Safety

FIG. 44:

1. Caution - No clearance for person in the working

area of the machine.

FIG. 45:

2. Warning - External hydraulic system filled with ISO

VG 46.

FIG. 46:

3. Caution - Do not work under the cab, when the

Safety pin is not mounted.

FIG. 44

Q000115S

FIG. 45

P625052-A

FIG. 46

Q000116S

Safety

1-26

627333-A

FIG. 47:

4. Danger - No clearance for person in this area when

turning vehicle. Keep distance/pinching hazard.

FIG. 48:

5. Warning - Tipping over order cabin.

i.

Open engine hood;

ii.

Dismount side panels engine hood;

iii. Check if there are no loose parts in the cab,

and everything is ready to tip over the cab;

iv. Dismount safety pin;

v.

Tip over cab;

vi. Mount safety pin.

FIG. 47

Q000117S

FIG. 48

Q625171-B

627333-A

1-27

Safety

FIG. 49:

6. Read and understand the operators manual. This

decal is in a vertical and in a horizontal position

available.

FIG. 50:

7. Warning - Beware of leaking hydraulic lines/hoses.

FIG. 51:

8. Secondary Fresh Air Filter.

FIG. 49

Q000118S

FIG. 50

Q000119S

FIG. 51

Q000134S

Safety

1-28

627333-A

FIG. 52:

9. Primary Fresh Air Filter.

FIG. 53:

10. Warning - Radar Hazard, do not look into the radar.

FIG. 52

Q000133S

FIG. 53

Q000120S
