Toyota Tundra (2015 year). Manual - part 1870





DTC

CODE

DETECTION ITEM

MIL

MEMORY

DTC FOR

MEXICO

MODELS

SEE

PAGE

P0120

Throttle / Pedal Position Sensor / Switch "A"

Circuit Malfunction

Comes on

DTC

stored

Applies

P0121

Throttle / Pedal Position Sensor / Switch "A"

Circuit Range / Performance Problem

Comes on

DTC

stored

Applies

P0122

Throttle / Pedal Position Sensor / Switch "A"

Circuit Low Input

Comes on

DTC

stored

Applies

P0123

Throttle / Pedal Position Sensor / Switch "A"

Circuit High Input

Comes on

DTC

stored

Applies

P0125

Insufficient Coolant Temperature for Closed

Loop Fuel Control

Comes on

DTC

stored

Applies

P0128

Coolant Thermostat (Coolant Temperature

Below Thermostat Regulating Temperature)

Comes on

DTC

stored

Applies

P0136

Oxygen Sensor Circuit Malfunction (Bank 1

Sensor 2)

Comes on

DTC

stored

-

P0137

Oxygen Sensor Circuit Low Voltage (Bank 1

Sensor 2)

Comes on

DTC

stored

Applies

P0138

Oxygen Sensor Circuit High Voltage (Bank 1

Sensor 2)

Comes on

DTC

stored

-

P0139

Oxygen Sensor Circuit Slow Response (Bank 1

Sensor 2)

Comes on

DTC

stored

-

P013A

Oxygen Sensor Slow Response - Rich to Lean

Bank 1 Sensor 2

Comes on

DTC

stored

-

P013C

Oxygen Sensor Slow Response - Rich to Lean

Bank 2 Sensor 2

Comes on

DTC

stored

-

P0141

Oxygen Sensor Heater Circuit Malfunction (Bank

1 Sensor 2)

Comes on

DTC

stored

Applies

P014C

A/F Sensor Slow Response - Rich to Lean Bank

1 Sensor 1

Comes on

DTC

stored

-

P014D

A/F Sensor Slow Response - Lean to Rich Bank

1 Sensor 1

Comes on

DTC

stored

-

P014E

A/F Sensor Slow Response - Rich to Lean Bank

2 Sensor 1

Comes on

DTC

stored

-

P014F

A/F Sensor Slow Response - Lean to Rich Bank

2 Sensor 1

Comes on

DTC

stored

-

P0156

Oxygen Sensor Circuit Malfunction (Bank 2

Sensor 2)

Comes on

DTC

stored

-

P0157

Oxygen Sensor Circuit Low Voltage (Bank 2

Sensor 2)

Comes on

DTC

stored

Applies

P0158

Oxygen Sensor Circuit High Voltage (Bank 2

Sensor 2)

Comes on

DTC

stored

-

P0159

Oxygen Sensor Circuit Slow Response (Bank 2

Sensor 2)

Comes on

DTC

stored

-

3UR-FE ENGINE CONTROL SYSTEM: SFI SYSTEM: DIAGNOSTI...

DTC

CODE

DETECTION ITEM

MIL

MEMORY

DTC FOR

MEXICO

MODELS

SEE

PAGE

P015A

A/F Sensor Delayed Response - Rich to Lean

Bank 1 Sensor 1

Comes on

DTC

stored

-

P015B

A/F Sensor Delayed Response - Lean to Rich

Bank 1 Sensor 1

Comes on

DTC

stored

-

P015C

A/F Sensor Delayed Response - Rich to Lean

Bank 2 Sensor 1

Comes on

DTC

stored

-

P015D

A/F Sensor Delayed Response - Lean to Rich

Bank 2 Sensor 1

Comes on

DTC

stored

-

P0161

Oxygen Sensor Heater Circuit Malfunction (Bank

2 Sensor 2)

Comes on

DTC

stored

Applies

P0171

System Too Lean (Bank 1)

Comes on

DTC

stored

Applies

P0172

System Too Rich (Bank 1)

Comes on

DTC

stored

Applies

P0174

System Too Lean (Bank 2)

Comes on

DTC

stored

Applies

P0175

System Too Rich (Bank 2)

Comes on

DTC

stored

Applies

P0220

Throttle / Pedal Position Sensor / Switch "B"

Circuit

Comes on

DTC

stored

Applies

P0222

Throttle / Pedal Position Sensor / Switch "B"

Circuit Low Input

Comes on

DTC

stored

Applies

P0223

Throttle / Pedal Position Sensor / Switch "B"

Circuit High Input

Comes on

DTC

stored

Applies

P0300

Random / Multiple Cylinder Misfire Detected

Comes on/

Blinks*1

DTC

stored

Applies

P0301

Cylinder 1 Misfire Detected

Comes on/

Blinks*1

DTC

stored

Applies

P0302

Cylinder 2 Misfire Detected

Comes on/

Blinks*1

DTC

stored

Applies

P0303

Cylinder 3 Misfire Detected

Comes on/

Blinks*1

DTC

stored

Applies

P0304

Cylinder 4 Misfire Detected

Comes on/

Blinks*1

DTC

stored

Applies

P0305

Cylinder 5 Misfire Detected

Comes on/

Blinks*1

DTC

stored

Applies

P0306

Cylinder 6 Misfire Detected

Comes on/

Blinks*1

DTC

stored

Applies

P0307

Cylinder 7 Misfire Detected

Comes on/

Blinks*1

DTC

stored

Applies

P0308

Cylinder 8 Misfire Detected

Comes on/

Blinks*1

DTC

stored

Applies

3UR-FE ENGINE CONTROL SYSTEM: SFI SYSTEM: DIAGNOSTI...

DTC

CODE

DETECTION ITEM

MIL

MEMORY

DTC FOR

MEXICO

MODELS

SEE

PAGE

P0327

Knock Sensor 1 Circuit Low Input (Bank 1 or

Single Sensor)

Comes on

DTC

stored

Applies

P0328

Knock Sensor 1 Circuit High Input (Bank 1 or

Single Sensor)

Comes on

DTC

stored

Applies

P032C

Knock Sensor 3 Circuit Low

Comes on

DTC

stored

Applies

P032D

Knock Sensor 3 Circuit High

Comes on

DTC

stored

Applies

P0332

Knock Sensor 2 Circuit Low Input (Bank 2)

Comes on

DTC

stored

Applies

P0333

Knock Sensor 2 Circuit High Input (Bank 2)

Comes on

DTC

stored

Applies

P0335

Crankshaft Position Sensor "A" Circuit

Comes on

DTC

stored

Applies

P0337

Crankshaft Position Sensor "A" Circuit Low Input Comes on

DTC

stored

Applies

P0338

Crankshaft Position Sensor "A" Circuit High

Input

Comes on

DTC

stored

Applies

P0339

Crankshaft Position Sensor "A" Circuit

Intermittent

-

DTC

stored

Applies

P033C

Knock Sensor 4 Circuit Low Input

Comes on

DTC

stored

Applies

P033D

Knock Sensor 4 Circuit High Input

Comes on

DTC

stored

Applies

P0340

Camshaft Position Sensor Circuit Malfunction

Comes on

DTC

stored

Applies

P0342

Camshaft Position Sensor "A" Circuit Low Input

(Bank 1 or Single Sensor)

Comes on

DTC

stored

Applies

P0343

Camshaft Position Sensor "A" Circuit High Input

(Bank 1 or Single Sensor)

Comes on

DTC

stored

Applies

P0345

Camshaft Position Sensor "A" Circuit (Bank 2)

Comes on

DTC

stored

Applies

P0347

Camshaft Position Sensor "A" Circuit Low Input

(Bank 2)

Comes on

DTC

stored

Applies

P0348

Camshaft Position Sensor "A" Circuit High Input

(Bank 2)

Comes on

DTC

stored

Applies

P0351

Ignition Coil "A" Primary / Secondary Circuit

Comes on

DTC

stored

Applies

P0352

Ignition Coil "B" Primary / Secondary Circuit

Comes on

DTC

stored

Applies

P0353

Ignition Coil "C" Primary / Secondary Circuit

Comes on

DTC

stored

Applies

3UR-FE ENGINE CONTROL SYSTEM: SFI SYSTEM: DIAGNOSTI...

DTC

CODE

DETECTION ITEM

MIL

MEMORY

DTC FOR

MEXICO

MODELS

SEE

PAGE

P0354

Ignition Coil "D" Primary / Secondary Circuit

Comes on

DTC

stored

Applies

P0355

Ignition Coil "E" Primary / Secondary Circuit

Comes on

DTC

stored

Applies

P0356

Ignition Coil "F" Primary / Secondary Circuit

Comes on

DTC

stored

Applies

P0357

Ignition Coil "G" Primary / Secondary Circuit

Comes on

DTC

stored

Applies

P0358

Ignition Coil "H" Primary / Secondary Circuit

Comes on

DTC

stored

Applies

P0365

Camshaft Position Sensor "B" Circuit (Bank 1)

Comes on

DTC

stored

Applies

P0367

Camshaft Position Sensor "B" Circuit Low Input

(Bank 1)

Comes on

DTC

stored

Applies

P0368

Camshaft Position Sensor "B" Circuit High Input

(Bank 1)

Comes on

DTC

stored

Applies

P0390

Camshaft Position Sensor "B" Circuit (Bank 2)

Comes on

DTC

stored

Applies

P0392

Camshaft Position Sensor "B" Circuit Low Input

(Bank 2)

Comes on

DTC

stored

Applies

P0393

Camshaft Position Sensor "B" Circuit High Input

(Bank 2)

Comes on

DTC

stored

Applies

P0412

Secondary Air Injection System Switching Valve

"A" Circuit

Comes on

DTC

stored

Applies

P0415

Secondary Air Injection System Switching Valve

"B" Circuit

Comes on

DTC

stored

Applies

P0418

Secondary Air Injection System Control "A"

Circuit

Comes on

DTC

stored

Applies

P0419

Secondary Air Injection System Control "B"

Circuit

Comes on

DTC

stored

Applies

P0420

Catalyst System Efficiency Below Threshold

(Bank 1)

Comes on

DTC

stored

Applies

P0430

Catalyst System Efficiency Below Threshold

(Bank 2)

Comes on

DTC

stored

Applies

P043E

Evaporative Emission System Leak Detection

Reference Orifice Low Flow

Comes on

DTC

stored

-

P043F

Evaporative Emission System Reference Orifice

High Flow

Comes on

DTC

stored

-

P0441

Evaporative Emission Control System Incorrect

Purge Flow

Comes on

DTC

stored

-

P0443

Evaporative Emission Control System Purge

Control Valve Circuit

Comes on*2 DTC

stored*2

Applies

3UR-FE ENGINE CONTROL SYSTEM: SFI SYSTEM: DIAGNOSTI...
