HINT: Prepare a battery as the power source to deploy the airbag. a. Check the function of SST (see DIAGNOSIS SYSTEM ). b. Remove the curtain shield airbag (see REMOVAL ). Fig. 305: Checking Function Of SST c. Cut off the deployment section of the curtain shield airbag. Fig. 306: Locating Deployment Section Of Curtain Shield Airbag d. Using a service-purpose wire harness for the vehicle, tie down the curtain shield airbag to the tire. Wire harness: Stripped wire harness section 1.25 mm 2 or more (0.00193 in. 2 or more)
CAUTION: If the wire harness is too thin or an alternative object is used to tie down the curtain shield airbag, it may be snapped by the 2 (0.00193 in. 2 ).
2009 Toyota Tundra 2009 RESTRAINTS Supplemental Restraint System - Tundra
|
