illustration. *1 HINT: Standard distance A: 21.00 to 21.76 mm (0.834 to 0.857 in.) (e) Assemble the 4 discs, 3 plates and flange as shown in the HINT: Standard distance B: 16.54 to 17.15 mm (0.651 to 0.675 in.) (f) Apply the A and B measurements taken in *1 and *2 to the graph below. Use A for the X axis and B for the Y axis, and then choose the flange indicated by the graph point. AB60F AUTOMATIC TRANSMISSION: AUTOMATIC TRANSMIS... |
