HUAWEI OptiX OSN 8800 T64/T32 Intelligent Optical Transport Platform. Product Description - part 53
TN52TOM: 1.5 kg (3.3 lb.)
Power Consumption
Board
Typical Power
Maximum Power
Consumption at 25°C (77°
Consumption at 55°C
F) (W)
(131°F) (W)
TN11TOM
55
60
TN52TOM
81
89.1
9.4.9 THA Specifications
Specifications include optical specifications, dimensions, weight, and power consumption.
Board
Client-Side Fixed
Client-Side Pluggable Optical Module
Optical Module
TN54TH
N/A
S-16.1-15 km
A
1000 BASE-LX-10 km (I-1310-LC)
NOTE
There is a margin between the default input power low alarm threshold and the receiver sensitivity and a
margin between the default input power high alarm threshold and the overload point. This ensures that the
system can report an input power low alarm before the actual input power reaches the receiver sensitivity
or report an input power high alarm before the actual input power reaches the overload point.
Client-Side Pluggable Optical Module
NOTE
S-16.1 module can be used to access OTU1, STM-16, OC-48, FC200, FC100, GE, STM-4, OC-12, ESCON,
STM-1, OC-3, DVB-ASI, and FE signals.
Table 9-150 Specifications of client-side pluggable optical module for SDH services
Item
Unit
Value
Optical Module Type
S-16.1
-15 km
Line code format
-
NRZ
Target distance
-
15 km (9.3 mi.)
Transmitter parameter specifications at point S
Operating wavelength range
nm
1260 to 1360
Maximum mean launched
dBm
0
power
565
Item
Unit
Value
Optical Module Type
S-16.1
-15 km
Minimum mean launched
dBm
-5
power
Minimum extinction ratio
dB
8.2
Maximum -20 dB spectral
nm
1
width
Minimum side mode
dB
30
suppression ratio
Eye pattern mask
-
G.959.1-compliant
Receiver parameter specifications at point R
Receiver type
-
PIN
Operating wavelength range
nm
1270 to 1580
Receiver sensitivity
dBm
-18
Minimum receiver overload
dBm
0
Maximum reflectance
dB
-27
NOTE
1000 BASE-LX-10 km module can be used to access GE, FC100, STM-4, ESCON, STM-1, FE and DVB-ASI
signals. The specifications listed below apply to GE signals. The actual values might be slightly different from
these specifications when the accessed signals are FC100, STM-4, ESCON, STM-1, FE, or DVB-ASI signals.
Table 9-151 Specifications of client-side pluggable optical module for GE services
Item
Unit
Value
Optical Module Type
1000 BASE-LX-10 km
(I-1310-LC)
Line code format
-
NRZ
Optical source type
-
SLM
Target distance
-
10 km (6.2 mi.)
Transmitter parameter specifications at point S
Operating wavelength range
nm
1270 to 1355
Maximum mean launched
dBm
-3
power
566
Item
Unit
Value
Optical Module Type
1000 BASE-LX-10 km
(I-1310-LC)
Minimum mean launched
dBm
-9.5
power
Minimum extinction ratio
dB
9
Eye pattern mask
-
IEEE802.3z -compliant
Receiver parameter specifications at point R
Receiver type
-
PIN
Operating wavelength range
nm
1260 to 1620
Receiver sensitivity
dBm
-20
Minimum receiver overload
dBm
-3
Mechanical Specifications
l Dimensions of front panel: 25.4 mm (W) x 220 mm (D) x 264.6 mm (H) (1.0 in. (W) x 8.7
in. (D) x 10.4 in. (H))
l Weight: 1.5 kg (3.2 lb.)
Power Consumption
Board
Typical Power
Maximum Power
Consumption at 25°C (77°
Consumption at 55°C
F) (W)
(131°F) (W)
TN54THA
35
40
9.4.10 TQX Specifications
Specifications include optical specifications, dimensions, weight, and power consumption.
Board
Client-Side Fixed
Client-Side Pluggable Optical Module
Optical Module
TN11TQ
N/A
10 Gbit/s Multirate-10 km
X
10 Gbit/s Multirate-40 km
10 Gbit/s Multirate-80 km
10 Gbit/s Single Rate-0.3 km
567
Board
Client-Side Fixed
Client-Side Pluggable Optical Module
Optical Module
TN52TQ
N/A
10 Gbit/s Multirate-10 km
X
10 Gbit/s Multirate-40 km
10 Gbit/s Multirate-80 km
10 Gbit/s Single Rate-0.3 km
TN53TQ
N/A
10 Gbit/s Multirate-10 km
X
10 Gbit/s Multirate-40 km
10 Gbit/s Multirate-80 km
10 Gbit/s Single Rate-0.3 km
TN55TQ
N/A
10 Gbit/s Multirate-10 km
X
10 Gbit/s Multirate-40 km
10 Gbit/s Multirate-80 km
10 Gbit/s Single Rate-0.3 km
NOTE
For information about the boards supported by the equipment, see Mappings Between the Board and Equipment
in the Hardware Description.
NOTE
There is a margin between the default input power low alarm threshold and the receiver sensitivity and a
margin between the default input power high alarm threshold and the overload point. This ensures that the
system can report an input power low alarm before the actual input power reaches the receiver sensitivity
or report an input power high alarm before the actual input power reaches the overload point.
NOTE
The 10 Gbit/s multirate 10 km module, 10 Gbit/s multirate 40 km module, and 10 Gbit/s multirate 80 km module
can be used to access OC-192, STM-64, 10GE WAN, FC1200, and OTU2/OTU2e signals.
The 10 Gbit/s single-rate 0.3 km module can be used to access 10GE LAN and FC1200 signals.
The 10 Gbit/s multirate 10 km module can be used to access FC800 signals.
Client-Side Pluggable Optical Module
Table 9-152 Specifications of client-side pluggable optical module for 10 Gbit/s rate services
Item
Unit
Value
Optical
10 Gbit/s
10 Gbit/s
10 Gbit/s
10 Gbit/s
Module
Multirate-10
Multirate-40
Multirate-80
Single
Type
km
km
km
Rate-0.3 km
Line code
-
NRZ
NRZ
NRZ
NRZ
format
Optical
-
SLM
SLM
SLM
MLM
source type
568
Item
Unit
Value
Optical
10 Gbit/s
10 Gbit/s
10 Gbit/s
10 Gbit/s
Module
Multirate-10
Multirate-40
Multirate-80
Single
Type
km
km
km
Rate-0.3 km
Target
-
10 km (6.2 mi.)
40 km (24.9
80 km (49.7
0.3 km (0.2
distance
mi.)
mi.)
mi.)
Transmitter parameter specifications at point S
Operating
nm
1290 to 1330
1530 to 1565
1530 to 1565
840 to 860
wavelength
range
Maximum
dBm
-1
2
4
-1.3
mean
launched
power
Minimum
dBm
-6
-4.7
0
-7.3
mean
launched
power
Minimum
dB
6
8.2
9
3
extinction
ratio
Maximum
nm
N/A
N/A
N/A
N/A
-20 dB
spectral
width
Minimum
dB
30
30
30
30
side mode
suppression
ratio
Eye pattern
-
G.691-compliant
mask
Receiver parameter specifications at point R
Receiver
-
PIN
PIN
APD
PIN
type
Operating
nm
1260 to 1565
1260 to 1605
1270 to 1600
840 to 860
wavelength
range
Receiver
dBm
-11
-14
-24
-7.5
sensitivity
(multirate )
569
Item
Unit
Value
Optical
10 Gbit/s
10 Gbit/s
10 Gbit/s
10 Gbit/s
Module
Multirate-10
Multirate-40
Multirate-80
Single
Type
km
km
km
Rate-0.3 km
Receiver
dBm
-14.4
-15.8
-24
-7.5
sensitivity
(10GE
LAN)
Minimum
dBm
0.5
-1
-7
-1
receiver
overload
(10GE
LAN)
Minimum
dBm
-1
-1
-7
-1
receiver
overload
(STM-64)
Maximum
dB
-27
-27
-27
-12
reflectance
Mechanical Specifications
l Dimensions of front panel: 25.4 mm (W) x 220 mm (D) x 264.6 mm (H) (1.0 in. (W) x 8.7
in. (D) x 10.4 in. (H))
l Weight:
TN52TQX: 1.6 kg (3.5 lb.)
TN53TQX: 1.6 kg (3.5 lb.)
TN55TQX: 1.6 kg (3.5 lb.)
Power Consumption
Board
Typical Power
Maximum Power
Consumption at 25°C (77°
Consumption at 55°C
F) (W)
(131°F) (W)
TN52TQX
91.5
100
TN53TQX
45
50
TN55TQX
45
50
9.4.11 TSXL Specifications
Specifications include optical specifications, dimensions, weight, and power consumption.
570
Board
Client-Side Fixed Optical
Client-Side Pluggable Optical
Module
Module
TN11TS
40G Transponder
N/A
XL/
TN53TS
XL
NOTE
For information about the boards supported by the equipment, see Mappings Between the Board and Equipment
in the Hardware Description.
NOTE
There is a margin between the default input power low alarm threshold and the receiver sensitivity and a
margin between the default input power high alarm threshold and the overload point. This ensures that the
system can report an input power low alarm before the actual input power reaches the receiver sensitivity
or report an input power high alarm before the actual input power reaches the overload point.
Client-Side Fixed Optical Module
Table 9-153 Specifications of client-side fixed optical module
Item
Unit
Value
Optical Module Type
40G Transponder
Line code format
-
NRZ
Transmitter parameter specifications at point S
Operating wavelength range
nm
1530 to 1565
Maximum mean launched power
dBm
3
Minimum mean launched power
dBm
0
Minimum extinction ratio
dB
8.2
Minimum side mode suppression ratio
dB
35
Dispersion tolerance
ps/nm
40
Receiver parameter specifications at point R
Receiver type
-
PIN
Operating wavelength range
nm
1290 to 1570
Receiver sensitivity
dBm
-6
Minimum receiver overload
dBm
3
Maximum reflectance
dB
-27
571
Mechanical Specifications
TN11TSXL:
l Dimensions of front panel: 50.8 mm (W) x 220 mm (D) x 264.6 mm (H) (2.0 in. (W) x 8.7
in. (D) x 10.4 in. (H))
l Weight: 2.5 kg (5.5 lb.)
TN53TSXL:
l Dimensions of front panel: 25.4 mm (W) x 220 mm (D) x 264.6 mm (H) (1.0 in. (W) x 8.7
in. (D) x 10.4 in. (H))
l Weight: 1.4 kg (3.1 lb.)
Power Consumption
Board
Typical Power
Maximum Power
Consumption at 25°C (77°
Consumption at 55°C
F) (W)
(131°F) (W)
TN11TSXL
90.2
96
TN53TSXL
75
83
9.5 PID Unit Specifications
9.5.1 ENQ2 Specifications
The specifications include the dimensions, weight, and power consumption.
Mechanical Specifications
l Dimensions of front panel: 25.4 mm (W) x 220 mm (D) x 264.6 mm (H) (1.0 in. (W) x 8.7
in. (D) x 10.4 in. (H))
l Weight: 0.9 kg (2.0 lb.)
Power Consumption
Board
Typical Power Consumption
Maximum Power
at 25°C (77°F) (W)
Consumption at 55°C (131°F)
(W)
ENQ2
40
44
9.5.2 NPO2 Specifications
The specifications include the optical specifications, dimensions, weight, and power
consumption.
572
Board
WDM-Side Fixed Optical Module
WDM-Side Pluggable
Optical Module
TN54NP
200 ps/nm-PID-NRZ-PIN
N/A
O2
TN55NP
800 ps/nm-PID-NRZ-PIN (40 km)
N/A
O2
1500 ps/nm-PID-NRZ-PIN (80 km)
NOTE
For information about the boards supported by the equipment, see Mappings Between the Board and Equipment
in the Hardware Description.
NOTE
There is a margin between the default input power low alarm threshold and the receiver sensitivity and a
margin between the default input power high alarm threshold and the overload point. This ensures that the
system can report an input power low alarm before the actual input power reaches the receiver sensitivity
or report an input power high alarm before the actual input power reaches the overload point.
WDM-Side Fixed Optical Module
Table 9-154 Specifications of the PID optical module on the DWDM side
Item
Unit
Value
Optical
800 ps/nm-PID-
1500 ps/nm-PID-
200 ps/nm-PID-
Module Type
NRZ-PIN (40 km)
NRZ-PIN (80 km)
NRZ-PIN
Line code
-
NRZ
NRZ
NRZ
format
Transmitter parameter specifications at point S
Central
THz
192.10 to 196.05
192.10 to 196.05
192.10 to 196.05
frequency
Maximum
dBm
+2
+2
+2
mean launched
power (single
wavelength)
Minimum
dBm
-4
-6.5
-6.5
mean launched
power (single
wavelength)
Minimum
dB
6
6
6.5
extinction ratio
Central
GHz
±5
±5
±5
frequency
deviation
573
Item
Unit
Value
Optical
800 ps/nm-PID-
1500 ps/nm-PID-
200 ps/nm-PID-
Module Type
NRZ-PIN (40 km)
NRZ-PIN (80 km)
NRZ-PIN
Maximum -20
nm
0.8
0.8
0.8
dB spectral
width
Minimum side
dB
30
30
30
mode
suppression
ratio
Dispersion
ps/nm
800
1500
200
tolerance
Receiver parameter specifications at point R
Receiver type
-
PIN
PIN
PIN
Operating
nm
1200 to 1650
1200 to 1650
1200 to 1650
wavelength
range
Receiver
dBm
TN55NPO2S01 to
-12
-12
sensitivity
TN55NPO2S04:
(FEC enabled)
-13.5
EOL
TN55NPO2S06,
TN55NPO2S08:
-15
TN55NPO2S0A,
TN55NPO2S0B:
-15
Minimum
dBm
3
3
0
receiver
overload
Maximum
dB
-27
-27
-27
reflectance
Mechanical Specifications
TN54NPO2:
l Dimensions of front panel: 50.8 mm (W) x 220 mm (D) x 264.6 mm (H) (2.0 in. (W) x 8.7
in. (D) x 10.4 in. (H))
l Weight: 1.9 kg (4.2 lb.)
TN55NPO2:
l Dimensions of front panel: 50.8 mm (W) x 220 mm (D) x 264.6 mm (H) (2.0 in. (W) x 8.7
in. (D) x 10.4 in. (H))
574
l Weight: 1.7 kg (3.7 lb.)
TN54PQ2:
l Dimensions of front panel: 24.5 mm (W) x 68 mm (D) x 57 mm (H) (0.96 in. (W) x 2.69
in. (D) x 2.24 in. (H))
l Weight: 0.1 kg (0.22 lb.)
Power Consumption
Board
Typical Power
Maximum Power
Consumption at 25°C (77°
Consumption at 55°C
F) (W)
(131°F) (W)
TN54NPO2
134
147
TN55NPO2
143
157.3
TN54PQ2
1.1
1.2
9.5.3 NPO2E Specifications
The specifications include the optical specifications, dimensions, weight, and power
consumption.
Board
WDM-Side Fixed Optical Module
WDM-Side Pluggable
Optical Module
TN55NP
800 ps/nm-PID-NRZ-PIN (40 km)
N/A
O2E
1500 ps/nm-PID-NRZ-PIN (80 km)
NOTE
There is a margin between the default input power low alarm threshold and the receiver sensitivity and a
margin between the default input power high alarm threshold and the overload point. This ensures that the
system can report an input power low alarm before the actual input power reaches the receiver sensitivity
or report an input power high alarm before the actual input power reaches the overload point.
Specifications of Optical Modules on the DWDM Side
Table 9-155 Specifications of the PID optical module on the DWDM side
Item
Unit
Value
Optical Module
800 ps/nm-PID-NRZ-
1500 ps/nm-PID-NRZ-
Type
PIN (40 km)
PIN (80 km)
Line code format
-
NRZ
NRZ
Transmitter parameter
specifications at point S
575
