housing. HINT: Check the identification mark stamped on the camshaft. ITEM MARK for Intake Side NO. 1 for Exhaust Side NO. 2 (c) Confirm the marks and numbers on the camshaft bearing caps and place them in their proper positions and directions. (d) Temporarily install the 10 bolts in the order shown in the illustration. 22. INSTALL CAMSHAFT HOUSING SUB-ASSEMBLY RH (a) Make sure that the valve rocker arms are installed as shown in the illustration. (b) Apply seal packing in a continuous line as shown in the illustration. Seal packing: Toyota Genuine Seal Packing Black, Three Bond 1207B or equivalent Standard seal diameter: 3.5 to 4.0 mm (0.138 to 0.157 in.) NOTICE: Remove any oil from the contact surface. 3UR-FE ENGINE MECHANICAL: ENGINE UNIT: REASSEMBLY; 2... |
