Last Modified: 9-16-2014 6.6 A Doc ID: RM000002ZY1017X Model Year: 2015 Model: Tundra Prod Date Range: [08/2014 - ] Title: AUDIO / VISUAL: INSTRUMENT PANEL SPEAKER (for CrewMax): INSTALLATION; 2015 MY Tundra [08/2014 - ] INSTALLATION 1. INSTALL FRONT NO. 4 SPEAKER ASSEMBLY (for 12 Speakers) (a) Connect the connector. (c) Install the front No. 4 speaker assembly with the 2 bolts. Torque: 3.5 N·m {36 kgf·cm, 31in·lbf} NOTICE: (a) Attach the 8 clips to install the No. 1 speaker hole cover. 3. INSTALL FRONT NO. 2 SPEAKER ASSEMBLY RH (a) Connect the connector. (c) Install the front No. 2 speaker assembly RH with the 2 bolts. Torque: 3.5 N·m {36 kgf·cm, 31in·lbf} NOTICE: (a) Connect the connector. (c) Install the front No. 2 speaker assembly LH with the 2 bolts. Torque: 3.5 N·m {36 kgf·cm, 31in·lbf} NOTICE: |
