SYMPTOM SUSPECTED AREA SEE PAGE ECM No engine brake ECM No kick-down ECM Engine stalls when starting off or stopping Shift solenoid valve SLU circuit* ECM ATF temperature warning light remains on, lock-up at 3rd gear and/or shift point too high No. 2 ATF temperature sensor circuit* Engine coolant temperature sensor circuit (for 3UR-FE)* Engine coolant temperature sensor circuit (for 3UR-FBE)* ECM Malfunction in shifting Park/neutral position switch circuit* Transmission control switch circuit ECM Harsh engagement (1st -> 2nd -> 3rd -> 4th -> 5th) Shift solenoid valve SR circuit* Slip or shudder (5th -> 6th -> and 6th -> 5th) Shift solenoid valve SR circuit* 2. CHAPTER 2: ON-VEHICLE REPAIR AND OFF-VEHICLE REPAIR SYMPTOM SUSPECTED AREA SEE PAGE Vehicle does not move when shift lever is in any forward position or reverse position Transmission control cable (for Column Shift Type) Transmission control cable (for Floor Shift Type) Manual valve Parking lock pawl Rear planetary gear unit Torque converter Vehicle does not move with shift lever on R Valve body assembly B4 brake No up-shift (1st -> 2nd) Valve body assembly B3 brake F1 one-way clutch F2 one-way clutch No up-shift (2nd -> 3rd) Valve body assembly AB60F AUTOMATIC TRANSMISSION: AUTOMATIC TRANSMIS... |
