Toyota Tundra (2015 year). Manual - part 31
Last Modified: 9-16-2014
6.6 A
Doc ID: RM0000042IP006X
Model Year: 2015
Model: Tundra
Prod Date Range: [08/2014 - ]
Title: AUDIO / VISUAL: SATELLITE RADIO ANTENNA: INSTALLATION; 2015 MY Tundra [08/2014 - ]
INSTALLATION
1. INSTALL SATELLITE RADIO ANTENNA ASSEMBLY
(a) Attach the 2 claws and guide to install the satellite radio antenna assembly.
(b) Install the nut.
Torque:
4.5 N·m {45 kgf·cm, 39in·lbf}
Text in Illustration
*a
Guide
-
-
(c) Attach the 3 clamps.
(d) Connect the connector.
2. INSTALL ROOF HEADLINING ASSEMBLY
(a) for Double Cab:
(b) for CrewMax:
(c) for Regular Cab:
3. CONNECT CABLE TO NEGATIVE BATTERY TERMINAL
NOTICE:
AUDIO / VISUAL: SATELLITE RADIO ANTENNA: INSTALLATION...
