88

2. Instrument cluster

*

1

: These lights turn on when the engine switch is turned to the “ON” position

(vehicles without a smart key system) or the engine switch is turned to
IGNITION ON mode (vehicles with a smart key system), to indicate that a
system check is being performed. They will turn off after the engine is
started, or after a few seconds. There may be a malfunction in a system if
a light does not come on, or turn off. Have the vehicle inspected by your
Toyota dealer.

*

2

: If equipped

*

3

: This light flashes to indicate a malfunction.

*

4

: This light illuminates on the center panel.

*

5

: This light flashes to indicate a malfunction. Additionally, it will turn on if the

system is turned off.

*

1

(Canada)

Parking brake warning
light (

→P. 582)

89

2. Instrument cluster

2

Instrum

e

nt clus

ter

The indicators inform the driver of the operating state of the vehicle’s
various systems.

Indicators

Turn signal indicator
(

→P. 233)

LDA (Lane Departure
Alert with steering con-
trol) indicator
(

→P. 275)

(U.S.A.)

Headlight indicator
(

→P. 235)

*

2, 3



Intuitive parking assist
indicator

(Canada)

Tail light indicator
(

→P. 235)

*

2

BSM (Blind Spot Moni-
tor) indicator(

→P. 316)

Headlight high beam
indicator (

→P. 236)

*

2, 6, 7

BSM (Blind Spot Moni-
tor) outside rear view
mirror indicators
(

→P. 316)

Automatic High Beam
indicator (

→P. 239)

*

1, 4



Slip indicator (

→P. 333)

*

2

Front fog light indicator
(

→P. 243)

*

1

VSC OFF indicator
(

→P. 333)

Dynamic radar cruise
control (constant speed
control mode) indicator
(

→P. 293)

*

1, 2

All-wheel drive lock indi-
cator (

→P. 330)

Dynamic radar cruise
control (vehicle-to-vehi-
cle distance control
mode) indicator
(

→P. 289)

*

2

Downhill assist control
system indicator
(

→P. 337)

Dynamic radar cruise
control “SET”
indicator (

→P. 289, 293)

*

8

Security indicator
(

→P. 80, 82)

*

1, 5

PCS (Pre-Collision Sys-
tem) warning light
(

→P. 261)

*

1, 9

Eco Driving Indicator
Light (

→P. 102)

90

2. Instrument cluster

*

1

: These lights turn on when the engine switch is turned to the “ON” position

(vehicles without a smart key system) or the engine switch is turned to
IGNITION ON mode (vehicles with a smart key system), to indicate that a
system check is being performed. They will turn off after the engine is
started, or after a few seconds. There may be a malfunction in a system if
a light does not come on, or turn off. Have the vehicle inspected by your
Toyota dealer.

*

2

: If equipped

*

3

: Refer to “NAVIGATION AND MULTIMEDIA SYSTEM OWNER’S MAN-

UAL”.

*

4

: This light flashes to indicate that the system is operating.

*

5

: The light comes on when the system is turned off.

*

2

“PWR MODE” indicator
(

→P. 229)

*

2, 5

Stop & Start cancel indi-
cator (

→P. 297)

Snow mode indicator
(

→P. 228)

*

1, 8

(U.S.A.)

“AIR BAG ON/
OFF” indicator
(

→P. 53)

*

2

Stop & Start indicator
(

→P. 297)

*

1, 8

(Canada)

“AIR BAG ON/
OFF” indicator
(

→P. 53)

91

2. Instrument cluster

2

Instrum

e

nt clus

ter

*

6

: In order to confirm operation, the BSM outside rear view mirror indicators

illuminate in the following situations:



Vehicles without a smart key system

• When the BSM function is enabled on

 of the multi-information dis-

play, the engine switch is turned to the “ON” position.

• When the engine switch is the “ON” position, the BSM function is

enabled on

 of the multi-information display.



Vehicles with a smart key system

• When the BSM function is enabled on

 of the multi-information dis-

play, the engine switch is turned to IGNITION ON mode.

• When the engine switch is in IGNITION ON mode, the BSM function is

enabled on

 of the multi-information display.

If the system is functioning correctly, the BSM outside rear view mirror indi-
cators will turn off after a few seconds.

If the BSM outside rear view mirror indicators do not illuminate or do not
turn off, there may be a malfunction in the system.

If this occurs, have the vehicle inspected by your Toyota dealer.

*

7

: This light illuminates on the outside rear view mirrors.

*

8

: This light illuminates on the center panel.

*

9

: This light does not turn on when the system is disabled.

WARNING

■

If a safety system warning light does not come on
Should a safety system light such as the ABS and SRS warning lights not
come on when you start the engine, this could mean that these systems are
not available to help protect you in an accident, which could result in death
or serious injury. Have the vehicle inspected by your Toyota dealer immedi-
ately if this occurs.
