33.9 Removing, dismantling, reassem- • Drain the oil. • [RS] Remove number plate carrier. • [GS] Remove rear wheel cover at rear wheel • Unfasten brake caliper/secure to rear frame with • [ABS]/[GS/R/RT] Remove sensor. Removing rear wheel drive • Remove rear wheel. • Loosen strut at rear wheel drive (1). • Release clamping strap (2). • Heat free bearing journal (3) to max. 120 °C/ • [RS/R/RT] Remove brake disk/heat retaining • Remove free bearing/fixed bearing journal (3/4). L Note: Inner races of needle bearings. • Detach strut from rear wheel drive. • Disconnect rear wheel drive from drive shaft. L Note: If rear wheel drive is filled with oil, do not place on Removing input bevel pinion • Press out splined section of shaft. • If necessary, remove/install circlip. 3 2 1 4 j 120 j 120 RS330010 LT 33.043 LT330430 |
