 1 7541925 2 Nut, Nylok 2 7555746 2 Washer 3 4010793 4010794 1 1 Regulator, AC 14.3V (Manual Start) Regulator, AC/DC 14.3V (Electric Start) 4 7512031 7517263 2 2 Screw (Manual Start) Screw (Electric Start) 5 4010192 7 Socket 6 4010193 2 Housing, Connector 7 4020153 1 Housing 1 Circuit 8 4020063 1 Housing 9 2461146 1 Harness, Main Wire, ER, FS 10 4020057 1 Housing 11 7515199 2 Screw 12 5434134 1 Console 13 5410611 1 Cap w/Key NOTE: When ordering igni- tion key PN 5410611 be sure to specify if for an A,B,C,D, or E switch. Letter code will be labeled on underside of switch body behind console. Key dot code found on key cap (i.e. one dot = A, two dots= B, etc.). 14 7547035 1 Nut, Ignition 15 2201614 1 Kit, Ignition Switch 16 7670088 2 Clip,Plastic, Dart, Nylon 17 2201439 1 Lever, Choke (Incl. Pin) 18 5432944 1 Nut, Choke, w/Notch 19 7080946 1 Cable, Choke, Rack (Incl. 17,18) 20 5812441 1 Collar, Foam, RMK (Vert. Esc.) 3/03 |
