Last Modified: 9-16-2014 6.6 N Doc ID: RM000002ZO500WX Model Year: 2015 Model: Tundra Prod Date Range: [08/2014 - ] Title: ENGINE HOOD / DOOR: FRONT DOOR (for CrewMax): ADJUSTMENT; 2015 MY Tundra [08/2014 - ] ADJUSTMENT HINT: Before adjusting the door position for vehicles equipped with side airbags and curtain shield airbags, be sure to disconnect the battery. After adjustment, inspect the SRS warning light and check for DTC
. Use the same procedures for the RH side and LH side. 1. ADJUST FRONT DOOR (a) Disconnect the cable from the negative (-) battery terminal. CAUTION: Wait at least 90 seconds after disconnecting the cable from the negative (-) battery terminal to prevent airbag and seat belt NOTICE: Some systems need to be initialized after the cable is
. After the ignition switch is turned OFF, the navigation system (b) Using SST, loosen the body's hinge bolts and adjust the door's position. SST: 09812-00010 (c) Using SST, tighten the body's hinge bolts after the adjustment. Torque: 29 N·m {296 kgf·cm, 21ft·lbf} ENGINE HOOD / DOOR: FRONT DOOR (for CrewMax): ADJUST... |
