46.3
46
Technical Data 46 Frame
R 1150 RT
Frame
Type
Cast aluminium front frame with tubular steel rear
frame, load-bearing drive unit
Data plate location
Front frame, on right
Vehicle identification number location
Front frame, on right
Vehicle dimensions
Maximum length
mm (in) 2,230 (87.7968)
Overall height in normal position (full fuel
load and 85 kg/187 lbs rider)
mm (in) 1,380 (54.3316)
Maximum width (across mirrors)
mm (in) 898 (35.3549)
Seat height without rider
mm (in) 805/825/845 (31.6935/32.4809/33.2683)
[OE] low seat
mm (in) 780/800/820 (30.7092/31.4966/32.2840)
Ground clearance in normal position (full fuel
load and 85 kg/187 lbs rider)
mm (in) 153 (6.0237)
Vehicle weight
Unladen weight, ready for road, tank full
(without optional extras)
kg (lbs) 279 (615) (without cases)
Dry weight
kg (lbs) 255.1 (562.39)
Permitted gross weight
kg (lbs) 490 (1080)
Maximum payload
kg (lbs) 211 (465)
Running-gear data
Wheelbase in normal position (full fuel load
and 85 kg/187 lbs rider)
mm (in) 1,485
Castor in normal position (full fuel load and
85 kg/187 lbs rider)
mm (in) 122 (4.8032)
Steering head angle in normal position (full
fuel load and 85 kg/187 lbs rider)
° 62.9
Steering lock angle
° 34
Axle load split in normal position (f/r) (full fuel
load and 85 kg/187 lbs rider)
% 49.1 / 50.9
Wheel track offset
normal
mm (in) + 3.5 (0.1378) (= to right)
Max
mm (in) ± 9 (± 0.3543); datum is + 3.5 (+ 0.1378)
