Toyota Highlander (2018 year). Manual - part 15

72

1-1. For safe use

Run the seat belt through the
child restraint system and
insert the plate into the
buckle. Make sure that the
belt is not twisted.

Fully extend the shoulder belt
and allow it to retract to put it
in lock mode. In lock mode,
the belt cannot be extended.

While pushing the child
restraint system into the rear
seat, allow the shoulder belt
to retract until the child
restraint system is securely
in place.

After the shoulder belt has
retracted to a point where there
is no slack in the belt, pull the
belt to check that it cannot be
extended.

If the child restraint has a top tether strap, the top tether strap
should be latched onto the top tether strap anchor. (

→P. 75)

3

4

5

6

73

1-1. For safe use

1

Fo
r

safety and securi

ty

■

Booster seat

Adjusting the seat



Second seats

Fold the seatback while pulling
the lever. Return the seatback
and secure it at the 1st lock
position (most upright position).

Move the seat as far back as
possible.



Third seats

Fold the seatback while pulling
the strap. Return the seatback
and secure it at the 1st lock
position (most upright position).

Place the child restraint system on the seat facing the front of the
vehicle.

If your child restraint system interferes with a head restraint and cannot
be installed properly, install the child restraint system after removing the
head restraint. (

→P. 163)

1

2



High back type



Booster type

74

1-1. For safe use

Sit the child in the child
restraint system. Fit the seat
belt to the child restraint sys-
tem according to the manu-
facturer’s instructions and
insert the plate into the
buckle. Make sure that the
belt is not twisted.

Check that the shoulder belt is correctly positioned over the child’s
shoulder and that the lap belt is as low as possible. (

→P. 30)

Push the buckle release button
and fully retract the seat belt.

3

Removing a child restraint installed with a seat belt

75

1-1. For safe use

1

Fo
r

safety and securi

ty

Raise the head restraint so that
the top tether strap can easily
be passed between the head
restraint and seatback.

If your child restraint system inter-
feres with a head restraint and can-
not be installed properly, install the
child restraint system after remov-
ing the head restraint. (

→P. 163)

Secure the child restraint sys-
tem using the seat belt or
LATCH anchors.

Open the anchor bracket cover,
latch the hook onto the anchor
bracket and tighten the top
tether strap.

Run the top tether strap under the
head restraint.

Make sure the top tether strap is
securely latched.

■

Laws and regulations pertaining to anchorages
The LATCH system conforms to FMVSS225 or CMVSS210.2.
Child restraint systems conforming to FMVSS213 or CMVSS213 specifica-
tions can be used.
This vehicle is designed to conform to the SAE J1819.

Child restraint systems with a top tether strap

1

2

3
