Optical Module Type
2.67 Gbit/s Multirate
(eSFP DWDM)-120 km
Target distance
-
120 km (74.6 mi.)
Transmitter parameter specifications at point S
Maximum mean launched
dBm
3
power
Minimum mean launched
dBm
0
power
Minimum extinction ratio
dB
8.5
Central frequency
THz
192.10 to 196.00
Central frequency deviation
nm
±12.5
Maximum -20 dB spectral
nm
1
width
Minimum side mode
dB
30
suppression ratio
Dispersion tolerance
ps/nm
2400
Eye pattern mask
-
G.957-compliant (5% margin
are required for the eye pattern
of STM-16 services and
equivalent OTU1 services)
Receiver parameter specifications at point R
Receiver type
-
APD
Operating wavelength range
nm
N/A
Receiver sensitivity
dBm
-28
Minimum receiver overload
dBm
-9
Maximum reflectance
dB
-27
Mechanical Specifications
l Dimensions of front panel: 25.4 mm (W) x 220 mm (D) x 264.6 mm (H) (1.0 in. (W) x 8.7
in. (D) x 10.4 in. (H))
l Weight: 1.1 kg (2.4 lb.)
455
Power Consumption
Board
Typical Power
Maximum Power
Consumption at 25°C (77°
Consumption at 55°C
F) (W)
(131°F) (W)
TN13LQM
32.6
35.9
9.3.11 LQMD Specifications
Specifications include optical specifications, dimensions, weight, and power consumption.
Bo
Client-Side
Client-Side
WDM-Side Fixed
WDM-Side
ard
Fixed
Pluggable Optical
Optical Module
Pluggable
Optical
Module
Optical
Module
Module
TN
N/A
I-16-2 km
12800 ps/nm-C Band-
N/A
11L
Fixed Wavelength-
S-16.1-15 km
QM
NRZ-PIN
L-16.1-40 km
D
12800 ps/nm-C Band-
L-16.2-80 km
Fixed Wavelength-
2.125 Gbit/s
NRZ-APD
Multirate-0.5 km
6500 ps/nm-C Band-
1000 BASE-LX-10 km
Fixed Wavelength-
NRZ-PIN
1000 BASE-LX-40 km
3200 ps/nm-C Band-
1000 BASE-ZX-80 km
Fixed Wavelength-
1.25 Gbit/s Multirate
NRZ-APD
(eSFP CWDM)-40 km
12800 ps/nm-C Band-
2.67 Gbit/s Multirate
Tunable Wavelength-
(eSFP CWDM)-80 km
NRZ-APD
6400 ps/nm-C Band-
Tunable Wavelength-
NRZ-APD (Four
Channels-Tunable)
1600 ps/nm-CWDM
Band-Fixed
Wavelength-NRZ-APD
456
Bo
Client-Side
Client-Side
WDM-Side Fixed
WDM-Side
ard
Fixed
Pluggable Optical
Optical Module
Pluggable
Optical
Module
Optical
Module
Module
TN
N/A
I-16-2 km
12800 ps/nm-C Band-
N/A
12L
Fixed Wavelength-
S-16.1-15 km
QM
NRZ-APD
L-16.1-40 km
D
12800 ps/nm-C Band-
L-16.2-80 km
Tunable Wavelength-
2.125 Gbit/s
NRZ-APD
Multirate-0.5 km
6400 ps/nm-C Band-
1000 BASE-LX-10 km
Tunable Wavelength-
NRZ-APD (Four
1000 BASE-LX-40 km
Channels-Tunable)
1000 BASE-ZX-80 km
1.25 Gbit/s Multirate
(eSFP CWDM)-40 km
2.67 Gbit/s Multirate
(eSFP CWDM)-80 km
2.67 Gbit/s Multirate
(eSFP DWDM)-120 km
NOTE
For information about the boards supported by the equipment, see Mappings Between the Board and Equipment
in the Hardware Description.
NOTE
There is a margin between the default input power low alarm threshold and the receiver sensitivity and a
margin between the default input power high alarm threshold and the overload point. This ensures that the
system can report an input power low alarm before the actual input power reaches the receiver sensitivity
or report an input power high alarm before the actual input power reaches the overload point.
Client-Side Pluggable Optical Module
NOTE
The I-16/SR-1 OC-48 module, S-16.1/IR-1 OC-48 module, L-16.1/LR-1 OC-48 module and L-16.2/LR-2
OC-48 module can be used to access OTU1, STM-16, OC-48, FC200, FC100, GE, STM-4, OC-12, ESCON,
STM-1, OC-3, DVB-ASI, and FE signals.
Table 9-76 Specifications of client-side pluggable optical module for SDH services
Item
Unit
Value
Optical
I-16-2 km
S-16.1-15
L-16.1-40
L-16.2-80
Module
km
km
km
Type
Line code
-
NRZ
NRZ
NRZ
NRZ
format
457
Item
Unit
Value
Optical
I-16-2 km
S-16.1-15
L-16.1-40
L-16.2-80
Module
km
km
km
Type
Optical
-
MLM
SLM
SLM
SLM
source type
Target
-
2 km (1.2 mi.)
15 km (9.3
40 km (24.9
80 km (49.7
distance
mi.)
mi.)
mi.)
Transmitter parameter specifications at point S
Operating
nm
1266 to 1360
1260 to 1360
1280 to 1335
1500 to 1580
wavelength
range
Maximum
dBm
-3
0
3
3
mean
launched
power
Minimum
dBm
-10
-5
-2
-2
mean
launched
power
Minimum
dB
8.2
8.2
8.2
8.2
extinction
ratio
Maximum
nm
N/A
1
1
1
-20 dB
spectral
width
Minimum
dB
N/A
30
30
30
side mode
suppression
ratio
Eye pattern
-
G.957-compliant
mask
G.959.1-compliant
Receiver parameter specifications at point R
Receiver
-
PIN
PIN
APD
APD
type
Operating
nm
1270 to 1580
1270 to 1580
1280 to 1335
1500 to 1580
wavelength
range
Receiver
dBm
-18
-18
-27
-28
sensitivity
458
Item
Unit
Value
Optical
I-16-2 km
S-16.1-15
L-16.1-40
L-16.2-80
Module
km
km
km
Type
Minimum
dBm
-3
0
-9
-9
receiver
overload
Maximum
dB
-27
-27
-27
-27
reflectance
NOTE
The 2.125 Gbit/s multirate module can be used to access FC200, GE, FC100, and FE signals.
NOTE
The 1000 BASE-LX-10 km module, 1000 BASE-LX-40 km module and 1000 BASE-ZX-80 km module can
be used to access GE, FC100, STM-4, OC-12, ESCON, STM-1, OC-3, FE and DVB-ASI signals.
Table 9-77 Specifications of client-side pluggable optical module for GE services
Item
Unit
Value
Optical
2.125 Gbit/s
1000 BASE-
1000 BASE-
1000 BASE-
Module
Multirate-0.
LX-10 km
LX-40 km
ZX-80 km
Type
5 km
Line code
-
NRZ
NRZ
NRZ
NRZ
format
Target
-
0.5 km (0.3
10 km (6.2
40 km (24.9
80 km (49.7
distance
mi.)
mi.)
mi.)
mi.)
Transmitter parameter specifications at point S
Operating
nm
830 to 860
1270 to 1355
1270 to 1355
1500 to 1580
wavelength
range
Maximum
dBm
-2.5
-3
0
5
mean
launched
power
Minimum
dBm
-9.5
-11.5
-4.5
-2
mean
launched
power
Minimum
dB
9
9
9
9
extinction
ratio
459
Item
Unit
Value
Optical
2.125 Gbit/s
1000 BASE-
1000 BASE-
1000 BASE-
Module
Multirate-0.
LX-10 km
LX-40 km
ZX-80 km
Type
5 km
Eye pattern
-
IEEE802.3z-compliant
mask
Receiver parameter specifications at point R
Receiver
-
PIN
PIN
PIN
PIN
type
Operating
nm
770 to 860
1270 to 1355
1270 to 1355
1500 to 1580
wavelength
range
Receiver
dBm
-17
-19
-20
-22
sensitivity
Minimum
dBm
0
-3
-3
-3
receiver
overload
NOTE
The 1.25 Gbit/s multirate module (eSFP CWDM) can be used to access GE, FC100, STM-4, OC-12, ESCON,
STM-1, OC-3, FE, DVB-ASI signals.
NOTE
The 2.67 Gbit/s multirate module (eSFP CWDM) can be used to access OTU1, STM-16, OC-48, FC200, FC100,
GE, STM-4, OC-12, ESCON, STM-1, OC-3, DVB-ASI, FE signals.
Table 9-78 Specifications of client-side pluggable optical module for CWDM colored
wavelengths
Item
Unit
Value
Optical Module Type
1.25 Gbit/s Multirate
2.67 Gbit/s Multirate
(eSFP CWDM)-40
(eSFP CWDM)-80
km
km
Line code format
-
NRZ
NRZ
Target distance
-
40 km (24.9 mi.)
80 km (49.7 mi.)
Transmitter parameter specifications at point S
Operating wavelength
nm
1471 to 1611
1471 to 1611
range
Maximum mean
dBm
5
5
launched power
460
Item
Unit
Value
Optical Module Type
1.25 Gbit/s Multirate
2.67 Gbit/s Multirate
(eSFP CWDM)-40
(eSFP CWDM)-80
km
km
Minimum mean launched
dBm
0
0
power
Minimum extinction ratio
dB
9
8.2
Central wavelength
nm
±6.5
±6.5
deviation
Maximum -20 dB
nm
1.0
1.0
spectral width
Minimum side mode
dB
30
30
suppression ratio
Eye pattern mask
-
IEEE802.3z-compliant
G.957-compliant
G.959.1-compliant
IEEE802.3z-compliant
Receiver parameter specifications at point R
Receiver type
-
PIN
APD
Operating wavelength
nm
1270 to 1620
1270 to 1620
range
Receiver sensitivity
dBm
-19
-28
Minimum receiver
dBm
-3
-9
overload
Maximum reflectance
dB
-27
-27
NOTE
The 2.67 Gbit/s multirate module (eSFP DWDM) can be used to access OTU1, STM-16, OC-48, FC200, FC100,
GE, STM-4, OC-12, ESCON, STM-1, OC-3, DVB-ASI, FE signals.
Table 9-79 Specifications of client-side pluggable optical module for DWDM colored
wavelengths
Item
Unit
Value
Optical Module Type
2.67 Gbit/s Multirate (eSFP DWDM)-120
km
Line code format
-
NRZ
Target distance
-
120 km (74.6 mi.)
461
Item
Unit
Value
Optical Module Type
2.67 Gbit/s Multirate (eSFP DWDM)-120
km
Transmitter parameter specifications at point S
Central frequency
THz
192.10 to 196.00
Central frequency deviation
GHz
±12.5
Maximum mean launched
dBm
4
power
Minimum mean launched
dBm
0
power
Minimum extinction ratio
dB
8.5
Maximum -20 dB spectral
nm
1
width
Minimum side mode
dB
30
suppression ratio
Dispersion tolerance
ps/nm
2400
Eye pattern mask
-
G.957-compliant (5% margin are required for
the eye pattern of STM-16 services and
equivalent OTU1 services)
G.959.1-compliant (5% margin are required
for the eye pattern of STM-16 services and
equivalent OTU1 services)
Receiver parameter specifications at point R
Receiver type
-
APD
Operating wavelength
nm
N/A
range
Receiver sensitivity
dBm
-28
Minimum receiver overload
dBm
-9
Maximum reflectance
dB
-27
462
WDM-Side Fixed Optical Module
Table 9-80 Specifications of DWDM-side fixed optical module
Item
Unit
Value
Optical Module
12800 ps/
12800 ps/
6500 ps/
3200 ps/
12800 ps/
6400 ps/
Type
nm-C
nm-C
nm-C
nm-C
nm-C
nm-C
Band-
Band-
Band-
Band-
Band-
Band-
Fixed
Fixed
Fixed
Fixed
Tunable
Tunable
Wavelen
Wavelen
Wavelen
Wavelen
Wavelen
Wavelen
gth-NRZ-
gth-NRZ-
gth-NRZ-
gth-NRZ-
gth-NRZ-
gth-NRZ-
PIN
APD
PIN
APD
APD
APD
(Four
Channels
-
Tunable)
Line code format
-
NRZ
NRZ
NRZ
NRZ
NRZ
NRZ
Transmitter parameter specifications at point S
Maximum mean
dBm
-4
-4
0
0
0
0
launched power
Minimum mean
dBm
-8
-8
-5
-5
-5
-5
launched power
Minimum
dB
10
10
8.2
8.2
10
8.2
extinction ratio
Central frequency
THz
192.10 to 196.00
Central frequency
GHz
±10
deviation
Maximum -20 dB
nm
0.2
0.2
0.5
0.5
0.2
0.5
spectral width
Minimum side
dB
35
35
30
30
35
35
mode suppression
ratio
Dispersion
ps/nm
12800
12800
6500
3200
12800
6400
tolerance
Eye pattern mask
-
G.959.1 - compliant
Receiver parameter specifications at point R
Receiver type
-
PIN
APD
PIN
APD
APD
APD
Operating
nm
1200 to 1650
1300 to
wavelength range
1575
Receiver
dBm
-18
-28
-18
-28
-28
-28
sensitivity
463
Item
Unit
Value
Optical Module
12800 ps/
12800 ps/
6500 ps/
3200 ps/
12800 ps/
6400 ps/
Type
nm-C
nm-C
nm-C
nm-C
nm-C
nm-C
Band-
Band-
Band-
Band-
Band-
Band-
Fixed
Fixed
Fixed
Fixed
Tunable
Tunable
Wavelen
Wavelen
Wavelen
Wavelen
Wavelen
Wavelen
gth-NRZ-
gth-NRZ-
gth-NRZ-
gth-NRZ-
gth-NRZ-
gth-NRZ-
PIN
APD
PIN
APD
APD
APD
(Four
Channels
-
Tunable)
Minimum receiver
dBm
0
-9
0
-9
-9
-9
overload
Maximum
dB
-27
-27
-27
-27
-27
-27
reflectance
Table 9-81 Specifications of CWDM-side fixed optical module using fixed wavelengths
Item
Unit
Value
Optical Module Type
1600 ps/nm-CWDM
Band-Fixed Wavelength-
NRZ-APD
Line code format
-
NRZ
Transmitter parameter specifications at point S
Maximum mean launched
dBm
2
power
Minimum mean launched
dBm
-0.5
power
Minimum extinction ratio
dB
8.2
Central wavelength
nm
1271 to 1611
Central wavelength deviation
nm
≤ ±6.5
Maximum -20 dB spectral
nm
1
width
Minimum side mode
dB
30
suppression ratio
Dispersion tolerance
ps/nm
1600
Eye pattern mask
-
G.959.1-compliant
Receiver parameter specifications at point R
464
Item
Unit
Value
Optical Module Type
1600 ps/nm-CWDM
Band-Fixed Wavelength-
NRZ-APD
Receiver type
-
APD
Operating wavelength range
nm
1200 to 1650
Receiver sensitivity
dBm
-28
Minimum receiver overload
dBm
-9
Maximum reflectance
dB
-27
Mechanical Specifications
l Dimensions of front panel: 25.4 mm (W) x 220 mm (D) x 264.6 mm (H) (1.0 in. (W) x 8.7
in. (D) x 10.4 in. (H))
l Weight: 1.4 kg (3.1 lb.)
Power Consumption
Board
WDM-Side Module
Typical Power
Maximum
Consumption at
Power
25°C (77°F) (W)
Consumption at
55°C (131°F) (W)
TN12
-
31.1
35.0
LQM
D
9.3.12 LQMS Specifications
Specifications include optical specifications, dimensions, weight, and power consumption.
465















Content   ..  41  42  43  44   ..
