Сигнальные колонны SL. Обзор системы
Видео «Signal towers SL4
and SL7».
Обозначения
1. Модуль ламп накаливания
2. Светодиодные модули, непрерывный свет
3. Светодиодные модули, мигающий свет
4. Светодиодные модули, стробоскопический свет
5. Акустические модули
6. Базовые модули
7. Базовый модуль для подключения к
коммуникационной системе SmartWire-DT
8. Аксессуары
Сигнальные колонны серии
SL
выгодно отличаются легко узнаваемым дизайном, уникальной яркостью светодиодных
модулей, гибкостью монтажа и простой настройкой звуковой сигнализации, адаптируемой к любым условиям
эксплуатации!
Обеспечивают визуальные и звуковые сигналы состояния установки, легко определяемые на расстоянии. Сигналы,
представленные как непрерывный свет, мигающий свет, вспышки или звук, согласно их уровню важности, могут быть
правильно оценены.
Колонны доступны в двух исполнениях:
SL4
и
SL7
, что, вместе с высокой степенью защиты IP66, позволяет
использовать их в широком спектре решений. Индивидуальные модули могут быть скомпонованы и собраны простым
прищелкиванием и легким поворотом, без дополнительных инструментов и проводов.
Сигнальные колонны
SL4
Диаметр
40
мм
SL7
Диаметр
70
мм
148
Command & Signaling
CA047003EN – October 2016 www.eaton.eu
SL7
70mm
SL4
40mm
Signal Operating States Quickly,
Clearly, and Flexibly
SL4 and SL7 signal towers are used to continuously signal operating states for
machines, systems, and processes. Their scope of application is extremely wide-
ranging, going from production, through logistics, all the way to retail. This is in no
small part thanks to the fact that the fast and clear signaling they provide ensures
smooth and safe operation in any environment.
The light and acoustic modules in the series can be configured flexibly both in
terms of volume and of the specific visual signals they emit. This versatility is only
further enhanced by the signal towers‘ high-performance LEDs, which ensure that
visual signals are recognized even under adverse light conditions. Moreover, a high
IP66 degree of protection makes it possible to use the signal towers in demanding
environments, such as outdoors.
With a diameter of 40 mm / 70 mm, SL4 and SL7 signal towers feature extremely
compact dimensions designed to save space. In addition, only a few steps are
required in order to quickly and easily install and remove them, which can prove to be
a tremendous advantage when packing and transporting control panels or machines.
Connecting the signal towers to a SmartWire-DT communication system cuts down
on wiring time and reduces the number of digital outputs required from your
PLC. This, combined with the fact that data from the switchgear connected with
SmartWire-DT will be processed in your PLC, ensures that operating states such
as impending overloads will be detected and signaled with the signal towers
immediately. The result? A marked increase in your systems‘ availability.
SL7/SL4signaltowers
configurator
www.eaton.eu/config/SL
148
Command & Signaling
CA047003EN – October 2016 www.eaton.eu
SL7
70mm
SL4
40mm
Signal Operating States Quickly,
Clearly, and Flexibly
SL4 and SL7 signal towers are used to continuously signal operating states for
machines, systems, and processes. Their scope of application is extremely wide-
ranging, going from production, through logistics, all the way to retail. This is in no
small part thanks to the fact that the fast and clear signaling they provide ensures
smooth and safe operation in any environment.
The light and acoustic modules in the series can be configured flexibly both in
terms of volume and of the specific visual signals they emit. This versatility is only
further enhanced by the signal towers‘ high-performance LEDs, which ensure that
visual signals are recognized even under adverse light conditions. Moreover, a high
IP66 degree of protection makes it possible to use the signal towers in demanding
environments, such as outdoors.
With a diameter of 40 mm / 70 mm, SL4 and SL7 signal towers feature extremely
compact dimensions designed to save space. In addition, only a few steps are
required in order to quickly and easily install and remove them, which can prove to be
a tremendous advantage when packing and transporting control panels or machines.
Connecting the signal towers to a SmartWire-DT communication system cuts down
on wiring time and reduces the number of digital outputs required from your
PLC. This, combined with the fact that data from the switchgear connected with
SmartWire-DT will be processed in your PLC, ensures that operating states such
as impending overloads will be detected and signaled with the signal towers
immediately. The result? A marked increase in your systems‘ availability.
SL7/SL4signaltowers
configurator
www.eaton.eu/config/SL
