TESTER DISPLAY
MEASUREMENT ITEM/RANGE
NORMAL
CONDITION
DIAGNOSTIC NOTE
14 psi)
max.: 449.35 kPa (4.5 kgf/cm
2
, 63 psi)
ID 3 Initial
Threshold of
Low-pressure
min.: 100.00 kPa (1 kgf/cm
2
,
14 psi)
max.: 449.35 kPa (4.5 kgf/cm
2
, 63 psi)
Tire pressure after
initialization
-
ID 4 Initial
Threshold of
Low-pressure
min.: 100.00 kPa (1 kgf/cm
2
,
14 psi)
max.: 449.35 kPa (4.5 kgf/cm
2
, 63 psi)
Tire pressure after
initialization
-
ID 5 Initial
Threshold of
Low-pressure
-
-
-
min.: 0
max.: 255
0
-
HINT:
*1: Displayed only when the ID No. is not registered.
*2: It may take about 5 or 6 minutes until the values are displayed. If the values are not displayed after a
few minutes, perform troubleshooting according to the inspection procedure for DTCs C2121/21 to
C2124/24
.
2. PERFORM ACTIVE TEST
HINT:
Using the Techstream to perform Active Tests allows relays, VSVs, actuators and other items to be
operated without removing any parts. This non-intrusive functional inspection can be very useful because
intermittent operation may be discovered before parts or wiring is disturbed. Performing Active Tests early
in troubleshooting is one way to save diagnostic time. Data List information can be displayed while
performing Active Tests.
(a) Turn the ignition switch off.
(b) Connect the Techstream to the DLC3.
(c) Turn the ignition switch to ON and the Techstream on.
(d) Enter the following menus: Body / Combination Meter / Active Test.
(e) According to the display on the tester, perform the "Active Test".
Combination Meter
TESTER DISPLAY
TEST PART
CONTROL
RANGE
DIAGNOSTIC NOTE
Indicat. Tire Pressure
Tire pressure
ON or OFF
Perform the test with the vehicle stopped
