Perceived temperature

The climate control system regulates the cli-
mate in the passenger compartment based
on the perceived temperature, not on actual
temperature.

The temperature you select in the passenger
compartment corresponds to the physically
perceived temperature as affected by factors
such as the ambient temperature, air speed,
humidity, solar radiation, etc. in and around
the car at the time.

The system includes a sun sensor which
detects on which side the sun is shining into
the passenger compartment. This means that
the temperature can differ between the right
and left-hand side's air vents despite the con-
trols being set for the same temperature on
both sides.

Related information

•

-------------------------------------------------------------------------------------------------------------------------------------------------------------

CLIMATE

* Option/accessory.

200

Controlling the climate control

system using voice control

Commands for voice control of the climate
control system in order to e.g. change tem-
perature, activate a heated seat

or change

fan level.

Tap on

and say one of the following com-

mands:

•

Climate

" - starts a dialogue for climate

control and shows examples of com-
mands.

•

Set temperature to X degrees

" - sets

the desired temperature.

•

Raise temperature

"/"

Lower

temperature

" - raise/lower the tempera-

ture setting one step.

•

Sync temperature

" - synchronises the

temperature for all climate zones in the car
with the temperature set for the driver's
side.

•

Air on feet

"/"

Air on body

" - opens the

desired air flow.

•

Air on feet off

"/"

Air on body off

" -

closes the desired air flow.

•

Set fan to max

"/"

Turn off fan

" -

changes the air flow to

Max

Off

•

Raise fan speed

"/"

Lower fan speed

" -

raises/lowers the fan level one step.

•

Turn on auto

" - activates automatic cli-

mate regulation.

•

Air condition on

"/"

Air condition off

" -

activates/deactivates the air conditioning.

•

Recirculation on

"/"

Recirculation off

" -

activates/deactivates the air circulation.

•

Turn on defroster

"/"

Turn off

defroster

" - activates/deactivates defrost-

ing of windows and door mirrors.

•

Turn on max defroster

"/"

Turn max

defroster off

" - activates/deactivates the

max defroster.

•

Turn on electric defroster

"/"

Turn off

electric defroster

" - activates/deacti-

vates the heated windscreen

•

Turn on rear defroster

"/"

Turn off rear

defroster

" - activates/deactivates the

heated rear window and door mirrors.

•

Turn steering wheel heat on

"/"

Turn

steering wheel heat off

" - activates/

deactivates the heated steering wheel

•

Raise steering wheel heat

"/"

Lower

steering wheel heat

" - raises/lowers the

setting for the heated steering wheel

one

step.

•

Turn on seat heat

"/"

Turn off seat heat

- activates/deactivates the heated seat

•

Raise seat heat

"/"

Lower seat heat

" -

raises/lowers the setting for the heated
seat

one step.

•

Turn on seat ventilation

"/"

Turn off

seat ventilation

" - activates/deactivates

the seat ventilation

•

Raise seat ventilation

"/"

Lower seat

ventilation

" - raises/lowers the setting for

the ventilated seat

one step.

Not all system languages support voice
recognition. The ones that do are high-
lighted with the

symbol in the list of

available system languages. Read more
about where the information can be found
in the section on settings for voice recogni-
tion.

Related information

•

Voice recognition (p. 143)

•

•

Using voice recognition (p. 144)

•

Settings for voice recognition (p. 148)

Applies to certain markets.

-------------------------------------------------------------------------------------------------------------------------------------------------------------

CLIMATE

}}

* Option/accessory.

201

Air quality

The materials selected for the passenger
compartment and the air cleaning system
ensure that the air quality in the passenger
compartment is high.

Materials in the passenger
compartment

The interior of the passenger compartment is
designed to be pleasant and comfortable,
even for people with contact allergies and for
asthma sufferers.

Tested materials have been developed in order
to reduce the quantity of dust in the passenger
compartment and to contribute to making the
passenger compartment easier to keep clean.

The carpets in both the passenger compart-
ment and the cargo area are removable and
easy to remove and clean.

Use cleaning agents and car care products
recommended by Volvo to clean the interior.

Air cleaning system

In addition to the passenger compartment fil-
ter, the car is equipped with an air cleaning
system that helps to maintain high air quality
in the passenger compartment.

Related information

•

•

•

•

•

Advanced Air Cleaner

(p. 204)

•

CleanZone

The CleanZone function checks and indicates
whether or not all conditions have been met
for good air quality in the passenger compart-
ment.

The indicator is visible in the climate view
in the centre display.
The indicator is visible in the climate row
when the climate view is not open.

If the conditions have not been met then the

Clean Zone

text is white. When all conditions

have been met, this is indicated by the text
changing colour to blue.

Conditions that need to be met:

•

That all doors and the boot lid are closed.

•

That all side windows and the sunroof

are

closed.

-------------------------------------------------------------------------------------------------------------------------------------------------------------

CLIMATE

* Option/accessory.

202

•

That the air quality system Interior Air
Quality System

is activated.

•

That the ventilation fan is activated.

•

That the air recirculation is deactivated.

CleanZone does not indicate that the air
quality is good. It only indicates that the
conditions for good air quality have been
met.

Related information

•

•

•

•

Clean Zone Interior Package

Clean Zone Interior Package (CZIP) compri-
ses a series of modifications that keep the
passenger compartment even clearer from
allergy and asthma-inducing substances,
among other things.

The following is included:

•

An enhanced fan function that means that
the fan starts when the car is unlocked
with the remote control key. The fan fills
the passenger compartment with fresh air.
The function starts when required and is
disengaged automatically after a time or
when one of the passenger compartment
doors is opened. The amount of time the
fan runs is reduced gradually due to
reduced need up until the car is 4 years
old.

•

The fully automatic air quality system
Interior Air Quality System (IAQS).

Related information

•

•

•

•

Interior Air Quality System

Interior Air Quality System (IAQS) is a fully
automatic air quality system that separates
gases and particles to reduce the levels of
odours and contaminants in the passenger
compartment.

IAQS is a part of the Clean Zone Interior
Package (CZIP) and cleans the air in the pas-
senger compartment from contaminants such
as particles, hydrocarbons, nitrous oxides and
ground-level ozone.

If the air quality sensor senses that the outside
air is contaminated, the air intake is closed
and air recirculation is activated.

Activating and deactivating the air quality
sensor

The air quality sensor must always be ena-
bled to ensure the best air in the passenger
compartment.

In a cold climate recirculation is limited so
as to prevent misting.

In the event of misting, the defrost func-
tions for windscreen, side windows and
rear window should be used.

Related information

•

•

•

-------------------------------------------------------------------------------------------------------------------------------------------------------------

CLIMATE

* Option/accessory.

203

•

•

Activating and deactivating the air

quality sensor

The air quality sensor is part of the fully auto-
matic air quality system Interior Air Quality
System (IAQS).

It is possible to set whether the air quality sen-
sor should be activated/deactivated.

1. Press

Settings

in the top view in the cen-

tre display.

2. Press

Climate

3. Select

Air Quality Sensor

to activate/

deactivate the air quality sensor.

Related information

•

Passenger compartment filter

All air entering the car's passenger compart-
ment is cleaned with a filter.

Replacing the passenger
compartment filter

To maintain high climate system performance,
the filter must be changed at regular intervals.
Follow the Volvo Service Programme for the
recommended replacement intervals. If the car
is used in a severely contaminated environ-
ment, it may be necessary to replace the filter
more often.

There are different types of passenger
compartment filter. Make sure that the cor-
rect filter is fitted.

Related information

•

•

•

•

-------------------------------------------------------------------------------------------------------------------------------------------------------------

CLIMATE

* Option/accessory.

204

Advanced Air Cleaner

Advanced Air Cleaner is a fully-automatic air
purifier that collects contaminants in the form
of small airborne particulate matter and
exhaust gases in the passenger compartment
filter, which improves the climate in the pas-
senger compartment.

The function is started automatically when the
fan is started.

Small airborne particulate matter is some-
times called PM

2.5

(particles smaller than 2.5

µm), the content of such particles in the car is
measured by one of the car's climate sensors.
The content in the car is presented in the
downloadable Air Quality app.

Related information

•

•

•

•

•

Climate control - sensors (p. 199)

•

Air distribution

The climate control system distributes the
incoming air via a number of different vents in
the passenger compartment.

Automatic and manual air distribution

With auto-regulated climate running the air
distribution takes place automatically. If nec-
essary, the air distribution can be controlled
manually.

Adjustable air vents

Some of the air vents in the car are adjustable,
which means that you can open/close the vent
to aim the air flow.

Location of adjustable air vents in the passenger

compartment.

Four on the instrument panel and one on
each of the door pillars between the front
and rear doors.

Related information

•

Changing air distribution (p. 205)

•

•

Opening, closing and aiming the air vents
(p. 205)

•

Table of air distribution options (p. 207)

-------------------------------------------------------------------------------------------------------------------------------------------------------------

CLIMATE

}}

205

Changing air distribution

The air distribution can be changed manually
if required.

1. Open climate view in the centre display by

pressing the symbol in the middle of the
climate row.

The air distribution buttons in the climate view.

Air distribution - windscreen defroster
vents
Air distribution - air vents in instrument
panel and centre console
Air distribution - air vents in the floor

2. Press one or more of the air distribution

buttons in order to open/close the corres-
ponding air flow.
> The air distribution is changed and the

buttons illuminate/extinguish.

Related information

•

Air distribution (p. 204)

•

Opening, closing and aiming the air vents
(p. 205)

•

Table of air distribution options (p. 207)

Opening, closing and aiming the

air vents

Some air vents in the passenger compart-
ment can be opened, closed and aimed indi-
vidually.

If the car's outer vents are aimed at the side
windows then misting can be eliminated.

If the car's outer vents are aimed inwards
then, in a hot climate, a comfortable environ-
ment is obtained in the passenger compart-
ment.

Opening and closing the air vents

Air vents on the instrument panel:

–

Turn the rotary knob in the middle of the
air vent to open/close the air flow from the
vent.

The air flow is at maximum when the
marking on the knob is in vertical position.

Air vents in the door pillars:

–

Roll the thumbwheel under the air vent in
order to open/close the air flow from the
vent.

The longer the white lines on the thumb-
wheel that are visible, the higher the air
flow.

Aiming the air vents

–

Move the lever in the middle of the air vent
horizontally/vertically to direct the air flow
from the vent.

-------------------------------------------------------------------------------------------------------------------------------------------------------------

CLIMATE

206

Related information

•

Air distribution (p. 204)

•

Changing air distribution (p. 205)

•

Table of air distribution options (p. 207)

-------------------------------------------------------------------------------------------------------------------------------------------------------------

CLIMATE

}}

207

Table of air distribution options

The air distribution can be changed manually
if required. The following options are available
for setting.

Air distribution

Purpose

If all air distribution buttons are deselected in manual mode, the climate control system returns to automatically regulated climate
control.

Main air flow from the defroster vents. Some air flows from other air
vents.

Counteracts misting and icing in a cold and humid cli-
mate (to achieve this, fan level must not be low).

Main air flow from the air vents in the instrument panel. Some air flows
from other air vents.

Provides efficient cooling in a hot climate.

Main air flow from the air vents at the floor. Some air flows from other
air vents.

Provides heat or cooling to the floor.

-------------------------------------------------------------------------------------------------------------------------------------------------------------

CLIMATE

208

Air distribution

Purpose

Main air from the defroster vents and air vents in the instrument panel.
Some air flows from other air vents.

Provides good comfort in hot and dry climates.

Main air flow from the defroster vents and air vents at the floor. Some
air flows from other air vents.

Provides good comfort and good demisting in a cold or
humid climate.

Main air flow from the air vents in the instrument panel and air vents at
the floor. Some air flows from other air vents.

Provides good comfort in sunny weather with cool out-
door temperatures.

Main air flow from the defroster vents, from the air vents in the instru-
ment panel and air vents at the floor.

Gives balanced comfort in the passenger compart-
ment.

-------------------------------------------------------------------------------------------------------------------------------------------------------------

CLIMATE

209

Related information

•

Air distribution (p. 204)

•

Opening, closing and aiming the air vents
(p. 205)

•

Changing air distribution (p. 205)

-------------------------------------------------------------------------------------------------------------------------------------------------------------

CLIMATE

* Option/accessory.

210

Climate controls

The climate control system's functions are
controlled from physical buttons in the centre
console, the centre display and the climate
controls at the rear of the tunnel console

Physical buttons in centre console

Button for heated windscreen

and max

defroster.
Button for heated rear window and door
mirrors.

Climate row in centre display

The most common climate functions can be
regulated from the climate row.

Temperature controls for driver and pas-
senger side.
Controls for heated

and ventilated

driver

and front passenger seat, as well as
heated steering wheel

Button for access to the climate view. The
graphic on the button shows activated cli-
mate settings.

Climate view in centre display

Open climate view by pressing the
symbol in the middle of the climate
row.

Depending on equipment level, the

climate view can be divided into several tabs.
Change between the tabs by swiping left/right
or by pressing the respective heading.

Main climate

In addition to the climate row's functions,
other main climate functions can also be con-
trolled in the

Main climate

tab.

Max

Electric

Rear

- Controls for defrost-

ing the windows and door mirrors.

- Controls for air conditioning.

Recirc

- Controls for air recirculation.

Controls for air distribution.

-------------------------------------------------------------------------------------------------------------------------------------------------------------

CLIMATE

}}

* Option/accessory.

211

Fan control.

AUTO

- Auto regulating the climate.

Parking climate

The car's parking climate control can be regu-
lated in the

Parking climate

tab.

Climate controls at rear of tunnel
console

If the car is equipped with heated rear seats

there are physical buttons at the rear of the
tunnel console for controlling this function.

Related information

•

Activating and deactivating heated front
seat

•

(p. 211)

•

Activating and deactivating heated rear
seat

(p. 212)

•

Activating and deactivating ventilated
front seat

(p. 213)

•

Activating and deactivating the heated
steering wheel

(p. 214)

•

Activating auto climate control (p. 214)

•

Activating and deactivating air recircula-
tion (p. 215)

•

Activating and deactivating max defroster
(p. 216)

•

Activating and deactivating the heated
windscreen

(p. 217)

•

Activating and deactivating the heated
rear window and door mirrors (p. 218)

•

Regulating fan level for front seat (p. 219)

•

Synchronising temperature (p. 221)

•

Activating and deactivating air condition-
ing (p. 221)

Activating and deactivating heated

front seat

The seats can be heated in order to increase
comfort for driver and passengers when it is
cold.

1. Press the left or right-hand side's steering

wheel and seat button in the climate row
in the centre display in order to open the
controls for seat and steering wheel.

If the car is not equipped with ventilated
seats or heated steering wheel (for the
driver's side), the button for heated seats
is immediately available in the climate
row.

2. Repeatedly press the button for heated

seats in order to change between the four
levels:

Off

High

Medium

and

Low

> The level changes and the button

shows the set level.

-------------------------------------------------------------------------------------------------------------------------------------------------------------

CLIMATE

* Option/accessory.

212

WARNING

Heated seats must not be used by people

who find it difficult to perceive an increase

in temperature due to a lack of sensation or

who otherwise have problems operating

the controls for the heated seats.

Related information

•

Activating and deactivating automatic
start of heated front seat

•

(p. 212)

Activating and deactivating

automatic start of heated front

seat

The seats can be heated in order to increase
comfort for driver and passengers when it is
cold.

It is possible to set whether automatic start of
heated seats should be activated/deactivated
when the engine is started. With automatic
start activated, heating will start in the event
of low ambient temperature.

1. Press

Settings

in the top view in the cen-

tre display.

2. Press

Climate

3. Select

Auto Driver Seat Heating Level

and

Auto Passenger Seat Heating Level

to activate/deactivate automatic start of
heated driver's and passenger seat.
> An "A" is shown at each button for

heated front seats in the climate row
when automatic starting has been acti-
vated.

4. Select

Low

Medium

High

to select

level after the function has been activated.

Related information

•

Activating and deactivating heated front
seat

•

(p. 211)

Activating and deactivating heated

rear seat

The seats can be heated in order to increase
comfort for driver and passengers when it is
cold.

Activating and deactivating the heated
rear seat from the rear seat

Buttons for heated seats at the rear of the tunnel

console.

–

Press repeatedly on the left or right-hand
side's physical buttons for heated seats at
the rear of the tunnel console to switch
between the four levels:

Off

High

Medium

and

Low

> The level changes and the LEDs in the

button show the set level.

-------------------------------------------------------------------------------------------------------------------------------------------------------------

CLIMATE

* Option/accessory.

213

WARNING

Heated seats must not be used by people

who find it difficult to perceive an increase

in temperature due to a lack of sensation or

who otherwise have problems operating

the controls for the heated seats.

Related information

•

Activating and deactivating

ventilated front seat

The seats can be ventilated to provide
increased comfort in a hot climate, for exam-
ple.

The ventilation system consists of fans in the
seats and backrests that draw air through the
seat upholstery. The cooling effect increases
the cooler the passenger compartment air
becomes. The system can be activated when
the engine is running.

1. Press the left or right-hand side's steering

wheel and seat button in the climate row
in the centre display in order to open the
controls for seat and steering wheel.

If the car is not equipped with heated
seats or heated steering wheel (for the
driver's side), the button for ventilated
seats is immediately available in the cli-
mate row.

2. Repeatedly press the button for ventilated

seats in order to change between the four
levels:

Off

High

Medium

and

Low

> The level changes and the button

shows the set level.

Related information

•

-------------------------------------------------------------------------------------------------------------------------------------------------------------

CLIMATE

* Option/accessory.

214

Activating and deactivating the

heated steering wheel

The steering wheel can be heated in order to
increase comfort for the driver when it is
cold.

1. Press the driver's side steering wheel and

seat button in the climate row of the cen-
tre display in order to open the controls for
seat and steering wheel.

If the car is not equipped with heated
seats or ventilated seats, the button for
heated steering wheel is immediately
available in the climate row.

2. Repeatedly press the button for heated

steering wheel in order to change
between the four levels:

Off

High

Medium

and

Low

> The level changes and the button

shows the set level.

Related information

•
