NOTICE: HINT: *1 Squeegee *2 Rear Body Stripe LH *3 Release Paper *4 Application Sheet *a Sectional View *b Non-padded Side *c Padded Side *d Pressing *e Pulling - - (1) Remove the release paper and apply the tape carefully with your fingers. (2) Before applying the tape to each corner, heat the tape using a heat light and gradually apply it to avoid wrinkles in the tape and achieve a neat finish. (g) Check after installation (1) After completing the application, check if the tape is applied neatly. If the tape is not applied neatly, apply new tape. NOTICE: Do not reuse the tape. (h) Install a new rear body stripe LH. (1) Using a heat light, heat the vehicle body and a new rear body stripe LH. EXTERIOR: NAME PLATE: INSTALLATION; 2015 MY Tundra [08/... |
