Toyota Highlander (2018 year). Manual - part 34

148

3-2. Opening, closing and locking the doors

WARNING

■

Caution regarding interference with electronic devices

●

People with implantable cardiac pacemakers, cardiac resynchronization
therapy-pacemakers or implantable cardioverter defibrillators should keep
away from the smart key system antennas. (

→P. 141)

The radio waves may affect the operation of such devices. If necessary,
the entry function can be disabled. Ask your Toyota dealer for details, such
as the frequency of radio waves and timing of the emitted radio waves.
Then, consult your doctor to see if you should disable the entry function.

●

Users of any electrical medical device other than implantable cardiac
pacemakers, cardiac resynchronization therapy-pacemakers or implant-
able cardioverter defibrillators should consult the manufacturer of the
device for information about its operation under the influence of radio
waves.
Radio waves could have unexpected effects on the operation of such
medical devices.

Ask your Toyota dealer for details on disabling the entry function.

149

3

Op
eration

 o

f each

 compo

nen

t

3-3. Adjusting the seats



Manual seat



Power seat

Front seats

Adjustment procedure

Seat position adjustment lever

Seatback angle adjustment
lever

Vertical height adjustment
lever (driver’s side only)

1
2

3

Seat position adjustment
switch

Seatback angle adjustment
switch

Seat cushion (front) angle
adjustment switch (driver’s
side only)

Vertical height adjustment
switch (driver’s side only)

Seat cushion length adjust-
ment switch (if equipped, for
driver’s seat only)

Lumbar support adjustment
switch (driver’s side only)

1

2

3

4

5

6

150

3-3. Adjusting the seats

WARNING

■

When adjusting the seat position

●

Take care when adjusting the seat position to ensure that other passen-
gers are not injured by the moving seat.

●

Do not put your hands under the seat or near the moving parts to avoid
injury.
Fingers or hands may become jammed in the seat mechanism.

●

Make sure to leave enough space around the feet so they do not get stuck.

■

Seat adjustment

●

Be careful that the seat does not hit passengers or luggage.

●

To reduce the risk of sliding under the lap belt during a collision, do not
recline the seat more than necessary.
If the seat is too reclined, the lap belt may slide past the hips and apply
restraint forces directly to the abdomen, or your neck may contact the
shoulder belt, increasing the risk of death or serious injury in the event of
an accident.
Adjustments should not be made while driving as the seat may unexpect-
edly move and cause the driver to lose control of the vehicle.

●

Manual seat only: After adjusting the seat, make sure that the seat is
locked in position.

151

3-3. Adjusting the seats

3

Op
eration

 o

f each

 compo

nen

t

■

Second seats

■

Third seats

Seatback angle adjustment
strap

Rear seats

Adjustment procedure



Without a side table



With a side table

Seat position adjustment lever

Seatback angle adjustment lever

Pull the lever until the lock is completely released.

1
2
