-46-

Instrument Cluster

Parking indicator light

 “

P

”⑦

Switch on the position

“

P

”,

indicatior



light



will



be



on

.

Turn right indicator light

⑧

Switch on the



position

“”，

indicator light will be on.

Aeta indicator light

⑨

Press aeta switch,indicator light will be on.
High beam indicator ligth

⑩

Switch on the



position

and light switch on the position

,

indicator



light



will



be



on

.

Sidelights indicator light

⑾



Light switch on the position

Indicatior light will be on.

Malfunction Indicator Lamp

 ⑿



When vehicle is malfunction,the malfunction indicator lamp will be on.(see page 47

).

Clock

⒀



Display time, clock adjustment

 (

see



page 39

)

Note：

Indicator light is lighten and speedmeter is

'

not working,inquire the local dealer and insepct the speed sensor

whether it is defect.



-47-

Instrument Cluster



Refe no





Failure Description



Defects type



1

P0030





Signal defects



2

P0031







Min defects



3

P0032





Max defects



7

P0053







9

P0105







10

P0106







11

P0107





Min defects



12

P0108





Max defects



13

P0112





Max defects



14

P0113





Mi n defects



15

P0116







16

P0117





Max defects



17

P0118





Min defects





O2 Sensor Heater Contr. Circ

/

Open

O2 Sensor Heater Contr. Circ. Low

O2 Sensor Heater Contr. Circ. High

O2 Sensor Heater Resistance

Manifold



Abs

.

Pressure



or



Bar

.

Pressure Circuit

Manifold Abs.Pressure or Bar.Pressure Range/Performance

Manifold Abs.Pressure or Bar.Pressure Low Input

Manifold Abs.Pressure or Bar.Pressure High Input
Intake Air Temp.Circ. Low Input

Intake Air Temp.Circ. High Input

Engine Coolant Temp.Circ. Range/Performance

Engine Coolant Temp.Circ. Low Input

Engine Coolant Temp.Circ. High Input

Error code

Error



code



as



four



digit



blink



model

:

For example

：

0650

“

0

”：

blink 10



times

；

“

6

”：

blink 6



times

；

“

5

”：

blink 5



times

；

“

0

”：

blink 10



times

；

Error



code

-48-

Instrument Cluster

For example

：

0650

“

0

”：

blink 10 times

；

“

6

”：

blink 6 times

；

“

5

”：

blink 5 times

；

“

0

”：

blink 10 times

；



Refe no





Failure Description



Defects type



18

P0122







19

P0123







20

P0130







21

P0131







22

P0132







23

P0133







24

P0134







29

P0170







30

P0171







31

P0172







32

P0201







33

P0202







36

P0261











Error code

Error



code



as



four



digit



blink



model

:

Throttle Pos.Sensor Circ. Low Input

Min

.

error

Max

.

error

Signal error

Only for 2-cylinder

 engine

Min

.

error

Throttle Pos.Sensor Circ. High Input

O2 Sensor Circ. Malfunction

O2 Sensor Circ. Low Voltage
O2 Sensor Circ. High Voltage

O2 Sensor Circ. Slow Response

O2 Sensor Circ. No Activity Detected

Fuel Trim, Malfunction

Fuel Trim, System too Lean

Fuel Trim, System too Rich

Cylinder 1- Injector Circuit
Cylinder 2- Injector Circuit

Cylinder 1- Injector Circuit Low

Error



code

-49-

REF

Failure  Description                                                         Sort

37
38

39

51

52

60
61

62

65
66

67

68

69

P0262

P0264

P0265

P0321

P0322

P0444

P0458

P0459
P0501
P0506

P0507
P0508

P0509

Instrument Cluster

Cylinder 1- Injector Circuit High

Serious problem

Cylinder 2- Injector Circuit Low

Cylinder 2- Injector Circuit High

Engine Speed Reference Mark

Eng.Speed Inp.Circ. No Signal

Evaporative



Emiss

.

System



Purge



Control



Valve



Circ

.

Open

Evapora ti ve Emission Syste m Purg e Contr ol Valve Circ uit Low

Evapora ti ve Emission Syste m Purg e Contr ol Valve Circ uit High

Signal problem

Vehicle Speed Sensor Range/Performance

Signal problem

Idle Control System RPM Lower than Expected

Idle Control System RPM Higher than Expected

Drive



pi n



of



st ep



mot or

:

sho rt



ci rcui t



to



gr ound

Drive



pi n



of



st ep



mot or

:

shor t



ci rcui t



to



bat ter y

Error code

Error



code

Downloading Codes by Following

：

E.G.

：

0650

“

0

” ：

blink 10



times

；

“

6

” ：

blink 6



times

；

“

5

” ：

blink 5



times

；

“

0

” ：

blink 10



times

；

-50-

REF

Failure  Description                                                         Sort

P0511

P0560

P0562

P0563

P0602

P0627

P0628

P0629
P0650
P2177

P2178
P2195

P2196

70

75

76

77

78

79

80

81
85
91

92
93

94

Instrument Cluster

Instrument Cluster

Drive



pin



of



step



motor

:

open



circuit

System Voltage Malfunction

System Voltage Low Voltage

System Voltage High Voltage

Control Module



Programming



Error

Fuel Pump Control Circuit /Open
Fuel Pump Control Circuit Low

Fuel Pump Control Circuit High

Drive



circuit



error



of



MIL



light

System Too Lean
System Too Rich
O2 Sensor Circ., Slow Response



lean

O2 Sensor Circ.,



Slow



Response



rich

Unreasonable problem

Unimportant



problem

Serious problem

Signal problem

Unimportant



problem

Unimportant



problem

Error



code

Error code

Downloading Codes by Following

：

E.G.

：

0650

“

0

” ：

blink 10



times

；

“

6

” ：

blink 6



times

；

“

5

” ：

blink 5



times

；

“

0

” ：

blink 10



times

；

-51-

OPERATION

Vehicle Break-In Period

The break-in period for your new  CFMOTO  vehicle is the first 20



hours



of



operation, or the time it  takes to use

 the first two tanks full of gasoline.No single action on your part is as important as a proper break-in period.

Careful treatment of a new engine and drive components will result in



more efficient performance and longer

life for these components.



Perform



the following procedures carefully.

CAUTION

Excessive heat build-up during the first three hours of operation will damage



close-fitted engine parts and

drive components. Do not operate at full throttle



or more 50KM/H during the first three hours of using

.

Use of any oils other than those recommended by us



may



cause



serious



engine damage. We recommend

 the use of SAE 15/W40 SG oil.

-52-

OPERATION

Vehicle Break-In Period

The break-in period for your vehicle is defined on the previous page.
Please read the information carefully.
Engine and Drivetrain Break-in
1. Fill the fuel tank with gasoline. See page 36.
2. Check the oil level. See page 81

.

Add



the



recommended



oil



as



needed to maintain the oil level in

 the safe operating range.

3

．

Complete the New Operator Driving Procedures outlined on pages 57-58

NOTE:

Avoid aggressive use of the brakes. See Brake System Break-in.

4. Vary throttle positions. Do not operate at sustained idle.
5.Perform regular checks on fluid levels, controls and areas outlined



on the daily



pre

-

ride



inspection



checklist

.

See page 53

.

6.Pull only light loads.
7.During the break-in period, change both the oil and the filter at 20 hours or 250km
Brake System Break-in
Apply only moderate braking force for the first 50 stops

.

Aggressive



or



overly forceful braking when

 the brake system is new could damage



brake pads and rotors.

CVT



Break-in (Clutches/Belt)

A proper break-in of the clutches and drive belt will ensure a longer life



and better performance. Break

 in the clutches and belt by operating at



slower speeds during the break-in period as recommended.

 Pull only



light loads. Avoid aggressive acceleration and high speed operation during



the break-in  period.

-53-

Pre-Ride Inspection

If a proper inspection is not done before each use, severe injury or death



could result. Always inspect the

 vehicle before each use to ensure it's in



proper operating condition.

Item

Remarks

Page

Brake system/pedal travel

Ensure proper operation

Brake fluid

Ensure proper level

Front suspension

Inspect, lubricate if necessary

Rear suspension

Inspect, lubricate if necessary

Steering

Ensure free operation

Tires

Inspect, ensure fastener tightness

Frame nuts, bolts, fasteners

Inspect, ensure tightness

Fuel and oil

Ensure proper levels

Coolant level

Ensure proper level

Coolant hoses

Inspect for leaks

Throttle

Ensure proper operation

Indicator lights/switches

Ensure proper operation

Air filter, pre-filter

Inspect, clean

Headlamp

Check operation, apply  CFMOTO dielectric



grease when lamp is replaced

Brake light/tail lamp

Check operation, apply CFMOTO dielectric



grease when lamp is replaced

Seat Latches

Push down on both seat backs to



ensure the latches are secure

Seat Belts

Check length of belt for damage,



check latches for proper operation

Cab Nets

Check for wear or damage, ensure



proper installation

43,99

100

78

78

101

4,103

103

44,81

91,92

97
39
95

105

107

34
37

Wheels/fasteners

Inspect condition and pressure

-54-

Starting the Engine

Engine exhaust contains poisonous carbon monoxide and can cause loss of



consciousness resulting in

 severe injury or death. Never run an engine in an



enclosed area.

1

．

Sit in the driver's seat and fasten the seat belt.

2

．

Place the transmission in PARK.

3

．

Apply the brakes.



NOTE:

Do not press the throttle pedal while starting the engine.

4

．

Turn the ignition key past the ON/RUN position to START. Engage



the starter for a maximum of five

seconds. Release the key when the



engine starts.

5

．

If the engine does not start within five seconds, return the ignition



switch to the OFF position and

 wait five seconds. Repeat steps 4



and 5 until the engine starts.

6

．

Vary the engine RPM slightly with the throttle to aid in warm up



until the engine idles smoothly.

Stopping the Engine

Operating the vehicle immediately after starting could cause engine damage. Allow the engine to warm up for

 several minutes before operating the vehicle.

1

．

Release the throttle pedal completely and brake to a complete stop.

2

．

Place the transmission in PARK.



3

．

Turn the engine off.

A rolling vehicle can cause property damage and serious injury. Always place the transmission in



PARK



when



stopping



the



engine

.

-55-

Braking

1

．

Release the throttle pedal completely.

2

．

Press on the brake pedal evenly and firmly. Practice starting and



stopping (using the brakes) until you're

familiar with the controls.

NOTE:

When the throttle pedal is released completely and engine speed



slows to near idle, the vehicle has

no engine braking

.

Failure to allow for increased braking distance when hauling cargo or towing



a trailer may result in accident

 and injury.



Always



slow



down



and



allow



additional braking distance when towing or hauling cargo.

-56-

Parking the Vehicle

Gasoline is extremely flammable and can be explosive under certain



conditions. When parking inside a garage

or other structure, be sure that the



structure is well ventilated and that the vehicle is not close to any source

 of



flame or sparks, including any appliance with pilot lights

.

A rolling vehicle can cause property damage and serious injury. Always place



the transmission in PARK when

 stopping the engine.

1. Stop the vehicle on a level surface. Place the transmission in PARK.
2. Turn the engine off.
3. Remove the ignition switch key to prevent unauthorized use.

-57-

New Operator Driving Procedures

Operating improperly can cause an accident or overturn which could result in



severe injury or death. This

 vehicle handles differently than cars, trucks or



other off-road vehicles. Operators of this vehicle must become

 familiar with



vehicle handling at slow speeds before operating at faster speeds.

Do not carry a passenger until you have at least two hours of driving



experience with this vehicle.

1. Do not carry a passenger until you have at least two hours of driving



experience with this vehicle.

2. Do not tow or carry cargo during this period.
3. Select an open area that allows room to familiarize yourself with



vehicle operation and handling

.

Check



your



surroundings



and



determine



your path of travel.

4. Keeping both hands on the steering wheel, slowly release the brakes



and depress the throttle with your

 right foot to begin driving.

-58-

New Operator Driving Procedures

5

．

Drive slowly at first. On level surfaces, practice starting, stopping,



turning, maneuv-

ering, using the throttle and brakes and driving in



reverse. Learn how the vehicle handles

 when making both left and



right turns at a slow speed.

6

．

Increase speed only after mastering all maneuvers at a slow speed.

7

．

After you become skilled at making turns and begin to operate at



faster speeds, follow

 these precautions:

●

Avoid sharp turns.

●

Never turn while applying heavy throttle.

●

Never make abrupt steering maneuvers.

●

Operate at speeds appropriate for your skills, the conditions and



the terrain.

●

DO NOT do power slides,

“

donuts

”,

jumps



or



other



driving



stunts.

-59-

Driving with a Passenger

1

．

Complete the New Operator Driving Procedures outlined on pages 57-58

.

2

．

Perform the pre-ride inspection. See page

53

.

3

．

Make sure the passenger is at least 12 years of age and is tall enough



to comfortably and safely sit in the

 passenger seat with the seat belt



secured, put both feet on the floor and grasp the hand holds.



4

．

Make sure the passenger is wearing appropriate riding gear, including



an approved helmet and eye

 protection. See page 13.

5

．

Make sure the passenger secures the seat belt.

-60-

Driving with a Passenger

6

．

Allow a passenger to ride only in the passenger seat.

7

．

Do not carry more than one passenger. Additional passengers can



affect the operator

'

s ability to steer

 and operate the controls.
8

．

Slow down. Always travel at a speed appropriate for your skills,



your passenger's skills, and operating

 conditions. Avoid unexpected



or aggressive maneuvers that could cause discomfort or injury to a



passenger.

9

．

Vehicle handling may change with a passenger and/or cargo on



board. Allow more time and distance for

 braking.

10

．

Always follow all operating guidelines as outlined on safety labels



and in this manual

-61-

Driving on Slippery Surfaces

When driving on slipperysurfaces such as



wet trails,

、

loose gravel,



or ice, be alert for the



possibility of skidding

and sliding.



Under



these conditions, follow



these precautions:

1

．

Slow down when



entering slippery



areas.

2

．

Maintain a high



level of alertness,



reading the trail

and avoiding



quick, sharp turns, which can cause skids.

3

．

Engage all-wheel drive before wheels begin to lose traction.

4

．

Correct a skid by turning the steering wheel in the direction of the

skid.



Severe damage to the drive train may occur if the AWD is engaged while the



wheels are spinning. Always allow

 the wheels to stop spinning before



engaging AWD.

Failure to exercise care when operating on slippery surfaces can result in



loss of tire traction and cause loss

of control, accident, and serious injury or



death.

Never apply the brakes



during



a



skid

.

Do not operate on excessively slippery surfaces.
Always reduce speed and use additional caution when operating on slippery



surfaces.
