Toyota FJ Cruiser (GSJ 10, 15 series). Instruction - part 296

LIGHTING  –  REAR COMBINATION LIGHT ASSEMBLY

LI–79

LI

x4

w/ Woofer:

AMPLIFIER BOX
SPEAKER ASSEMBLY

DECK SIDE GARNISH

PACKAGE HOLDER
NET HOOK

QUARTER TRIM POCKET

QUARTER TRIM POCKET TRAY

SIDE TRIM COVER

SPEAKER MOUNTING COVER

N*m (kgf*cm, ft*lbf)  : Specified torque

8.1 (85, 72 in.*lbf)

REAR DECK
TRIM COVER

POWER OUTLET
CONNECTOR

w/ Power Outlet Socket:

RH Side:

SPEAKER CONNECTOR

B134989E02

LI–80

LIGHTING  –  REAR COMBINATION LIGHT ASSEMBLY

LI

DECK TRIM SIDE
PANEL ASSEMBLY
RH

FRONT DOOR
SCUFF PLATE RH

LAP BELT OUTER
ANCHOR COVER

PACKAGE
HOLDER NET
HOOK

REAR DOOR
SCUFF PLATE RH

REAR SEAT OUTER
BELT ASSEMBLY RH

N*m (kgf*cm, ft*lbf)  : Specified torque

42 (430, 31)

x3

RH Side:

B140021E01

LIGHTING  –  REAR COMBINATION LIGHT ASSEMBLY

LI–81

LI

DECK TRIM SIDE PANEL
ASSEMBLY LH

FRONT DOOR
SCUFF PLATE LH

LAP BELT OUTER
ANCHOR COVER

REAR DOOR
SCUFF PLATE LH

REAR SEAT OUTER BELT
ASSEMBLY LH

PACKAGE HOLDER
NET HOOK

N*m (kgf*cm, ft*lbf)  : Specified torque

42 (430, 31)

x3

LH Side:

B140020E01

LI–82

LIGHTING  –  REAR COMBINATION LIGHT ASSEMBLY

LI

REAR COMBINATION LIGHT
ASSEMBLY

N*m (kgf*cm, ft*lbf)  : Specified torque

6.0 (61, 53 in.*lbf)

E127209E01
