600

8-2. Steps to take in an emergency

(AWD models)

Indicates the AWD system has overheated
→ Immediately stop the vehicle in a safe place

and contact your Toyota dealer.

Indicates a malfunction in the brake override sys-
tem

A buzzer also sounds.

→ Have the vehicle inspected by your Toyota

dealer.

Indicates a malfunction in the Automatic High
Beam system

A buzzer also sounds.

→ Have the vehicle inspected by your Toyota

dealer.

Indicates that the accelerator and brake pedal
are being depressed simultaneously
→ Release the accelerator or brake pedal.

Indicates that the washer fluid level is low
→ Add washer fluid.

Indicates that remaining fuel is approximately 2.9
gal. (10.7 L, 2.4 Imp. gal.) or less
→ Refuel the vehicle.

Indicates that the TRAC (Traction Control) sys-
tem has been deactivated
→ Turn the TRAC on. (→P. 334)

Warning message

Details/Actions

(Flashes)

(Flashes)

601

8-2. Steps to take in an emergency

8

Wh

en tro

uble

 a

ris

es

(U.S.A. only)

Indicates that all maintenance according to the
driven distance on the maintenance schedule

*

should be performed soon.
Comes on approximately 4500 miles (7200 km)
after the message has been reset.
→ If necessary, perform maintenance.

(U.S.A. only)

Indicates that all maintenance is required to cor-
respond to the driven distance on the mainte-
nance schedule

*

.

Comes on approximately 5000  miles (8000 km)
after the message has been reset.
(The indicator will not work properly unless the
message has been reset.)
→ Perform the necessary maintenance.

Please reset the message after the mainte-
nance is performed (

→P. 508)

Indicates that the Automatic High Beam switch is
pressed while the headlights are in low beam.
→ Turn the high beam on and press the Auto-

matic High Beam switch again.

Indicates that, since the VSC (Vehicle Stability
Control) system was turned off, the pre-collision
brake system operation is stopped
→ Turn the VSC on. (→P. 334)

Indicates that the pre-collision system is tempo-
rarily unavailable
→ Please wait until the system returns. If the

message does not disappear, the system
may be malfunctioning. Have the vehicle
inspected by your Toyota dealer immedi-
ately.

Warning message

Details/Actions

(Flashes)

602

8-2. Steps to take in an emergency

*

: Refer to the separate “Scheduled Maintenance Guide” or “Owner’s Manual

Supplement” for the maintenance interval applicable to your vehicle.

■

Messages displays
The message illustrations used are intended as examples, and may differ
from the image that is actually displayed on the multi-information display.

■

Conditions that the tire pressure warning system may not function prop-
erly


→P. 537

■

Warning buzzer


→P. 587

■

Warning message in radar cruise mode
In the following cases, the warning message may not be displayed even if
vehicle-to-vehicle distance decreases:

●

When your vehicle and the vehicle ahead are traveling at the same speed or
the vehicle ahead is traveling more quickly than your vehicle

●

When the vehicle ahead is traveling at a very low speed

●

Immediately after cruise control speed is set

●

At the instant the accelerator pedal is depressed

Indicates that the pre-collision system sensor is
dirty, covered with ice, etc.
→ Remove any dirt, ice, etc.

Warning message

Details/Actions

(Flashes)

603

8-2. Steps to take in an emergency

8

Wh

en tro

uble

 a

ris

es

After taking the specified steps to correct the suspected problem,
check that the warning message and light go off.

Have the malfunction repaired immediately. (vehicles with a
smart key system)

Interior

buzzer

Exterior

buzzer

Warning message

Details/Actions

Con-
tinu-
ous

⎯

The driver’s door was opened
when the shift lever was not in
P and the engine switch was
not turned off.
→ Shift the shift lever to P.

Con-
tinu-
ous

Contin-
uous

The driver’s door was opened
and closed while the electronic
key was not in the vehicle, the
shift lever was not in P and the
engine switch was not turned
off.
→ Shift the shift lever to P.

→ Bring the electronic key

back into the vehicle.

Once

Contin-
uous

An attempt was made to exit
the vehicle with the electronic
key and lock the doors without
first turning the engine switch
off when the shift lever was in P.
→ Turn the engine switch off

and lock the doors again.

(Flashes)

(Displayed alternately)

(Flashes)

(Displayed alternately)

(Flashes)
