K01 Relay, starting switch, radio position (AC:3 C) K02 Relay, EMS (Engine Management (BA:1 A) K03 Relay, starter motor .......................... (AA:2 B/ K04 Relay, body builder fuse box (kl.15) . (ME:2 A/ K05 Relay, I-shift/Powertronic/Retarder ... (DC:0 A/ K06 Relay, fan climate unit ...................... (HY:0 B/ K07 Relay, intermittent wiper ................... (GM:1 C) K08 Relay, gearbox area inhibitor ............ (BA:1 A) K09 Relay, interior lamps ......................... (IH:2 A/ K10 Relay, fifth wheel-, working-light ....... (KE:0 C) K11 Relay, air suspension ....................... (FB:1 B) K12 Relay, reverse light, trailer ................ (GB:4 D) K13 Relay, alternator controlled ............... (AA:4 B) K14 Time delay relay, bogie lift, A-ride ..... (FI:1 B/ K15 Time delay relay, bogie lift, A-ride, (FK:2 C) K16 Relay, bogie lift, A-ride, with axle load (FK:1 C) K20 Relay, D+ short-circuit, (ADR-trucks (AE:4 D) K21 Relay, el. adjustable seat ................. (IA:2 B) K22 Relay, climate fan, 1:st speed (by (HY:1 B/ K23 Relay, cab tilt .................................... (KA:0 C) K24 Relay, central lubrication .................. (FU:0 B) K25 Relay, light sign ................................ (KI:1 C) K26A Relay, foldable rear view mirror arm, Japan ................................................ (IF:0 C) K26B Relay, foldable rear view mirror arm, Japan ................................................ (IF:1 C) K30 Relay, beacon warning light .............. (KM:0 B) K35 Relay, headlamp high pressure wash (GM:0 B) K37 Relay, parking light ........................... (NA:1 C/ K38 Relay, body builder preparation, (NA:1 C/ K39 Relay, body builder preparation, (NA:1 C/ K40 Relay, body builder preparation ........ (NA:3 C/ K41 Relay, body builder preparation, (NA:2 C/ K42 Relay, body builder preparation, (NI:1 B) K43 Relay, body builder preparation, (NC:3 C) K45A Relay, body builder preparation, dual speed ................................................ (NU:2 B) K45B Relay, body builder preparation, dual speed ................................................ (NU:2 C) K48 Power relay, engine preheating ........ (CJ:3 B) K49 Power relay, bogie lift motor ............. (FI:3 B/ K51 Power relay, battery main switch ...... (AB:0 C) K61 Relay, auxiliary reverse light, truck ... (NA:0 C/ K63 Relay, ACC Adaptive cruise control .. (BE:0 B) K64 Relay, man. main switch BBOX-EF .. (AB:1 C) K65 Power relay, starter motor pre-relay . (AA:1 D/ K66 Relay, tail lift indication ..................... (NB:2 C) K67 Relay, rainsensor, high speed wiper . (GM:3 C) K68 Relay, 24V, outlet .............................. (IR2:1 A) K69 Relay, fuel heater, thermoline ........... (FX:0 C) K70A Relay, ADR/SLP ............................... (AF:0 B) K70B Relay, ADR/SLP ............................... (AF:0 D) 230 |
