Last Modified: 9-16-2014 6.6 C Doc ID: RM000000W8G0I8X Model Year: 2015 Model: Tundra Prod Date Range: [08/2014 - ] Title: A760F AUTOMATIC TRANSMISSION: AUTOMATIC TRANSMISSION SYSTEM: P0778; Pressure Control Solenoid "B" Electrical (Shift Solenoid Valve SL2); 2015 MY Tundra [08/2014 - ] DTC P0778 Pressure Control Solenoid "B" Electrical (Shift Solenoid Valve SL2) DESCRIPTION solenoid valves, the ECM controls the remaining normal shift solenoid valves to allow the vehicle to be operated safely
. DTC CODE DTC DETECTION CONDITION TROUBLE AREA P0778 The ECM checks for an open or short in the shift solenoid valve SL2 circuit while driving and shifting gears (1-trip detection logic). Output signal duty equals 100%. HINT: SL2 output signal duty is less than 100% under normal conditions. Open or short in shift solenoid valve SL2 circuit Shift solenoid valve SL2 ECM MONITOR DESCRIPTION This DTC indicates an open or short in the shift solenoid valve SL2 circuit. The ECM commands gear shifts by turning the shift solenoid valves ON/OFF. When there is an open or short circuit in any shift solenoid valve circuit, the ECM detects the problem, illuminates the MIL and stores the DTC. Also, the ECM performs the fail-safe While driving and shifting gears, if the ECM detects an open or short in the shift solenoid valve SL2 circuit, the ECM determines there is a malfunction
. MONITOR STRATEGY Related DTCs P0778: Shift solenoid valve SL2/Range check Required sensors/Components Shift solenoid valve SL2 Duration 1 second MIL operation Immediately TYPICAL ENABLING CONDITIONS A760F AUTOMATIC TRANSMISSION: AUTOMATIC TRANSMISS... |
