OK OK TESTER CONNECTION CONDITION SPECIFIED CONDITION 1C-1 - 1B-4 When battery voltage is applied to terminals 1B-2 and 1B-3 Below 1 Ω NG REPLACE INTEGRATION RELAY 3. CHECK HARNESS AND CONNECTOR (ECM - BODY GROUND) (a) Disconnect the D74 ECM connector. (b) Measure the resistance according to the value(s) in the table below. Standard resistance: TESTER CONNECTION CONDITION SPECIFIED CONDITION D74-81 (E1) - Body ground Always Below 1 Ω NG REPAIR OR REPLACE HARNESS OR CONNECTOR 4. INSPECT ECM (IGSW VOLTAGE) 3UR-FBE ENGINE CONTROL SYSTEM: SFI SYSTEM: ECM Power... |
