Toyota Sequoia (2005). Manual - part 712
B07233
B07234
SST
3/4 Turn
B07235
Front
–
LUBRICATION
OIL AND FILTER
LU–3
2837
(d)
Tighten the oil filter by hand until the rubber gasket con-
tacts the seat of the filter mounting.
(e)
Using SST, give it an additional 3/4 turn to seat the filter.
SST
09228–07501
4.
REFILL WITH ENGINE OIL
(a)
Clean and install the oil drain plug with a new gasket.
Torque: 39 N·m (400 kgf·cm, 29 ft·lbf)
(b)
Fill with fresh engine oil.
Capacity:
Drain and refill
w/ Oil filter change
w/o Oil filter change
6.2 liters (6.6 Us qts, 5.5 Imp. qts)
5.7 liters (6.0 Us qts, 5.0 Imp. qts)
Dry fill
7.1 liters (7.5 Us qts, 6.2 Imp. qts)
(c)
Reinstall the oil filler cap.
HINT:
Install the oil filler cap facing the direction as shown in the il-
lustration.
5.
START ENGINE AND CHECK FOR ENGINE OIL
LEAKS
6.
RECHECK ENGINE OIL LEVEL
7.
w/ Oil filter change:
REINSTALL ENGINE UNDER COVER
