HUAWEI OptiX OSN 8800 T64/T32 Intelligent Optical Transport Platform. Product Description - part 49
WDM-Side Pluggable Optical Module
Table 9-119 Specifications of DWDM-side pluggable optical module using fixed wavelengths
Item
Unit
Value
Optical Module Type
800 ps/nm-C Band (Odd
& Even Wavelengths)-
Fixed Wavelength-NRZ-
PIN-XFP
Line code format
-
NRZ
Transmitter parameter specifications at point S
Maximum mean launched
dBm
2
power
Minimum mean launched
dBm
-3
power
Minimum extinction ratio
dB
9
Operating frequency range
THz
192.10 to 196.05
Central frequency deviation
GHz
±10
Eye pattern mask
-
G.959.1-compliant
Maximum -20 dB spectral
nm
0.3
width
Minimum side mode
dB
35
suppression ratio
Dispersion tolerance
ps/nm
800
Receiver parameter specifications at point R
Receiver type
-
PIN
Operating wavelength range
nm
1200 to 1650
Receiver sensitivity (FEC
dBm
-16
on) EOL
Minimum receiver overload
dBm
0
(FEC on)
Maximum reflectance
dB
-27
521
Table 9-120 Specifications of DWDM-side pluggable optical module using tunable wavelengths
Item
Unit
Value
Optical Module Type
800 ps/nm-C Band-
Tunable Wavelength-
NRZ-PIN-XFP
Line code format
-
NRZ
Transmitter parameter specifications at point S
Maximum mean launched
dBm
2
power
Minimum mean launched
dBm
-3
power
Minimum extinction ratio
dB
10
Operating frequency range
THz
192.10 to 196.05
Central frequency deviation
GHz
±5
Maximum -20 dB spectral
nm
0.3
width
Minimum side mode
dB
35
suppression ratio
Dispersion tolerance
ps/nm
800
Receiver parameter specifications at point R
Receiver type
-
PIN
Operating wavelength range
nm
1200 to 1650
Receiver sensitivity (FEC
dBm
-16
on) EOL
Minimum receiver overload
dBm
0
(FEC on)
Maximum reflectance
dB
-27
Table 9-121 Specifications of DWDM-side pluggable optical module using gray light
Item
Unit
Value
Optical
10 Gbit/s
10 Gbit/s
10 Gbit/s
Module Type
Multirate-10 km
Multirate-40 km
Multirate-80 km
Line code
-
NRZ
NRZ
NRZ
format
522
Item
Unit
Value
Optical
10 Gbit/s
10 Gbit/s
10 Gbit/s
Module Type
Multirate-10 km
Multirate-40 km
Multirate-80 km
Optical source
-
SLM
SLM
SLM
type
Target distance
-
10 km (6.2 mi.)
40 km (24.9 mi.)
80 km (49.7 mi.)
Transmitter parameter specifications at point S
Operating
nm
1290 to 1330
1530 to 1565
1530 to 1565
wavelength
range
Maximum
dBm
-1
2
4
mean launched
power
Minimum
dBm
-6
-1
0
mean launched
power
Minimum
dB
6
8.2
9
extinction ratio
Maximum -20
nm
N/A
N/A
N/A
dB spectral
width
Minimum side
dB
30
30
30
mode
suppression
ratio
Eye pattern
-
G.959.1-compliant
mask
Receiver parameter specifications at point R
Receiver type
-
PIN
PIN
APD
Operating
nm
1290 to 1565
1260 to 1605
1270 to 1600
wavelength
range
Receiver
dBm
-11
-14
-24
sensitivity
Minimum
dBm
-1
-1
-7
receiver
overload
Maximum
dB
-27
-27
-27
reflectance
523
Mechanical Specifications
l Dimensions of front panel: 25.4 mm (W) x 220 mm (D) x 264.6 mm (H) (1.0 in. (W) x 8.7
in. (D) x 10.4 in. (H))
l Weight:
TN11ND2/TN12ND2: 1.6 kg (3.5 lb. )
TN52ND2: 1.4 kg (3.1 lb.)
TN53ND2: 1.2 kg (2.7 lb.)
Power Consumption
Boar
WDM-Side Module
Typical Power
Maximum
d
Consumption at
Power
25°C (77°F) (W)
Consumption at
55°C (131°F) (W)
TN1
800 ps/nm-C Band (Odd & Even
61.1
68.4
1ND
Wavelength)-Fixed Wavelength-NRZ-
2
PIN
800 ps/nm-C Band-Tunable Wavelength-
62.7
70.2
NRZ-PIN
800 ps/nm-C Band-Tunable Wavelength-
68.4
76.6
DRZ-PIN
TN1
800 ps/nm-C Band-Tunable Wavelength-
57.2
64
2ND
NRZ-PIN
2
800 ps/nm-C Band-Tunable Wavelength-
62
69
DRZ-PIN
800 ps/nm-C Band (Odd & Even
46
52
Wavelengths)-Fixed Wavelength-NRZ-
PIN-XFP
10 Gbit/s Multirate-10 km
10 Gbit/s Multirate-40 km
10 Gbit/s Multirate-80 km
TN5
800 ps/nm-C Band-Tunable Wavelength-
70.5
77.5
2ND
NRZ-PIN
2
800 ps/nm-C Band-Tunable Wavelength-
67.8
74.6
DRZ-PIN
TN5
800 ps/nm-C Band (Odd & Even
25
28
3ND
Wavelengths)-Fixed Wavelength-NRZ-
2
PIN-XFP
800 ps/nm-C Band-Tunable Wavelength-
NRZ-PIN-XFP
10 Gbit/s Multirate-10 km
10 Gbit/s Multirate-40 km
524
9.4.2 NQ2 Specifications
Specifications include optical specifications, dimensions, weight, and power consumption.
Board
WDM-Side Fixed
WDM-Side Pluggable Optical Module
Optical Module
TN51NQ
N/A
800 ps/nm-C Band (Odd & Even Wavelengths)-Fixed
2
Wavelength-NRZ-PIN-XFP
800 ps/nm-C Band-Tunable Wavelength-NRZ-PIN-
XFP
10 Gbit/s Multirate-10 km
10 Gbit/s Multirate-40 km
10 Gbit/s Multirate-80 km
TN52NQ
N/A
800 ps/nm-C Band (Odd & Even Wavelengths)-Fixed
2
Wavelength-NRZ-PIN-XFP
800 ps/nm-C Band-Tunable Wavelength-NRZ-PIN-
XFP
10 Gbit/s Multirate-10 km
10 Gbit/s Multirate-40 km
TN53NQ
N/A
800 ps/nm-C Band (Odd & Even Wavelengths)-Fixed
2
Wavelength-NRZ-PIN-XFP
800 ps/nm-C Band-Tunable Wavelength-NRZ-PIN-
XFP
10 Gbit/s Multirate-10 km
10 Gbit/s Multirate-40 km
TN54NQ
N/A
800 ps/nm-C Band (Odd & Even Wavelengths)-Fixed
2
Wavelength-NRZ-PIN-XFP
800 ps/nm-C Band-Tunable Wavelength-NRZ-PIN-
XFP
10 Gbit/s Multirate-10 km
10 Gbit/s Multirate-40 km
NOTE
For information about the boards supported by the equipment, see Mappings Between the Board and Equipment
in the Hardware Description.
NOTE
There is a margin between the default input power low alarm threshold and the receiver sensitivity and a
margin between the default input power high alarm threshold and the overload point. This ensures that the
system can report an input power low alarm before the actual input power reaches the receiver sensitivity
or report an input power high alarm before the actual input power reaches the overload point.
525
WDM-Side Pluggable Optical Module
Table 9-122 Specifications of DWDM-side pluggable optical module using fixed wavelengths
Item
Unit
Value
Optical Module Type
800 ps/nm-C Band (Odd
& Even Wavelengths)-
Fixed Wavelength-NRZ-
PIN-XFP
Line code format
-
NRZ
Transmitter parameter specifications at point S
Maximum mean launched
dBm
2
power
Minimum mean launched
dBm
-3
power
Minimum extinction ratio
dB
9
Operating frequency range
THz
192.10 to 196.05
Central frequency deviation
GHz
±10
Eye pattern mask
-
G.959.1-compliant
Maximum -20 dB spectral
nm
0.3
width
Minimum side mode
dB
35
suppression ratio
Dispersion tolerance
ps/nm
800
Receiver parameter specifications at point R
Receiver type
-
PIN
Operating wavelength range
nm
1200 to 1650
Receiver sensitivity (FEC
dBm
-16
on) EOL
Minimum receiver overload
dBm
0
(FEC on)
Maximum reflectance
dB
-27
526
Table 9-123 Specifications of DWDM-side pluggable optical module using tunable wavelengths
Item
Unit
Value
Optical Module Type
800 ps/nm-C Band-
Tunable Wavelength-
NRZ-PIN-XFP
Line code format
-
NRZ
Transmitter parameter specifications at point S
Maximum mean launched
dBm
2
power
Minimum mean launched
dBm
-3
power
Minimum extinction ratio
dB
10
Operating frequency range
THz
192.10 to 196.05
Central frequency deviation
GHz
±5
Maximum -20 dB spectral
nm
0.3
width
Minimum side mode
dB
35
suppression ratio
Dispersion tolerance
ps/nm
800
Receiver parameter specifications at point R
Receiver type
-
PIN
Operating wavelength range
nm
1200 to 1650
Receiver sensitivity (FEC
dBm
-16
on) EOL
Minimum receiver overload
dBm
0
(FEC on)
Maximum reflectance
dB
-27
Table 9-124 Specifications of DWDM-side pluggable optical module using gray light
Item
Unit
Value
Optical
10 Gbit/s
10 Gbit/s
10 Gbit/s
Module Type
Multirate-10 km
Multirate-40 km
Multirate-80 km
Line code
-
NRZ
NRZ
NRZ
format
527
Item
Unit
Value
Optical
10 Gbit/s
10 Gbit/s
10 Gbit/s
Module Type
Multirate-10 km
Multirate-40 km
Multirate-80 km
Optical source
-
SLM
SLM
SLM
type
Target distance
-
10 km (6.2 mi.)
40 km (24.9 mi.)
80 km (49.7 mi.)
Transmitter parameter specifications at point S
Operating
nm
1290 to 1330
1530 to 1565
1530 to 1565
wavelength
range
Maximum
dBm
-1
2
4
mean launched
power
Minimum
dBm
-6
-1
0
mean launched
power
Minimum
dB
6
8.2
9
extinction ratio
Maximum -20
nm
N/A
N/A
N/A
dB spectral
width
Minimum side
dB
30
30
30
mode
suppression
ratio
Eye pattern
-
G.959.1-compliant
mask
Receiver parameter specifications at point R
Receiver type
-
PIN
PIN
APD
Operating
nm
1290 to 1565
1260 to 1605
1270 to 1600
wavelength
range
Receiver
dBm
-11
-14
-24
sensitivity
Minimum
dBm
-1
-1
-7
receiver
overload
Maximum
dB
-27
-27
-27
reflectance
528
Mechanical Specifications
l Dimensions of front panel: 25.4 mm (W) x 220 mm (D) x 264.6 mm (H) (1.0 in. (W) x 8.7
in. (D) x 10.4 in. (H))
l Weight:
l TN51NQ2: 1.6 kg (3.5 lb.)
l TN52NQ2: 2.0 kg (4.4 lb.)
l TN53NQ2: 1.6 kg (3.5 lb.)
l TN54NQ2: 1.6 kg (3.5 lb.)
Power Consumption
Boar
WDM-Side Module
Typical Power
Typical Power
d
Consumption at
Consumption at
25°C (77°F) (W)
25°C (77°F) (W)
TN51
800 ps/nm-C Band (Odd & Even
88
95
NQ2
Wavelengths)-Fixed Wavelength-NRZ-
PIN-XFP
800 ps/nm-C Band-Tunable Wavelength-
NRZ-PIN-XFP
10 Gbit/s Multirate-10 km
10 Gbit/s Multirate-40 km
10 Gbit/s Multirate-80 km
TN52
800 ps/nm-C Band (Odd & Even
88
97
NQ2
Wavelengths)-Fixed Wavelength-NRZ-
PIN-XFP
800 ps/nm-C Band-Tunable Wavelength-
NRZ-PIN-XFP
10 Gbit/s Multirate-10 km
10 Gbit/s Multirate-40 km
TN53
800 ps/nm-C Band (Odd & Even
46.5
50
NQ2
Wavelengths)-Fixed Wavelength-NRZ-
PIN-XFP
800 ps/nm-C Band-Tunable Wavelength-
NRZ-PIN-XFP
10 Gbit/s Multirate-10 km
10 Gbit/s Multirate-40 km
TN54
800 ps/nm-C Band (Odd & Even
53
58.3
NQ2
Wavelengths)-Fixed Wavelength-NRZ-
PIN-XFP
800 ps/nm-C Band-Tunable Wavelength-
NRZ-PIN-XFP
10 Gbit/s Multirate-10 km
10 Gbit/s Multirate-40 km
529
9.4.3 NS2 Specifications
Specifications include optical specifications, dimensions, weight, and power consumption.
Board
WDM-Side Fixed Optical Module
WDM-Side Pluggable Optical
Module
TN11NS
800 ps/nm-C Band (Odd & Even
N/A
2
Wavelength)-Fixed Wavelength-NRZ-
PIN
800 ps/nm-C Band-Fixed Wavelength-
NRZ-PIN
1200 ps/nm-C Band-Tunable
Wavelength-NRZ-PIN
1200 ps/nm-C Band-Tunable
Wavelength-NRZ-APD
4800 ps/nm-C Band-Tunable
Wavelength-ODB-APD
800 ps/nm-C Band-Tunable
Wavelength-DRZ-PIN
TN12NS
800 ps/nm-C Band (Odd & Even
800 ps/nm-C Band (Odd & Even
2
Wavelength)-Fixed Wavelength-NRZ-
Wavelengths)-Fixed Wavelength-
PIN
NRZ-PIN-XFP
1200 ps/nm-C Band-Tunable
Wavelength-NRZ-PIN
1200 ps/nm-C Band-Tunable
Wavelength-NRZ-APD
4800 ps/nm-C Band-Tunable
Wavelength-ODB-APD
800 ps/nm-C Band-Tunable
Wavelength-DRZ-PIN
800 ps/nm-C Band-Tunable
Wavelength-NRZ-PIN
TN52NS
800 ps/nm-C Band-Tunable
N/A
2
Wavelength-DRZ-PIN
800 ps/nm-C Band-Tunable
Wavelength-NRZ-PIN
TN53NS
N/A
800 ps/nm-C Band (Odd & Even
2
Wavelengths)-Fixed Wavelength-
NRZ-PIN-XFP
800 ps/nm-C Band-Tunable
Wavelength-NRZ-PIN-XFP
10 Gbit/s Multirate-10 km
10 Gbit/s Multirate-40 km
530
NOTE
For information about the boards supported by the equipment, see Mappings Between the Board and Equipment
in the Hardware Description.
NOTE
There is a margin between the default input power low alarm threshold and the receiver sensitivity and a
margin between the default input power high alarm threshold and the overload point. This ensures that the
system can report an input power low alarm before the actual input power reaches the receiver sensitivity
or report an input power high alarm before the actual input power reaches the overload point.
WDM-Side Fixed Optical Module
Table 9-125 Specifications of DWDM-side fixed optical module using fixed wavelengths
Item
Unit
Value
Optical Module Type
800 ps/nm-C Band
800 ps/nm-C Band-
(odd & even
Fixed Wavelength-
wavelengths)-Fixed
NRZ-PIN
Wavelength-NRZ-
PIN
Line code format
-
NRZ
NRZ
Transmitter parameter specifications at point S
Maximum mean launched
dBm
2
2
power
Minimum mean launched
dBm
-3
-3
power
Minimum extinction ratio
dB
10
10
Central frequency
THz
192.10 to 196.05
192.10 to 196.05
Central frequency deviation
GHz
±10
±5
Maximum -20 dB spectral
nm
0.3
0.3
width
Minimum side mode
dB
35
35
suppression ratio
Dispersion tolerance
ps/nm
800
800
Receiver parameter specifications at point R
Receiver type
-
PIN
PIN
Operating wavelength range
nm
1200 to 1650
Receiver sensitivity (FEC
dBm
-16
-16
on) EOL
Minimum receiver overload
dBm
0
0
Maximum reflectance
dB
-27
-27
531
