If a pending DTC is not output, perform the following procedure. Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness. 9. Input the DTC: P060D. 10. Check the DTC judgment result. TESTER DISPLAY DESCRIPTION NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions N/A Unable to perform DTC judgment HINT: If the judgment result shows ABNORMAL, the system has a malfunction. 11. If the test result is INCOMPLETE or N/A and no pending DTC is output, perform a universal trip and check for permanent DTCs
. HINT: If a permanent DTC is output, the system is malfunctioning. 12. INSPECTION PROCEDURE NOTICE: After turning ignition switch off, waiting time may be required before disconnecting the cable from the negative (-) battery terminal. Therefore, make sure to read the disconnecting the cable from the negative (-) battery terminal notices before proceeding with work
. HINT: Read freeze frame data using the Techstream. The ECM records vehicle and driving condition information as freeze frame data the moment a DTC is stored. When troubleshooting, freeze frame PROCEDURE 1. CHECK DTC (a) Clear DTC
. (b) Turn the ignition switch off. (c) Disconnect the cable from the negative (-) battery terminal and wait for 1 minute. (d) Connect the cable to the negative (-) battery terminal. 3UR-FBE ENGINE CONTROL SYSTEM: SFI SYSTEM: P060D; Inter... |
