HUAWEI OptiX OSN 8800 T64/T32 Intelligent Optical Transport Platform. Product Description - part 61
Mechanical Specifications
l Dimensions of front panel: 50.8 mm (W) x 220 mm (D) x 264.6 mm (H) (2.0 in. (W) x 8.7
in. (D) x 10.4 in. (H))
l Weight:
l TN11OBU2: 1.9 kg (4.2 lb.)
l TN12OBU2: 1.6 kg (3.5 lb.)
Power Consumption
Board
Typical Power
Maximum Power
Consumption at 25°C (77°
Consumption at 55°C
F) (W)
(131°F) (W)
TN11OBU205
17
24
TN12OBU205
14
19
9.12 System Control, Supervision and Communication
Board Specifications
9.12.1 SCC Specifications
Specifications include dimensions, weight, and power consumption.
Mechanical Specifications
Dimensions of front panel:
l TN11SCC: 25.4 mm (W) x 220 mm (D) x 264.6 mm (H) or 1.0 in. (W) x 8.7 in. (D) x 10.4
in. (H)
l TN16SCC: 54.5 mm (W) x 220 mm x (D) 350.3 mm (H) or 2.1 in. (W) x 8.7 in. (D) x 13.8
in. (H)
l TN21SCC: 25.4 mm (W) x 220 mm (D) x 118.9 mm (H) or 1.0 in. (W) x 8.7 in. (D) x 4.7
in. (H)
l TN22SCC: 25.4 mm (W) x 220 mm (D) ox 118.9 mm (H) or 1.0 in. (W) x 8.7 in. (D) x 4.7
in. (H)
l TN51SCC: 25.4 mm (W) x 220 mm (D) x 264.6 mm (H) or 1.0 in. (W) x 8.7 in. (D) x 10.4
in. (H)
l TN52SCC: 25.4 mm (W) x 220 mm (D) x 264.6 mm (H) or 1.0 in. (W) x 8.7 in. (D) x 10.4
in. (H)
l TNK2SCC: 76.2 mm (W) x 220 mm (D) x 110.0 mm (H) or 3.0 in. (W) x 8.7 in. (D) x 4.4
in. (H)
Weight:
l TN11SCC: 1.2 kg (2.6 lb.)
653
l TN16SCC: 1.3 kg (2.8 lb.)
l TN21SCC: 0.5 kg (1.1 lb.)
l TN22SCC: 0.5 kg (1.1 lb.)
l TN51SCC: 1.2 kg (2.6 lb.)
l TN52SCC: 1.0 kg (2.2 lb.)
l TNK2SCC: 0.9 kg (2.0 lb.)
Power Consumption
Board
Typical Power
Maximum Power
Consumption at 25°C (77°
Consumption at 55°C
F) (W)
(131°F) (W)
TN16SCC
32.0
35.0
TN51SCC
18.0
20.0
TN52SCC
23.0
25.1
TNK2SCC
26.7
29.3
9.12.2 AUX Specifications
Specifications include dimensions, weight, and power consumption.
Mechanical Specifications
l Dimensions of the front panel:
- TN51AUX: 25.4 mm (W) x 220 mm (D) x 107.5 mm (H) (1.0 in. (W) x 8.7 in. (D) x
4.2 in. (H))
- TN16AUX: 76.2 mm (W) x 220 mm (D) x 80 mm (H) (3.0 in. (W) x 8.7 in. (D) x 3.1
in. (H))
- TN11AUX: 25.4 mm (W) x 220 mm (D) x 107.6 mm (H) (1.0 in. (W) x 8.7 in. (D) x
4.2 in. (H))
- TN21AUX: 25.4 mm (W) x 220 mm (D) x 118.9 mm (H) (1.0 in. (W) x 8.7 in. (D) x
4.7 in. (H))
- TN22AUX: 25.4 mm (W) x 220 mm (D) x 118.9 mm (H) (1.0 in. (W) x 8.7 in. (D) x
4.7 in. (H))
l Weight:
- TN51AUX: 0.45 kg (0.99 lb.)
- TN16AUX: 0.6 kg (1.32 lb.)
- TN11AUX: 0.5 kg (1.1 lb.)
- TN21AUX: 0.6 kg (1.32 lb.)
- TN22AUX: 0.5 kg (1.1 lb.)
654
Power Consumption
Board
Typical Power
Maximum Power
Consumption at 25°C (77°
Consumption at 55°C
F) (W)
(131°F) (W)
TN51AUX
17.5
19.0
TN16AUX
16.5
19.2
TN11AUX
12.0
17.0
TN21AUX
11.7
13.0
TN22AUX
15.0
17.0
9.13 Optical Supervisory Channel Unit Specifications
9.13.1 HSC1 Specifications
Specifications include optical specifications, dimensions, weight, and power consumption.
NOTE
A margin of the lower threshold of input optical power compared with the receiver sensitivity of the board
and a margin of the upper threshold of output optical power compared with the overload point of the board
are reserved on the U2000 as a precaution.
Optical Specifications
Table 9-221 lists the optical specifications of the HSC1 board.
Table 9-221 Optical specifications of the HSC1 board
Item
Unit
Value
Signal rate
Mbit/s
4.096
Operating wavelength range
nm
1500 to 1520
Signal coding
-
CMI
Launched optical power
dBm
5 to 10
Receiver sensitivity
dBm
≤ -48
Receiver overload
dBm
-3
Mechanical Specifications
l Dimensions of front panel: 25.4 mm (W) x 220 mm (D) x 264.6 mm (H) (1.0 in. (W) x 8.7
in. (D) x 10.4 in. (H))
655
l Weight: 1.0 kg (2.2 lb.)
Power Consumption
Board
Typical Power
Maximum Power
Consumption at 25°C (77°
Consumption at 55°C
F) (W)
(131°F) (W)
HSC1
8.0
8.8
9.13.2 SC1 Specifications
Specifications include optical specifications, dimensions, weight, and power consumption.
Optical Specifications
Table 9-222 lists the optical specifications of the SC1 board.
Table 9-222 Optical specifications of the SC1 board
Item
Unit
Value
Signal ratea
Mbit/s
16.896
4.096
Operating wavelength range
nm
1500 to 1520
Signal coding
-
CMI
Launched optical power
dBm
-4 to 0
Receiver sensitivity
dBm
≤ -46
≤ -48
Receiver overload
dBm
-3
a: The SC1 board at the receive end can automatically determines the signal rate of the OSC
channel based on the OSC board configured at the transmit end. By default, the signal rate of
the OSC channel is 16 Mbit/s.
Mechanical Specifications
l Dimensions of front panel: 25.4 mm (W) x 220 mm (D) x 264.6 mm (H) (1.0 in. (W) x 8.7
in. (D) x 10.4 in. (H))
l Weight: 1.0 kg (2.2 lb.)
656
Power Consumption
Board
Typical Power
Maximum Power
Consumption at 25°C (77°
Consumption at 55°C
F) (W)
(131°F) (W)
SC1
11.0
14.9
9.13.3 ST2 Specifications
Specifications include optical specifications, dimensions, weight, and power consumption.
Optical Specifications
Table 9-223 lists the optical specifications of the ST2.
Table 9-223 Optical specifications of the ST2 board
Item
Unit
Value
Signal rate
Mbit/s
155.52
Operating wavelength range
nm
1504.5 to 1517.5
1484.5 to 1497.5
Launched optical power
dBm
0.5 to 5
Receiver sensitivity
dBm
≤ -41
Receiver overload
dBm
-10
Mechanical Specifications
l Dimensions of front panel: 25.4 mm (W) x 220 mm (D) x 264.6 mm (H) (1.0 in. (W) x 8.7
in. (D) x 10.4 in. (H))
l Weight: 0.95 kg (2.09 lb.)
Power Consumption
Board
Typical Power
Maximum Power
Consumption at 25°C (77°
Consumption at 55°C
F) (W)
(131°F) (W)
ST2
17.5
19.5
9.13.4 SC2 Specifications
Specifications include optical specifications, dimensions, weight, and power consumption.
657
Optical Specifications
Table 9-224 lists the optical specifications of the SC2.
Table 9-224 Optical specifications of the SC2 board
Item
Unit
Value
Signal ratea
Mbit/s
16.896
4.096
Operating wavelength range
nm
1500 to 1520
Signal coding
-
CMI
Launched optical power
dBm
-4 to 0
Receiver sensitivity
dBm
≤ -46
≤ -48
Receiver overload
dBm
-3
a: The SC2 board at the receive end can automatically determines the signal rate of the OSC
channel based on the OSC board configured at the transmit end. By default, the signal rate of
the OSC channel is 16 Mbit/s.
Mechanical Specifications
l Dimensions of front panel: 25.4 mm (W) x 220 mm (D) x 264.6 mm (H) (1.0 in. (W) x 8.7
in. (D) x 10.4 in. (H))
l Weight: 1.0 kg (2.2 lb.)
Power Consumption
Board
Typical Power
Maximum Power
Consumption at 25°C (77°
Consumption at 55°C
F) (W)
(131°F) (W)
SC2
13.5
14.5
9.14 Clock Unit Specifications
9.14.1 STG Specifications
Specifications include dimensions, weight, and power consumption.
Mechanical Specifications
l Dimensions of the front panel:
- TNK2STG: 50.3mm (W) x 220 mm (D) x 107.5 mm (H) (2.0 in. (W) x 8.7 in. (D) x 4.2
in. (H))
658
- TN52STG: 28.8 mm (W) x 220 mm (D) x 107.5 mm (H) (1.1 in. (W) x 8.7 in. (D) x
4.2 in. (H))
- TN11STG: 25.4 mm (W) x 220 mm (D) x 264.6 mm (H) (1.0 in. (W) x 8.7 in. (D) x
10.4 in. (H))
l Weight:
- TN52STG/TNK2STG: 0.5 kg (1.1 lb.)
- TN11STG: 1.1 kg (2.4 lb.)
Power Consumption
Board
Typical Power
Maximum Power
Consumption at 25°C (77°
Consumption at 55°C
F) (W)
(131°F) (W)
TNK2STG
14.0
16.0
TN52STG
13.0
14.1
TN11STG
8.7
9.57
9.15 Optical Protection Unit Specifications
9.15.1 DCP Specifications
Specifications include optical specifications, dimensions, weight, and power consumption.
Optical Specifications
Table 9-225 Optical specifications of the DCP on the OptiX OSN 8800
Interface
Item
Unit
Value
TN11DCPa
TN12DCPb
TI1-TO11
Insertion loss
Single-mode
dB
-
≤4
at the
TI1-TO12
multimode
dB
≤4.5
-
transmit end
TI2-TO21
TI2-TO22
RI11-RO1
Insertion loss
Single-mode
dB
-
≤1.5
at the receive
RI12-RO1
Multi-mode
dB
≤2
-
end
RI21-RO2
RI22-RO2
Range of the input optical
Single-mode
dBm-
-
-35 to 7
power
Multi-mode
dBm
-35 to 0
-
659
Interface
Item
Unit
Value
TN11DCPa
TN12DCPb
Operating wavelength range
Single-mode
nm
-
1270 to
1350,
1528 to 1567
Multi-mode
nm
830 to 870
-
Switching threshold of optical power
dB
5
5
difference
Range of the alarm threshold for the optical
dB
3 to 8
3 to 8
power difference
a: TN11DCP has no single-mode optical module.
b: TN12DCP has no multi-mode optical module.
Table 9-226 Optical specifications of the DCP board on the OptiX OSN 6800 and OptiX OSN
3800
Interface
Item
Unit
Value
TN11DCP
TN12DCPa
TI1-TO11
Insertion loss
Single-mode
dB
≤4
≤4
at the
TI1-TO12
Multi-mode
dB
≤4.5
-
transmit end
TI2-TO21
TI2-TO22
RI11-RO1
Insertion loss
Single-mode
dB
≤1.5
≤1.5
at the receive
RI12-RO1
Multi-mode
dB
≤2
-
end
RI21-RO2
RI22-RO2
Range of the input optical
Single-mode
dBm
-35 to 7
-35 to 7
power
Multi-mode
dBm
-35 to 0
-
Operating wavelength range
Single-mode
nm
1270 to
1270 to
1350,
1350,
1528 to 1567
1528 to 1567
Multi-mode
nm
830 to 870
-
Switching threshold of optical power
dB
5
5
difference
Range of the alarm threshold for the optical
dB
3 to 8
3 to 8
power difference
a: TN12DCP board has no multi-mode optical module.
660
Mechanical Specifications
l Dimensions of front panel: 25.4 mm (W) x 220 mm (D) x 264.6 mm (H) (1.0 in. (W) x 8.7
in. (D) x 10.4 in. (H))
l Weight: 1.0 kg (2.2 lb.)
Power Consumption
Board
Typical Power
Maximum Power
Consumption at 25°C (77°
Consumption at 55°C
F) (W)
(131°F) (W)
DCP
6.8
7.5
9.15.2 OLP Specifications
Specifications include optical specifications, dimensions, weight, and power consumption.
Optical Specifications
Table 9-227 Optical specifications of the OLP board on the OptiX OSN 8800
Interfa
Item
Unit
Value
ce
TN11OLPa
TN12OLP01b
TN12OLP03b
TI-TO1
Insertio
single
dB
-
≤4
≤4
n loss at
mode
TI-TO2
the
multimo
dB
≤4.5
-
-
transmit
de
end
RI1-RO
Insertio
single
dB
-
≤1.5
≤1.5
n loss at
mode
RI2-RO
the
multimo
dB
≤2
-
-
receive
de
end
Range of the input
single
dBm
-
-35 to 7
-30 to 23
optical power
mode
multimo
dBm
-35 to 0
-
-
de
Operating
single
nm
-
1270 to 1350,
1270 to 1350,
wavelength range
mode
1528 to 1567
1528 to 1567
multimo
nm
830 to 870
-
-
de
Switching threshold of optical
dB
5
5
5
power difference
661
Interfa
Item
Unit
Value
ce
TN11OLPa
TN12OLP01b
TN12OLP03b
Range of the alarm threshold
dB
3 to 8
3 to 8
3 to 8
for the optical power difference
a: TN11OLP has no single mode optical module.
b: TN12OLP has no multimode optical module.
Table 9-228 Optical specifications of the OLP board on the OptiX OSN 6800 and OptiX OSN
3800
Interfa
Item
Unit
Value
ce
TN11OLP
TN12OLP01a
TN12OLP03a
TI-TO1
Insertio
single
dB
≤4
≤4
≤4
n loss at
mode
TI-TO2
the
multimo
dB
≤4.5
-
-
transmit
de
end
RI1-RO
Insertio
single
dB
≤1.5
≤1.5
≤1.5
n loss at
mode
RI2-RO
the
multimo
dB
≤2
-
-
receive
de
end
Range of the input
single
dBm
-35 to 7
-35 to 7
-30 to 23
optical power
mode
multimo
dBm
-35 to 0
-
-
de
Operating
single
nm
1270 to
1270 to 1350,
1270 to 1350,
wavelength range
mode
1350,
1528 to 1567
1528 to 1567
1528 to 1567
multimo
nm
830 to 870
-
-
de
Switching threshold of optical
dB
5
5
5
power difference
Range of the alarm threshold
dB
3 to 8
3 to 8
3 to 8
for the optical power difference
a: TN12OLP has no multimode optical module.
662
Mechanical Specifications
l Dimensions of front panel: 25.4 mm (W) x 220 mm (D) x 264.6 mm (H) (1.0 in. (W) x 8.7
in. (D) x 10.4 in. (H))
Weight
l TN11OLP: 0.9 kg (1.98 lb.)
l TN12OLP: 1.0 kg (2.20 lb.)
Power Consumption
Board
Typical Power
Maximum Power
Consumption at 25°C (77°
Consumption at 55°C
F) (W)
(131°F) (W)
TN11OLP
6.0
6.6
TN12OLP
4.0
4.5
9.15.3 SCS Specifications
Specifications include optical specifications, dimensions, weight, and power consumption.
Optical Specifications
Table 9-229 lists the optical specifications of the SCS board.
Table 9-229 Optical specifications of the SCS board
Interface
Item
Unit
Value
TI1-TO11
Splitting
Single-mode
dB
≤4
insertion loss
TI1-TO12
Multi-mode
dB
≤4.5
TI2-TO21
TI2-TO22
RI11-RO1
Coupling
Single-mode
dB
≤4
insertion loss
RI12-RO1
Multi-mode
dB
≤4.5
RI21-RO2
RI22-RO2
Operating wavelength range
Single-mode
nm
1270 to 1350, 1528 to
1567
Multi-mode
nm
830 to 870
663
