Last Modified: 9-16-2014 6.6 A Doc ID: RM000002YBA01DX Model Year: 2015 Model: Tundra Prod Date Range: [08/2014 - ] Title: A760F AUTOMATIC TRANSMISSION: SHIFT LEVER ASSEMBLY (for Column Shift Type): DISASSEMBLY; 2015 MY Tundra [08/2014 - ] DISASSEMBLY 1. REMOVE COLUMN SHIFT SHIFTING BELLCRANK ASSEMBLY (a) Remove the bolt and shifting bellcrank from the column shift control shift lever retainer. 2. REMOVE COLUMN SHIFT LEVER COMPRESSION SPRING (a) Remove the bolt and spring from the column shift control shift lever retainer. 3. REMOVE SHIFT LEVER PLATE SUB-ASSEMBLY (a) Disconnect the transmission control switch connector clamp from the column shift. (b) Detach the wire harness clamp and cut off the 4 wire guides. A760F AUTOMATIC TRANSMISSION: SHIFT LEVER ASSEMBLY (... |
