Vehicle speed (After transition to 5th gear) Less than 100 km/h (62.2 mph) TYPICAL MALFUNCTION THRESHOLDS [OFF malfunction] Turbine speed / Output speed (NT / NO) 0.93 or more, and 1.07 or less (This means actual gear is 4th) OFF Malfunction (B) Turbine speed / Output speed (NT / NO) 0.51 or more, and 0.65 or less (This means actual gear is 6th) [ON malfunction] Turbine speed / Output speed (NT / NO) 1.28 or more, and 1.53 or less (This means actual gear is 3rd) ON Malfunction (B) Turbine speed - Output speed x 4th gear ratio (NT - NO x 4th gear ratio) 1000 rpm or more ON Malfunction (C) Turbine speed - Output speed x 5th gear ratio (NT - NO x 5th gear ratio) 1000 rpm or more INSPECTION PROCEDURE NOTICE: Perform the universal trip to clear permanent DTCs
. 1. ACTIVE TEST HINT: Using the Techstream to perform Active Tests allows relays, VSVs, actuators and other items to be operated without removing any parts. This non-intrusive functional inspection can be very useful because (a) Warm up the engine. (b) Turn the ignition switch off. A760F AUTOMATIC TRANSMISSION: AUTOMATIC TRANSMISS... |
