CFMoto motorcycle CF650NK. Service Manual - part 2

7

、

Weight attached to handlebar or front fork will increase the mass of steering and can result in

unsafe riding condition.

8

、

Fairings, windshield

,

backrest and any other large items have the capability of adversely affecting



stability and handling of the motorcycle

.

Not only because of their weight

,

but also due to aerodynamic



forces acting on these surfaces while motorcycle is in operation. Poorly  designed or installed items

 can result in unsafe riding condition.

9

、

The motorcycle cannot be modified to triple-wheel motorcycle and intended to be used for towing

any trailer or other vehicle. CFMOTO cannot assume responsibility for the results of such uninten-

ded use of the motorcycle. Furthermore, any adverse effects on motorcycle components caused by

the use of such accessories will not be remedied under warranty.

Maximum load

：

Weight of rider

,

passenger

,

baggage and accessories must not exceed



180kg

.

-11-

   Tachometer



Water temperature indicator light



Neutral indicator light

   High beam indicator light



Fuel level indicator light                Left turn signal indicator light

   Right turn signal indicator light        EFI trouble indicator light
   Speedometer                                      Engine oil pressure warning indicator light
   Odometer                                            Neutral indicator light

①
②
③
④
⑤

⑥

⑧

⑦

⑩

⑨

11

12

Tachometer gauge ①

The tachometer shows the engine speed in revolutions per minute. There

'

s

“

RED

”

zone in right



side of tachometer

.

Engine



RPM in the red zone is above maximum recommended engine



speed

and is also above the range for good performance

.

-12-

GENERAL INFORMATION

When ignition



key



is



turned



to



“   ”

，

the tachometer needle momentarily point to last reading to

check its operation. If the tachometer doesn

'

t work correctly, have it inspected by an authorized

 CFMOTO dealer.

CAUTION

Engine r/min (RPM) should not be allowed to enter the red zone. Operation
in the red zone will overstress the engine and may cause serious engine

 damage.

High beam indicator light ②

When light switch is

“   ”

“  ”

“



”

and dimmer switch is



then high beam indicator light is lit

.

Right turn signal light ③

When turn switch is

right turn signal switch flashes on.

Speedometer ④

Speedometer is at the right side of meter instrument, it shows speed of the vehicle.

Odometer ⑤

The odometer shows total distance in Km or Miles that vehicle has been ridden.

Coolant temperature warning indicator ⑥

When coolant temperature is at C zone, it shows coolant temperature is normal. When coolant

 temperature goes onto H zone, it shows coolant temperature is too high. If warning light goes on,

stop the engine and check the coolant level in the reserve tank after the engine cools down, or go to

-13-

your dealer for consultation.

CAUTION

When water temperature warning light flashes, don't let the engine continue running.
Prolonged engine operation will result in severe damage from overheating.

Fuel gauge⑦ :

Used to tell how much fuel remains.

“

F

”

indicates the total amount of



fuel is17L



when fuel tank is

 full.

“

E

”

indicates there is only about



4L



fuel left

,

please refuel as soon as possible

.

Oil pressure warning light

⑧

When the oil pressure in the engine is too low, this light goes on.

CAUTION

When the oil pressure warning light flashes ,stop the engine，check for the oil capacity,
add oil if necessary. If oil pressure warning light flashes when the engine is cold, and the
oil capacity is enough, see your dealer. Running the engine before trouble shooting will
 result in severe damage for your engine.

Fuel injection indicator

⑨

Flashes when electrical circuit or fuel injection functions improperly.



Park indicator⑩

When



the



ignition



switch



turns



to



the

“   ”

position

，

and the vehicle parks with the side stand

,

-14-

park



indicator



is



on

.

Neutral indicator

11

Goes on when the transmission is in the Neutral.

Left turn signal indicator

12

When the turn signal switch is pushed to

“   ”，

Left turn signal indicator flashes.

Key

Can be used for ignition switch/steering lock, seat lock, and fuel tank cap. Keep your key safely

.

Remove the spare key and store it in a safe place

.

If both original and spare keys are lost

,

see you

dealer

.

A

B

C

Power off
Power on
Steering locked

Ignition Switch/Steering Lock

This ignition switch has



“     ”

、

“   ”

、 “   ”

positions, etc.

“     ”

: Engine can’t be started.

ALL electrical circuits off.
Engine can be started.

ALL electrical equipment can be used.

Steering locked. ALL electrical circuits off.

“   ”

:



“   ”

:

-15-

NOTE

All lights can be lit when the ignition key is in the

position. when

 headlight is on, it's better to start the engine. Otherwise, prolonged
 lighting can cause battery being discharged ,even damaged.

Right Handlebar Switches
Engine Stop Switch①

Both ignition switch and engine stop switch must
be put in the



position before riding.

The engine stop switch is for emergency use. If

some emergency requires stopping the engine,

turn the engine stop switch to the



position.

①
②
③

Engine Stop Switch
Lighting Switch
Starter button

NOTE

Although the engine stop switch stops the engine, it

 doesn't turns off all the electrical circuits. Ordinarily,

the ignition switch should be used to stop the engine.

Lighting Switch②

Lighting switch includes

：

“    ” 、

“ ”

“   ”、

-16-

“    ”:

“ ”

“   ” ：

When the lighting switch turns to this position

，

headlight, position light, tail light, panel

 light can be lit.

When the lighting switch turns to this position

，

position light, tail light, panel light can be lit

.

:

When the lighting switch turns to this position

，

headlight, position light, tail light, panel

light are off.

Starter button

③

When both ignition switch and engine stop switch turn to the

position

，

meanwhile, transmis-

sion is in the Neutral, push this button to start the engine.



Left Handlebar Switches
Dimmer Switch①

Dimmer switch consists of

：

“   ” 、“   ”

positions,



etc.

①
②
③

     ④

     ⑤

Dimmer Switch

Assing Button

Turn Signal Switch        Hazard Button
Horn Button

: When dimmer switch turns to this position

and lighting switch is on

，

Hi beam and Hi beam



indicator



go



on

.

: When dimmer switch turns to this

Position and lighting switch is on

，



Lo beam is lit.

Turn Signal Switch②

Includes:

“   ”、

“   ”、“   ”

positions, etc.

：

When turn signal switch moves to this Position

 ,



left turn light and left turn signal Indicator are lit.

-17-

:

When turn signal switch is pushed in,



turn light is off

.

:

When turn signal switch moves to this position,  right turn light and right turn signal indicator

are on.

Horn Button③

Overriding Button④

When the horn button is pushed, the horn sounds.

When the passing button is pushed, the Hi beam(passing beam) comes on to signal the driver of the

vehicle ahead that you are about to pass him. The passing light is off as soon as the passing button

 is released.

Hazard Button

：

⑤

When this button is pushed in, turn lights and turn signal indicators flash to warn other drivers

of your location.

CAUTION

If you leave the hazard button on for over 30 minutes, the battery may become totally

 discharged.

Brake/Clutch Lever Adjuster

There is an adjuster on both the brake and clutch levers. Each adjuster has 5 positions so that the

 released lever position can be adjusted to suit the operator

'

s hands. Push the Lever forward and

 turn the adjuster to align the number with the arrow mark on the lever holder. The distance from the

-18-

 grip to the released lever is minimum at Number 5 and maximum at Number 1.

①

②

Adjuster
Mark

Fuel Tank Cap

To open the fuel tank cap, pull up the key hole cover. Insert the ignition key into the fuel tank cap and

 turn the key to the right.

To close the cap, push it down into place with the key inserted. The key can be removed by turning it

 to the left to the original position.

The fuel tank cap cannot be closed without the key inserted, and the key cannot

 be removed unless the cap is locked properly. Don't push on the key to close the

cap, or the cap cannot be locked.

NOTE

-19-

①
②
③

The fuel tank cap cannot be closed without the key inserted, and the key cannot

 be removed unless the cap is locked properly. Don't push on the key to close the

cap, or the cap cannot be locked.

NOTE

Key Hole cover
Ignition Key
Fuel Tank Cap

Fuel Tank

Avoid spilling gasoline on the fuel tank ,if so, wipe

 it off immediately to prevent it from pollution or

causing dangers.

A

B

C

D

Fuel Tank Cap
Fuel Tank

Top Level

Filler Neck

-20-

WARNING

Gasoline is extremely flammable and can be explosive under certain conditions. When

 refueling, turn the ignition key to “OFF” .Don't smoke. Make sure the area is well

ventilated and free from any source of flame or sparks; this includes any appliance with
a pilot light. Never fill the tank so the fuel level rises to the filler neck .After refueling,
make sure the fuel tank cap is locked securely.

Fuel Requirement

This motorcycle is designed to use only unleaded 93# or above gasoline.

CAUTION

Don't use leaded gasoline, as this will destroy the catalytic converter（For further

 information ,refer to the catalytic converter section in the “How to ride the
 Motorcycle” chapter）

Octane Rating

The octane of a gasoline is a measure of its resistance to detonation or “knocking”.The term comm-
only used to describe a gasoline's octane rating is the Research Octane Number(RON).The higher
the RON is,the greater the gasoline's resistance to “knocking” is.Always use a gasoline with an

 octane rating equal to, or higher than RON 93.

NOTE

If “knocking” or “pinging” occurs, use a different brand of unleaded gasoline
 or an unleaded gasoline with higher octane rating.

-21-

Side Stand

This motorcycle is equipped with a side stand.

A

B

Side Stand
Side Stand Switch

NOTE

When using the side stand, turn the handlebar to the left.

Kick the side stand fully up before riding.

This motorcycle is equipped with a side stand switch. This switch is designed so

 that the engine doesn't start if the transmission in gear and the side stand is down.

-22-

Front Seat Lock

Front Seat Removal

Insert the ignition key into the seat lock.

Turn the key clockwise while pushing down the rear end of the seat

,

then pull up the front seat

.

A

B

C

E

D

Front Seat
Seat Lock
Ignition Key
Insert
Turn

-23-

Rear Seat

Rear Seat Removal

To remove the rear seat, remove the front seat first. Pull the seat release pin out while pushing down
the rear end of the rear seat, then pull up the rear seat.

A

B

Rear Seat
Seat Release Pin

NOTE

If there is a difficulty removing the seat, be sure to insert the ignition key all the way and
to push down strongly on the rear end of the seat while turning the key clockwise.

-24-

Seat Installation

Install seats in the reverse order of removal. After installation finished, make sure the seats are

securely locked, then remove the ignition key.

Helmet Holding Cable

Helmet can be secured to the motorcycle by helmet holding cable to avoid theft after parking.

WARNING

Don't ride the motorcycle with a helmet attached to the cable. The helmet could cause
an accident by distracting the operator or interfering with normal vehicle operation.

A

Helmet Holding Cable

-25-

Tool Kit

Stored under the front seat. You can see it once you open the front seat.

A

Tool Kit

The kit is helpful in making some simple repairs and adjustments.

Rear View Mirror

Rear View Mirror Adjustment

 Adjust the rear view mirror by slightly moving only the mirror portion of the assembly.

If the rear visibility can't be assured by moving the mirror, turn the mirror arm by hand.
